The diameter of the nil-clean graph of $\mathbb{Z}_n$

1.   Introduction

Using special elements to characterize the properties and structure of rings is a very common method, and it is also a very popular research field, which has attracted widespread attention by many researchers. Idempotents, nilpotent elements, and units are three very important types of elements that play a crucial role in characterizing the properties and structure of rings, and have also sparked many new concepts and the classes of rings, for example, clean rings, nil-clean rings, 2-good rings, and fine rings (see ^[8,9,13,17]).

On the other hand, using graphic properties and invariants to characterize the structure and properties of rings has been a hot research field in recent decades. After Beck ^[6] introduced the zero-divisor graph of a commutative ring in 1998, especially after Anderson and Livingston ^[3] modified the definition in 1999, various graph structures on rings were defined and studied, for example, unit graphs of rings, total graphs of rings, comaximal ideal graph of rings, zero-divisor graphs with respect to ideals of rings, and cozero divisor graphs (see ^{[2,5,12,14,18]}). This greatly enriches the methods for studying the properties and structures of rings. In 2017, Basnet and Bhattacharyya ^[7] introduced the nil-clean graph of a ring and studied its basic properties. Due to the complexity of the nil-clean elements of a ring, the properties of the nil-clean graph of the ring are less known. Even the diameter of the nil-clean graph for a basic finite commutative ring, such as the residue class ring of integers modulo $n$, is not completely clear. As usual, we use $\mathbb{Z}_n$ to denote the residue class ring of integers modulo $n$. In ^[7], the authors have only showed that ${\rm diam} (G_{NC}(\mathbb{Z}_{2^k})) = 1$; ${\rm diam}(G_{NC}(\mathbb{Z}_{2^k3^l})) = 2$ for $k\geq 0$ and $l\geq1$; ${\rm diam}(G_{NC}(\mathbb{Z}_{p})) = p-1$ for a prime $p$; and ${\rm diam}(G_{NC}(\mathbb{Z}_{2p})) = {\rm diam}(G_{NC}(\mathbb{Z}_{3p})) = p-1$ for an odd prime $p$. Let $n = p_1^{\alpha_1} \cdots p_s^{\alpha_s}$ be a prime factorization and $p_1 < \cdots < p_s$. We show that ${\rm diam}(G_{NC}(\mathbb{Z}_n)) = p_s-1$.

Diameter is one of the important invariants of a graph. Many papers are devoted to the diameter of the resulting graph in this research area (see ^[1,4,11,15]). For the unit graph of a ring, Heydari and Nikmehr ^[10] proved that the diameter of the unit graph of an Artinian ring only has four possibilities: $1, 2, 3, \infty$, and they classified all Artinian rings via its diameter of unit graphs. In 2019, Su and Wei generalized the result to self-injective rings in ^[16]. They also proved that there exists a ring such that the diameter of its unit graph is more than three.

Let $R$ be a ring with identity. We use $Id(R)$ and $Nil(R)$ to denote the set of all idempotents and the set of all nilpotent elements of $R$, respectively. An element $r$ is said to be a nil-clean element if $r$ is a sum of an idempotent and a nilpotent element in $R$. The set of all nil-clean elements of $R$ is denoted as the notation $NC(R)$. The nil-clean graph of $R$, denoted by $G_{NC}(R)$, is a simple graph with $R$ as its vertex set, and two distinct vertices $x$ and $y$ are adjacent if, and only if, $x+y\in NC(R)$. In the absence of the condition that vertex $x$ is not same as $y$, the graph defined in the same way is called the closed nil-clean graph of $R$, which may contain loops, and is denoted by $\overline{G_{NC}}(R)$. Some basic properties are studied in ^[7], for example, they have showed that $G_{NC}(R)$ is a complete graph if, and only if, $R$ is a nil-clean ring; the degree of a vertex $x$ in $G_{NC}(R)$ is either $\mid NC(R) \mid -1$ or $\mid NC(R) \mid$ depending on if $2x$ belongs to $NC(R)$ or not; and $G_{NC}(R)$ is a bipartite graph if, and only if, $R$ is a field.

