Linear regression of triple diffusive and dual slip flow using Lie Group transformation with and without hydro-magnetic flow

  • These authors contributed equally to this work and are co-first authors
  • This study examines the flow of an incompressible flow over a linear stretching surface with the inclusion of momentum and thermal slip conditions. A scaling set of alterations is applied to the governing system for both with and without magnetic field situations. The physical system being leftover invariant caused by some associations surrounded by the transformations. Later we find the absolute invariants 3rd -order ODEs for the linear momentum equation and two 2nd order ODEs consistent with the energy and concentration are obtained. The equations that coincide with the boundary circumstances are elucidated mathematically. The physical pertinent parameters as shown in graphs and the friction factor, Nusselt number and Salts 1 and 2 Sherwood numbers are shown in surface plots. We observed that the momentum slip parameter decelerates the skin friction coefficient in the presence of a magnetic field and enhances in the absence of the magnetic field parameter. The thermal slip parameter enhances the Nusselt number in both the presence and absence of magnetic field parameter. Finally, the thermal and concentration buoyancy ratio parameters are shown to upsurge the friction factor, Nusselt and Salts 1 and 2 Sherwood numbers in both cases of M=0 and M=1.

    Citation: T. Mahesh Kumar, Nehad Ali Shah, V. Nagendramma, P. Durgaprasad, Narsu Sivakumar, B. Madhusudhana Rao, C. S. K. Raju, Se-Jin Yook. Linear regression of triple diffusive and dual slip flow using Lie Group transformation with and without hydro-magnetic flow[J]. AIMS Mathematics, 2023, 8(3): 5950-5979. doi: 10.3934/math.2023300

    Related Papers:

    [1] Khalil Ur Rehman, Wasfi Shatanawi, Zead Mustafa . Artificial intelligence (AI) based neural networks for a magnetized surface subject to tangent hyperbolic fluid flow with multiple slip boundary conditions. AIMS Mathematics, 2024, 9(2): 4707-4728. doi: 10.3934/math.2024227
    [2] Sami Ul Haq, Saeed Ullah Jan, Syed Inayat Ali Shah, Ilyas Khan, Jagdev Singh . Heat and mass transfer of fractional second grade fluid with slippage and ramped wall temperature using Caputo-Fabrizio fractional derivative approach. AIMS Mathematics, 2020, 5(4): 3056-3088. doi: 10.3934/math.2020198
    [3] Kottakkaran Sooppy Nisar, Muhammad Shoaib, Muhammad Asif Zahoor Raja, Yasmin Tariq, Ayesha Rafiq, Ahmed Morsy . Design of neural networks for second-order velocity slip of nanofluid flow in the presence of activation energy. AIMS Mathematics, 2023, 8(3): 6255-6277. doi: 10.3934/math.2023316
    [4] Muhammad Asif Zahoor Raja, Kottakkaran Sooppy Nisar, Muhammad Shoaib, Ajed Akbar, Hakeem Ullah, Saeed Islam . A predictive neuro-computing approach for micro-polar nanofluid flow along rotating disk in the presence of magnetic field and partial slip. AIMS Mathematics, 2023, 8(5): 12062-12092. doi: 10.3934/math.2023608
    [5] Yousef Jawarneh, Humaira Yasmin, Wajid Ullah Jan, Ajed Akbar, M. Mossa Al-Sawalha . A neural networks technique for analysis of MHD nano-fluid flow over a rotating disk with heat generation/absorption. AIMS Mathematics, 2024, 9(11): 32272-32298. doi: 10.3934/math.20241549
    [6] Nadeem Abbas, Wasfi Shatanawi, Taqi A. M. Shatnawi, Fady Hasan . Theoretical analysis of induced MHD Sutterby fluid flow with variable thermal conductivity and thermal slip over a stretching cylinder. AIMS Mathematics, 2023, 8(5): 10146-10159. doi: 10.3934/math.2023513
    [7] Ali Raza, Umair Khan, Aurang Zaib, Wajaree Weera, Ahmed M. Galal . A comparative study for fractional simulations of Casson nanofluid flow with sinusoidal and slipping boundary conditions via a fractional approach. AIMS Mathematics, 2022, 7(11): 19954-19974. doi: 10.3934/math.20221092
    [8] W. Abbas, Ahmed M. Megahed, Osama M. Morsy, M. A. Ibrahim, Ahmed A. M. Said . Dissipative Williamson fluid flow with double diffusive Cattaneo-Christov model due to a slippery stretching sheet embedded in a porous medium. AIMS Mathematics, 2022, 7(12): 20781-20796. doi: 10.3934/math.20221139
    [9] Abdulaziz H. Alharbi, Ahmed G. Salem . Analytical and numerical investigation of viscous fluid-filled spherical slip cavity in a spherical micropolar droplet. AIMS Mathematics, 2024, 9(6): 15097-15118. doi: 10.3934/math.2024732
    [10] K. Veera Reddy, G. Venkata Ramana Reddy, Ali Akgül, Rabab Jarrar, Hussein Shanak, Jihad Asad . Numerical solution of MHD Casson fluid flow with variable properties across an inclined porous stretching sheet. AIMS Mathematics, 2022, 7(12): 20524-20542. doi: 10.3934/math.20221124
  • This study examines the flow of an incompressible flow over a linear stretching surface with the inclusion of momentum and thermal slip conditions. A scaling set of alterations is applied to the governing system for both with and without magnetic field situations. The physical system being leftover invariant caused by some associations surrounded by the transformations. Later we find the absolute invariants 3rd -order ODEs for the linear momentum equation and two 2nd order ODEs consistent with the energy and concentration are obtained. The equations that coincide with the boundary circumstances are elucidated mathematically. The physical pertinent parameters as shown in graphs and the friction factor, Nusselt number and Salts 1 and 2 Sherwood numbers are shown in surface plots. We observed that the momentum slip parameter decelerates the skin friction coefficient in the presence of a magnetic field and enhances in the absence of the magnetic field parameter. The thermal slip parameter enhances the Nusselt number in both the presence and absence of magnetic field parameter. Finally, the thermal and concentration buoyancy ratio parameters are shown to upsurge the friction factor, Nusselt and Salts 1 and 2 Sherwood numbers in both cases of M=0 and M=1.



    Nomenclature

    uandv Fluid velocities corresponding in x and y-directions
    a The rate of stretching sheet
    L The momentum slip parameter
    V The thermal slip factor
    ψ Stream function
    r1,r2,r3,r4,r5,r6 Any constant real arbitrary parameter
    η Similarity variable
    f,θ,ϕ1,ϕ2 Dependent variables
    α1 Momentum slip parameter
    α2 Thermal slip parameter
    τw Shear stress
    qw Heat flux
    h1m and h2m Mass flux
    Le1 and Le2 Lewis numbers
    ϕ1 Salt 1 concentration
    ϕ2 Salt 2 concentration
    Λ1 Thermal buoyancy ratio parameter
    Λ2 Solutal buoyancy ratio parameter
    M Magnetic field parameter
    T Temperature of the fluid
    C Concentration of the fluid
    βT Thermal buoyancy
    βC1 Solutal 1 buoyancy
    βC2 Solutal 2 buoyancy
    C1 and C2 Solutal 1and 2 at ambient flow
    ν Kinematic viscosity of the fluid
    Pr Prandtl number
    θ Temperature
    g Gravity
    ε Small parameter
    λ>0 Buoyancy assisting flow
    λ<0 Buoyancy opposing flow
    Cf Local friction factor
    Nux Local Nusselt number
    Shx1 and Shx2 Local Sherwood numbers
    C1w and C2w Concentrations 1 and 2 at the wall
    Rex Reynolds number
    α Thermal diffusivity
    Ds1 and Ds2 Mass 1 and 2 diffusivities