We recall some necessary notions in graph theory. Let $G$ be a simple graph, meaning it has no loops and multi-edges. We use the symbol $x \sim y$ to denote when two vertices $x$ and $y$ in a graph $G$ are adjacent. A walk of lengths $k$ with endpoints $v_0$ and $v_k$ in $G$ is a sequence of vertices $(v_0, v_1, \ldots, v_{k-1}, v_k)$, in which $v_{i-1} \sim v_{i}$ for every $i = 1, \ldots, k$. A path in a graph is a walk that has all distinct vertices (except the endpoints). A graph $G$ is connected if there is a path between each pair of the vertices of $G$; otherwise, $G$ is disconnected. The distance between two vertices $x$ and $y$, denoted by $d(x, y)$, is the length a shortest path between $x$ and $y$. If there is no path connecting two vertices, the distance between them is defined as infinite. The longest distance between all pairs of vertices of $G$ is called the diameter of $G$, and is denoted by ${\rm diam}(G)$. Let $G_1, G_2$ be two graphs. Their tensor product, denoted by $G_1 \otimes G_2$, is a graph with vertex set $G_1 \times G_2$, where $(x_1, x_2) \sim (y_1, y_2)$ if, and only if, $x_1 \sim y_1$ in $G_1$ and $x_2 \sim y_2$ in $G_2$.

2.   Main results and proofs

To begin, we decompose the graph $\overline{G_{NC}}(\mathbb{Z}_{n})$ into $\overline{G_{NC}}(\mathbb{Z}_{p_1^{\alpha_1}}) \otimes \cdots \otimes \overline{G_{NC}}(\mathbb{Z}_{p_s^{\alpha_s}})$ for the prime factorization $n = p_1^{\alpha_1} \cdots p_s^{\alpha_s}$. On this basis, we mainly provide a complete characterization of ${\rm diam}(\mathbb{Z}_n)$. In addition, a mechanical way to find a path between two vertices $x$ and $y$ in $G_{NC}(\mathbb{Z}_{n})$ is given.

For two isomorphic rings, their nil-clean graphs are clearly isomorphic as well. Due to the Chinese remainder theorem, there is an isomorphism of the rings, $\mathbb{Z}_n\cong \mathbb{Z}_{p_1^{\alpha_1}} \times \cdots \times \mathbb{Z}_{p_s^{\alpha_s}}$, where $n = p_1^{\alpha_1}\cdots p_s^{\alpha_s}$ is the prime factorization. Therefore, we are now investigating the nil-clean graph of the ring $\mathbb{Z}_{p_1^{\alpha_1}} \times \cdots \times \mathbb{Z}_{p_s^{\alpha_s}}$, and denoting it by $G_{NC}(\mathbb{Z}_n)$ by abuse of notation.

Let $R_1$ and $R_2$ be two rings. We have that $Nil(R_1 \times R_2) = Nil(R_1) \times Nil(R_2)$ and $Id(R_1 \times R_2) = Id(R_1) \times Id(R_2)$. For a prime $p$ and a positive integer $\alpha$, $\mathbb{Z}_{p^{\alpha}}$ is a commutative local ring, having the unique maximal ideal $Nil(\mathbb{Z}_{p^{\alpha}}) = (p)$, and $Id(\mathbb{Z}_{p^{\alpha}})$ is trivial. Then, $NC(\mathbb{Z}_{p^{\alpha}})$ is the disjoint union $(p) \cup 1 + (p)$, where $1 + (p) = \left\lbrace 1 + x \in \mathbb{Z}_{p^{\alpha}} \mid x \in (p) \right\rbrace$. We have that $NC(\mathbb{Z}_{p_1^{\alpha_1}} \times \mathbb{Z}_{p_2^{\alpha_2}}) = NC(\mathbb{Z}_{p_1^{\alpha_1}}) \times NC(\mathbb{Z}_{p_2^{\alpha_2}})$. The following proposition characterizes the form of nil-clean elements in $\mathbb{Z}_{p_1^{\alpha_1}} \times \cdots \times \mathbb{Z}_{p_s^{\alpha_s}}$.

Proposition 2.1. Give $x = (x_1, \ldots, x_s) \in \mathbb{Z}_{p_1^{\alpha_1}} \times \cdots \times \mathbb{Z}_{p_s^{\alpha_s}}$. Then, $x$ is a nil-clean element of $\mathbb{Z}_{p_1^{\alpha_1}} \times \cdots \times \mathbb{Z}_{p_s^{\alpha_s}}$ if, and only if, $x_i$ is a nil-clean element of $\mathbb{Z}_{p_i^{\alpha_i}}$, for every $i = 1, \ldots, s$.

Proof. Suppose $x = (x_1, \ldots, x_s)$ is a nil-clean element in $\mathbb{Z}_{p_1^{\alpha_1}} \times \cdots \times \mathbb{Z}_{p_s^{\alpha_s}}$, then there exists an idempotent $y = (y_1, \ldots, y_s)$ and a nilpotent element $z = (z_1, \ldots, z_s)$, such that $x = y+z = (y_1+z_1, \ldots, y_s+z_s)$. Note that $y_i$ is an idempotent element of $\mathbb{Z}_{p_i^{\alpha_i}}$ and $z_i$ is a nilpotent element of $\mathbb{Z}_{p_i^{\alpha_i}}$, for every $i = 1, \ldots, s$. Thus, $x_i$ is a nil-clean element of $\mathbb{Z}_{p_i^{\alpha_i}}$, for every $i = 1, \ldots, s$.

Conversely, suppose that $x_i$ is a nil-clean element of $\mathbb{Z}_{p_i^{\alpha_i}}$, for each $i = 1, \ldots, s$. Then, there exist an idempotent element $y_i \in \mathbb{Z}_{p_i^{\alpha_i}}$ and a nilpotent element $z_i \in \mathbb{Z}_{p_i^{\alpha_i}}$, such that $x_i = y_i+z_i$, for each $i = 1, \ldots, s$. Note that $y = (y_1, \ldots, y_s)$ is an idempotent and $z = (z_1, \ldots, z_s)$ is a nilpotent element in $\mathbb{Z}_{p_1^{\alpha_1}} \times \cdots \times \mathbb{Z}_{p_s^{\alpha_s}}$. The equality $x = y+z$ implies that $x$ is a nil-clean element in $\mathbb{Z}_{p_1^{\alpha_1}} \times \cdots \times \mathbb{Z}_{p_s^{\alpha_s}}$. □

We can determine the adjacency relation of $G_{NC}(\mathbb{Z}_n)$ completely by Proposition 2.1.

Corollary 2.1. Suppose that $x = (x_1, \ldots, x_s)$ and $y = (y_1, \ldots, y_s)$ are distinct vertices of $G_{NC}(\mathbb{Z}_n)$. Then, $x$ and $y$ are adjacent if, and only if, $x_i + y_i$ is a nil-clean element of $\mathbb{Z}_{p_i^{\alpha_i}}$, for every $i = 1, \ldots, s$. More precisely, $x$ and $y$ are adjacent if, and only if, $x_i+y_i \in (p_i) \cup 1+ (p_i)$, for every $i = 1, \ldots, s$. In short, $\overline{G_{NC}}(\mathbb{Z}_{n}) \cong \overline{G_{NC}}(\mathbb{Z}_{p_1^{\alpha_1}}) \otimes \cdots \otimes \overline{G_{NC}}(\mathbb{Z}_{p_s^{\alpha_s}})$.

It is a fact that $\mathbb{Z}_{p^{\alpha}} / (p) \cong \mathbb{Z}_p$, and it is easy to study the nil-clean graph of $\mathbb{Z}_p$. In particular, we can determine the diameter of $G_{NC}(\mathbb{Z}_p$), as stated in Proposition 2.2 below, which has been shown in ^[7].

Proposition 2.2. Let $p$ be a prime. Then, $G_{NC}(\mathbb{Z}_p)$ is a path with $p$ vertices and its diameter is $p-1$.