    Lie group transformation or scaling group transformation has elements which are arbitrary close to the identity transformation, which means that the identity transformation is a transformation that changes nothing at all. When two mechanisms contributing to the density diffuse at different rates, convective waves can arise in a steadily stratified liquid. Sophus Lie's [1] was developed a differential invariant similarity for the Lie-group. His work was almost forgotten because of the growth of group theory and differential geometry to study differential equations [2]. Using Jeffrey and cross fluid models Bhatti et al. [3] and Sumer et al. [4] analysed importance of momentum with Lie group transformation. Numerical simulation of a thermally enhanced electro-magnetohydrodynamic (EMHD) flow of a heterogeneous micropolar mixture comprising (60%)-ethylene glycol, (40%) water, and copper oxide nanomaterials was studied by Shah et al. [5] and MHD heat transfer in thermal slip using semi-infinite domain and Carreau fluid has been discussed by Rehman et al. [6]. In recent year, so many researchers made their studies on Lie group transformation [7,8,9]. A two-component modeling for non-Newtonian nanofluid slips flow and heat transfer over sheet discussed by Rana et al. [10]. They observed that the heat transfer is decreases with increase in Brownian motion and thermophoresis parameters. Amanulla et al. [11] studied the numerical analysis of magnetohydrodynamic Williamson nanofluid over an isothermal sphere in the presence of momentum and thermal slip effects. Zhang et al. [12] proposed a new multi-view clustering model called Consensus Multi-view Clustering (CMC) model, and it is based on non-negative matrix factorization for predicting the multiple stages of Arithmetic design progression. The proposed CMC model performs multi-view learning to fully capture data features with limited medical images, analyzes similarity relations between different entities, addresses the shortcoming of multi-view fusion that requires manual setting parameters, and further acquires a consensus representation containing shared features and complementary knowledge of multiple view data. Later, Batool et al. [13] performed a numerical analysis of heat and mass transfer in micropolar nanofluids flow through a lid-driven cavity by using the finite volume method. They found that a high vortex viscosity parameter produces a weak concentration field and has significant behaviour when the Reynolds number is significant. Maneengam et al. [14] analyzed the entropy generation in a two-dimensional Lid-Driven porous container in the presence of obstacles of different shapes and under the influences of buoyancy and Lorentz forces. They concluded that the triangular shape of the baffle is the best in terms of thermal activity and also they observed that increasing the number of lower-wall waves reduces thermal activity. Bhutta et al. [15] experimentally investigated the development of novel hybrid two-dimensional and three-dimensional graphene oxide diamond microcomposite polyimide films to ameliorate electrical and thermal conduction. They found that the hybrid fillers with high thermal and low electrical conductivities were responsible for synergistic improvements in the experimental results.Rasool et al. [16] performed a numerical investigation of electromagnetohydrodynamic nanofluid flows over a convectively heated Riga pattern positioned horizontally in a Darcy-Forchheimer porous medium. They observed that Darcy-Forchheimer's and Lorentz's forces strengthen the resulting frictional factor at the Riga surface. Rasool et al. [17] reported on the Darcy-Forchheimer flow of water conveying multi-walled carbon nanoparticles through a vertical Cleveland z-staggered cavity subject to entropy generation. They found that the velocity of incompressible Darcy-Forchheimer flow at the middle vertical Cleveland Z-staggered cavity declines with a higher Reynolds number.

    The phenomena of heat and mass transport associated with entropy production describe the triple diffusion process, which can be found in metallurgy, oceanography, and geophysics. When more than one salt is used in a combined heat and mass transfer, the salts interact and cause coupling effects. In recent years tremendous research activity has been dedicated to developing various fluid models by using the triple diffusive effect: for examples with numerous geometries and multiple body forces, the reader is referred to Arif et al. [18], Patil et al. [19], Nawaz et al. [20] and Manjappa et al. [21]. Such techniques used to investigate momentum, thermal and various effects have been discussed by Patil et al. [22]; also the roughness of a surface with the nanofluid is studied by Patil et al. [23].