Proof. $\mathbb{Z}_p$ is a field with characteristic $p$. There are only two nil-clean elements, $0$ and $1$, in $\mathbb{Z}_p$. For any vertex $x \in G_{NC}(\mathbb{Z}_p)$, the only adjacent vertices are $p-x$ and $p-x+1$. This implies that $G_{NC}(\mathbb{Z}_p)$ is a path. For two vertices $x$ and $y$ in $G_{NC}(\mathbb{Z}_p)$, the path between them is unique. Note that $d(0, \frac{p+1}{2}) = p-1$. Therefore, ${\rm diam}(G_{NC}(\mathbb{Z}_p)) = p-1$. □

Proposition 2.3. Let $p$ be a prime and $\alpha$ be a positive integer. Then, ${\rm diam}(G_{NC}(\mathbb{Z}_{p^\alpha})) = p-1$.

Proof. The facts that $\mathbb{Z}_{p^\alpha} / (p) \cong \mathbb{Z}_p$ and $Nil(\mathbb{Z}_{p^\alpha}) = (p)$ are evident. Let $x, y \in \mathbb{Z}_{p^\alpha}$ and $\overline{x}, \overline{y}\in \mathbb{Z}_{p^\alpha} / (p)$. Thus, by Proposition 2.2, there is a unique path from $\overline{x}$ to $\overline{y}$ in the graph $G_{NC}(\mathbb{Z}_p)$. We may assume that the path is $\left(x_1, x_2, \ldots, x_{l-1}, x_l \right\rbrace$, where $x_1 = \overline{x}$ and $x_l = \overline{y}$. It is easy to see that $\left(x, x_2, \ldots, x_{l-1}, y \right\rbrace$ is a path from $x$ to $y$ in $G_{NC}(\mathbb{Z}_{p^\alpha})$. Thus, ${\rm diam}(G_{NC}(\mathbb{Z}_{p^\alpha})) \le {\rm diam}(G_{NC}(\mathbb{Z}_p)) = p-1$.

Next, we show that $d(0, \frac{p+1}{2}) = p-1$ in the graph $G_{NC}(\mathbb{Z}_{p^\alpha})$. Assume, to the contrary, there exists a path from $0$ and $\frac{p+1}{2}$ to a length less than $p-1$. This forces that $d(0, \frac{p+1}{2}) < p-1$ in the graph $G_{NC}(\mathbb{Z}_p)$, which contradicts Proposition 2.2. This completes the proof. □

Lemma 2.1. Let $p$ be a prime, $q$ be an odd positive integer, and $q \ge p$, $x$ and $y$ be two vertices in ${G_{NC} (\mathbb{Z}_{p^\alpha})}$. Then, there exists a sequence $\left\lbrace \beta_k \right\rbrace _{k = 1}^{k = q}$ consisting $q$ elements $($allowing repeat$)$ of $\mathbb{Z}_{p^\alpha}$, where $\beta_1 = x, \beta_q = y$, such that $\beta_k + \beta_{k+1}$ is a nil-clean element of $\mathbb{Z}_{p^\alpha}$, for every $k = 1, \ldots, q-1$.

Proof. In the case $p = 2$, $\mathbb{Z}_{2^\alpha}$ is a nil-clean ring, and ${G_{NC} (\mathbb{Z}_{2^\alpha})}$ is a complete graph with $2^\alpha$ vertices. Let $\beta_1 = \cdots = \beta_{q-1} = x, \beta_q = y$.

For $p$ is an odd prime, we discuss the case where $q = p$ since we just need to repeat the last two elements of the sequence when $q > p$. Without loss of generality, suppose that $d (0, \overline{x}) = \min\{{d (0, \overline{x}), d (\overline{x}, \frac{p+1}{2}), d (0, \overline{y}), d (\overline{y}, \frac{p+1}{2})} \}$ in $G_{NC}(\mathbb{Z}_p)$. There exists a unique shortest path from $\overline{x}$ to $0$ in $G_{NC}(\mathbb{Z}_p)$ by Proposition 2.2, denoted by $(v_1, \ldots, v_{d (0, \overline{x})+1})$, where $\overline{x} = v_1$ and $v_{d (0, \overline{x})+1} = 0$. Similarly, there exists a unique shortest path from $0$ to $\overline{y}$, denoted by $(u_1, \ldots, u_{d (0, \overline{y})+1})$, where $u_1 = 0$ and $u_{d(0, \overline{y})+1} = \overline{y}$.

Let $\beta_1 = x, \beta_2 = v_2, \cdots, \beta_{d (0, \overline{x})} = v_{d (0, \overline{x})} = 1,$ $\beta_{d (0, \overline{x}) + 1} = \cdots = \beta_{q - d (0, \overline{y})} = 0,$ $\beta_{q - d (0, \overline{y}) + 1} = u_2 = 1, \beta_{q - d (0, \overline{y}) + 2} = u_3 = p-1, \cdots,$ $\beta_{q-1} = u_{d(0, \overline{y})}, \beta_{q} = y$. The sequence $\left\lbrace \beta_k \right\rbrace _{k = 1}^{k = q}$ is desired. □

Now, we prove the main result in this note.

Theorem 2.1. Let $n = p_1^{\alpha_1} \cdots p_s^{\alpha_s}$ be the prime factorization, where $p_1 < \cdots < p_s$. Then, ${\rm diam}(G_{NC}(\mathbb{Z}_n)) = p_s-1$.

Proof. It holds for the case $n = 2^\alpha$, and $G_{NC}(\mathbb{Z}_{2^\alpha})$ is a complete graph. In other cases, give two vertices $(x_1, \ldots, x_s)$, $(y_1, \ldots, y_s) \in \mathbb{Z}_{p_1^{\alpha_1}} \times \cdots \times \mathbb{Z}_{p_s^{\alpha_s}}$.

For $i = 1$, $p = p_1$, and $q = p_s$, there exists a sequence $\left\lbrace \alpha_k^1 \right\rbrace _{k = 1}^{k = p_s}$ by Lemma 2.1, where $\alpha_1^1 = x_1$, $\alpha_{p^s}^1 = y_1$, such that $\alpha_k^1 + \alpha_{k+1}^1 \in NC(\mathbb{Z}_{p_1^{\alpha_1}})$, for every $k = 1, \ldots, p_s-1$.

For $i = 2$, $p = p_2$, and $q = p_s$, there exists a sequence $\left\lbrace \alpha_k^2 \right\rbrace _{k = 1}^{k = p_s}$ by Lemma 2.1, where $\alpha_1^2 = x_2$, $\alpha_{p^s}^2 = y_2$, such that $\alpha_k^2 + \alpha_{k+1}^2 \in NC(\mathbb{Z}_{p_2^{\alpha_2}})$, for every $k = 1, \ldots, p_s-1$.

Continuing this process, for $i = s$, $p = p_s$, and $q = p_s$, there exists a sequence $\left\lbrace \alpha_k^s \right\rbrace _{k = 1}^{k = p_s}$ by Lemma 2.1, where $\alpha_1^s = x_s$, $\alpha_{p^s}^s = y_s$, such that $\alpha_k^s + \alpha_{k+1}^s \in NC(\mathbb{Z}_{p_s^{\alpha_s}})$, for every $k = 1, \ldots, p_s-1$.

We obtain the sequence $\left\lbrace (\alpha_k^1, \ldots, \alpha_k^s) \right\rbrace _{k = 1}^{k = p_s}$, where $(\alpha_1^1, \ldots, \alpha_1^s) = (x_1, \ldots, x_s) = x$ and $(\alpha_{p_s}^1, \ldots, \alpha_{p_s}^s) = (y_1, \ldots, y_s) = y$. In addition, $(\alpha_k^1 + \alpha_{k+1}^1, \ldots, \alpha_k^s + \alpha_{k+1}^s)$ is a nil-clean element in $\mathbb{Z}_{p_1^{\alpha_1}} \times \cdots \times \mathbb{Z}_{p_s^{\alpha_s}}$, for every $k = 1, \ldots, p_s -1$. Then, there exists a path from $x$ to $y$ according the above sequence by removing those consecutive duplicate vertices (if applicable). Thus, ${\rm diam}(G_{NC}(\mathbb{Z}_n)) \le p_s-1$. On the other hand, it is clear that $d\big{(}(0, \ldots, 0, 0), (0, \ldots, 0, \frac{p_s + 1}{2})\big{)}$ is $p_s-1$ in $G_{NC}(\mathbb{Z}_n)$ by Proposition 2.3, and ${\rm diam}(G_{NC}(\mathbb{Z}_n)) \geq p_s-1$. This completes the proof. □