    The numerical studies incorporated for thermal and momentum slips by Xiong et al. [24] and Beg et al. [25]. Su et al. [26] investigated that increasing flow and convective heat transmission were explored numerically inside circular and parallel-plates micro channels. The slip flow of conductive viscoelastic flow past a permeable radiated shrinking or stretching surface with mass transpiration has been illustrated by Sneha et al. [27]. The significance of nanoparticle shape and thermo-hydrodynamic slip constraints on MHD alumina-water nanoliquid flows over a rotating heated disk has been discussed by Sabu et al. [28]. Numerous researchers Koriko et al. [29], Eleni Seid et al. [30], Turkyilmazoglu [31], Felipe et al. [32], Majeed et al. [33] and Zeeshan et al. [34] are carried out for different fluid model with various surfaces to analyse the influence of momentum and thermal slips.

    No research work has been done using Lie group transformation analysis to analyze the significance of triple diffusive convective flow by considering thermal and momentum slips, as per the authors' knowledge of the literature in most practical uses; however, the components of mass and heat are inextricably linked. The heat and mass diffusion components, on the other hand, are invariably coupled in most real-world applications. Triple diffusion of a fluid has practical applications in many bioengineering and medical sciences. For instance, aqueous suspensions of DNA contain more than two independently diffusing constituents with dissimilar diffusivities and medical drug manufacturing methods etc. However, triple diffusion in the presence of an applied magnetic field has significant applications in metallurgy, solar physics, geophysics, cosmic fluid dynamics, polymer industry, in the motion of the earth's core. This fact prompts us to investigate the combined impact of mass diffusion heat on magnetohydrodynamic free-convective flow in the boundary layer. As far as we can tell, the findings of this work appear to be perfectly consistent with previous research and, due to their simplicity, easily transferable to relevant applications.

    We perform the analysis of the steady triple diffusive hydromagnetic flow of heat and mass transmission of a viscous, electrically conducting fluid. The flow is supposed to be in the x-direction and y-axis perpendicular to it. A uniform magnetic field of strength B is offered perpendicular to the flow direction. It is also considered that all fluid possessions are fixed excluding the impact of the density deviation with temperature and concentration. The surface is retained at a fixed temperature Tw, which is greater than the constant.

    For this study, we have considered a triple diffusive free convective MHD incompressible flow with momentum and thermal slip conditions for a fluid model with the help of Lie group transformation analysis. Also, suppose that the flow generation is estimated for a linear widening surface. Additionally, the flow is restricted to the region y>0 and equivalent with the plane y>0.

    Under the pre-defined assumptions mentioned above, the governing system of continuity, energy, momentum and concentration are expressed as follows:

    ˉuˉx+ˉvˉy=0, (1)
    ˉuˉuˉx+ˉvˉuˉy=v2ˉuˉy2+[gβT(TT)+gβC1(CC1)+gβC2(CC2)σB2ρˉu], (2)
    ˉuˉTˉx+ˉvˉTˉy=α2ˉTˉy2, (3)
    ˉuC1ˉx+ˉvC1ˉy=DS12C1ˉy2, (4)
    ˉuC2ˉx+ˉvC2ˉy=DS12C2ˉy2, (5)

    Given the following boundary conditions:

    ˉu=aˉx+Luy,ˉv=0,T=Tw+D1Ty,C1=C1w,C2=C2watη=0ˉuu,TT,C1C1,C2C2asη, (6)

    Now, we need to transform the above Eqs (1) to (6) into non-dimensional form. To perform this, the following similarity dimensionless transformations are considered.

    u=ˉuav,v=ˉvav,x=ˉxv/a,y=ˉyv/aθ=TTTwT,ϕ1=C1C1C1wC1,ϕ2=C2C2C2wC2, (7)

    We substitute the above non-dimensional quantities of (7) in Eqs (1) to (5) along with the boundary conditions of Eq (6) and then complete the simplification results by using the following non-dimensional differential equations :

    ux+vy=0, (8)
    uux+vuy=2uy2σB2ρau+λθ+Λ1ϕ1+Λ2ϕ2, (9)
    uϕ1x+vϕ1y=DS1v2ϕ1y2, (10)
    uϕ1x+vϕ1y=DS1ν2ϕ1y2, (11)
    uϕ2x+vϕ2y=DS2v2ϕ2y2, (12)

    with the following boundary conditions :

    u=x+Lavuy,v=0,θ=1+D1avθy,ϕ1=1,ϕ2=1atη=0u0,θ0,ϕ10,ϕ20asη, (13)

    where λ=gβTΔTaav,Λ1=gβC1ΔC1aav,Λ1=gβC2ΔC2aav.

    First, the stream function ψ is taken as mentioned below before applying scaling transformations.

    u=ψyandu=ψx (14)

    We introduce the stream functions (14) to (8)–(12) together with the boundary conditions of (13). Obviously, Eq (8) is satisfied by them. And the remaining equations will be converted in terms of the stream function ψ as below period:

    ψx2ψxyψx2ψy2=3ψy3σB2ρaψyλθ+Λ1ϕ1+Λ2ϕ2, (15)
    ψyθxψxψy=αv2θy2, (16)
    ψyϕ1xψxϕ1y=DS1v2ϕ1y2, (17)
    ψyϕ2xψxϕ2y=DS2v2ϕ2y2, (18)

    with the following boundary conditions:

    ψy=x+Lav2ψy2,ψx=0,θ=1+D1avθy,ϕ1=1,ϕ2=1atη=0ψy0,θ0,ϕ10,ϕ20asη, (19)
    Also,eε(r2r3)ψy=1,eε(r1r3)=0,eεr4θ=0 (20)

    Consider ε as a small parameter of the scaling transformation. Then, the transformation F (a specified set of Lie group analysis) is taken as mentioned below period:

    F:x=xeεr1,y=yeεr2,ψ=ψeεr3θ=θeεr4,ϕ1=ϕ1eεr5,ϕ2=ϕ2eεr6, (21)

    Where, r1,r2,r3,r4,r5andr6 are any real arbitrary constant parameters The point conversion defined through (21) transmuted the co-ordinates (x,y,ψ,ϕ1,ϕ2) into (x,y,ψ,ϕ1,ϕ2). With the help of Lie group analysis mentioned through (15), Eqs (15)–(18) are transformed as

    eε(r1+r2r3r5)[ψy2ψxyψx2ψy2]=eε(3r2r3)3ψy3eε(r2r3)σB2ρaψyλeεr4θ (22)
    eε(r1+r2r3r5)[ψy2θxyψxθy]=aveε(2r2r4)2θy2 (23)
    eε(r1+r2r3r5)[ψyϕ1xψxϕ1y]=DS1veε(2r2r5)2ϕ1y2 (24)
    eε(r1+r2r3r6)[ψyϕ2xψxϕ2y]=DS2veε(2r2r6)2ϕ2y2. (25)

    If the exponent of the above converted equations fulfills the below linear equations, then the set of Eqs (22)–(25) will remain invariant under the folowing transformation

    r1=2r22r3=3r2r3=r2r3=r4=r5=r6, (26)
    r1+r2r3r4=2r2r4, (27)
    r1+r2r3r5=2r2r5, (28)
    r1+r2r3r6=2r2r6 (29)

    By solving the above linear equations (26)–(29) simultaneously, we find

    r1=r1,r2=0,r3=r1,r4=0,r5=0,r6=0. (30)

    Replacing the above values of (30) into the scaling transformations given in (21), we get

    F:x=xeεr1,y=y,ψ=ψeεr1,θ=θ,ϕ1=ϕ1,ϕ2=ϕ2. (31)

    The Taylor series expansions are

    xx=xεr1,yy=0,ψ=ψεr,θθ=0,ϕ1ϕ1=0,ϕ2ϕ2=0.