We finish this note with an example to helping in understanding Theorem 2.1.

Example 2.1. Let $n = 2^4 7^3 11^2 = 664048$, $\mathbb{Z}_{664048} \cong \mathbb{Z}_{2^4} \times \mathbb{Z}_{7^3} \times \mathbb{Z}_{11^2}$. Given $(1,339, 20)$, $(12, 55,114) \in \mathbb{Z}_{2^4} \times \mathbb{Z}_{7^3} \times \mathbb{Z}_{11^2}$, then $\overline{1} = 1$, $\overline{12} = 0 \in \mathbb{Z}_2$, $\overline{339} = 3$, $\overline{55} = 6 \in \mathbb{Z}_7$, $\overline{20} = 9$, $\overline{114} = 4 \in \mathbb{Z}_{11}$.

For $p = 2$ and $q = 11$, we obtain the sequence $\{ 1, 1, 1, 1, 1, 1, 1, 1, 1, 1, 12 \}$ by Lemma 2.1.

For $p = 7$ and $q = 11$, then $d (3, 4) = \min \{ d (0, 6), d (0, 3), d (3, 4), d (6, 4) \}$ in the graph $G_{NC}(\mathbb{Z}_7)$. We obtain the sequence $\{ 339, 4, 4, 3, 5, 2, 55, 2, 55, 2, 55 \}$ by Lemma 2.1.

For $p = 11$ and $q = 11$, then $d (4, 5) = \min \{ d (0, 9), d (0, 4), d (4, 5), d (9, 4) \}$ in the graph $G_{NC}(\mathbb{Z}_{11})$. We obtain the sequence $\{ 20, 3, 8, 4, 7, 6, 5, 5, 6, 7,114 \}$ by Lemma 2.1.

According to the proof of Theorem 2.1, we obtain the sequence: $\beta_1 = (1,339, 20)$, $\beta_2 = (1, 4, 3)$, $\beta_3 = (1, 4, 8)$, $\beta_4 = (1, 4, 4)$, $\beta_5 = (1, 4, 7)$, $\beta_6 = (1, 4, 5)$, $\beta_7 = (1, 4, 6)$, $\beta_8 = (1, 3, 6)$, $\beta_9 = (1, 5, 5)$, $\beta_{10} = (1, 2, 7)$, $\beta_{11} = (12, 55,114)$. We do not need to delete any vertices of this sequence, and obtain the path from $(1,339, 20)$ to $(12, 55,114)$ in the graph $G_{NC}(\mathbb{Z}_{2^4} \times \mathbb{Z}_{7^3} \times \mathbb{Z}_{11^2})$.

Remark 2.1. For a finite commutative ring $R$, we have the Artin's decomposition in local rings of $R \cong R_1 \times \cdots \times R_s$. Next, we may study the nil-clean graph of the finite product of finite fields, ignoring the impact of nilpotent elements on calculating the diameter. For a finite field $GF(p^k)$, $G_{NC}(GF(p^k))$ is the union of a path with $p$ vertices and $\frac{p^{k-1}-1}{2}$ $2p$-cycles ^[7]. In particular, ${\rm diam} (G_{NC}(GF(p^k))) = \infty$ when $k > 1$. Note that graph $G \otimes H$ is disconnected when one of $G$ and $H$. In other words, ${\rm diam} (G_{NC}(R)) = p-1$ for some prime $p$ or $\infty$.