    A simple algebraic expression for the above transformations given by (31) with the help of Taylor series expansion leads to a mono-parametric group of transformations in the form of the characteristic equation given below period

    dxdr1=dy0=dψψr1=dθ0=dϕ10=dϕ20. (32)

    From (32), we can easily obtain new similarity transformations as

    y=η,ψ=xf(η),θ=θ(η),ϕ1=ϕ1(η),ϕ2=ϕ2(η), (33)

    where, η is the similarity variable and f,θ,ϕ1,ϕ2 are the dependent variables. Now, we substitute the above quantities specified in (33) into PDEs (16) to (18) then, by applying the boundary conditions mentioned in (19), we attain the set of ordinary differential equations as

    f+fff2+λθ+Λ1ϕ1+Λ2ϕ2=0, (34)
    θ+Prθ=0, (35)
    ϕ1+Le1fϕ1=0, (36)
    ϕ2+Le2fϕ2=0. (37)

    Together with the boundary situations;

    f=0,f=1+α1f,θ=1+α2θ,ϕ1=1,ϕ2=1atη=0f0,θ0,ϕ10,ϕ20asη (38)

    Here, α1=Lav is the momentum slip parameter and α2=D1av is the thermal slip parameter.

    with the following predefined parameters:

    M=σB2ρa,λ=gβTΔTaav,Λ1=gβC1ΔC1aav,Λ2=gβC2ΔC2aav,Pr=vα,Le1=vDS1,Le2=vDS2.

    The physical measures requiring engineering attention are the local friction factor; local Nusselt number and Sherwood number which are defined as follows:

    Cf=τwρ(ax)2,Nux=xqwk(TwT),Nux=xqwk(TwT),Shx1=xhmDsm(C1wC1),Shx2=xhmDsm(C2wC2),

    where, τw,qw,h1m&h2m symbolize the shear stress, heat and mass flux change, respectively:

    τw=μ(uy),qw=k(Ty),h1m=Dsm(C1y),h2m=Dsm(C2y).

    The dimensionless friction factor, Nusselt number and Sherwood number are defined as

    CfRex1/2=f(0),NuxRex1/2=θ(0),Sh1xRex1/2=ϕ1(0),Sh2xRex1/2=ϕ2(0),

    Where, Rex=avlx.

    The collected results show the impact of non-dimensional regulating parameters such as Le1,Le2,Λ1,Λ2,α1,α2 on and f(η),θ(η),ϕ1(η),ϕ2(η)(See Figures 116). In the simulations, the pertinent parameter values were Pr=0.72,λ=0.5,Le1=1,Le2=1,Λ1=0.5,Λ2=0.5,α1=0.2,α2=0.2. These variables were kept constant throughout the inquiry, with the exception of the various values given in the associated figures. The results are compared with already divulged results and presents excellent correlation with the Ferdows et al. [35] results.

    Figure 1.  Salt 1 concentration on Le1.
    Figure 2.  Salt 2 concentration on Le1.
    Figure 3.  Salt 2 concentration on Le2.
    Figure 4.  Salt 1 concentration on Le2.
    Figure 5.  Velocity on Λ1.
    Figure 6.  Temperature on Λ1.
    Figure 7.  Salt 1 concentartion on Λ1.
    Figure 8.  Salt 2 concentration on Λ1.
    Figure 9.  Temperature on Λ2.
    Figure 10.  Velocity on Λ2.
    Figure 11.  Salt 1 concentration on Λ2.
    Figure 12.  Salt 2 concentration on Λ2.
    Figure 13.  Velocity on α1.
    Figure 14.  Temperature on α1.
    Figure 15.  Salt 2 concentration on α1.
    Figure 16.  Temperature on α2.
    Table 1.  Corroboration of θ(0) for distinct values of Pr with M=λ=Nc1=Nc2=Le1=Le2=0.
    Pr Ferdows et al. [35] Present Results
    1 0.9547 0.9546
    2 1.4715 1.4711
    3 1.8691 1.8672

     | Show Table
    DownLoad: CSV

    The variation in salt 1 and 2 concentration distributions ϕ1 and ϕ2 as a result of varying the regular Lewis numbers Le1 and Le2 in the presence and absence of the magnetic field parameter are shown in Figures 14. It was designed to observe the impact of Lewis numbers on salt 1 and 2 concentrations. Decreases in the solutal concentration profiles ϕ1andϕ2 is occurred due to the Lewis number. Physical explanation of such decline in the variations of ϕ1andϕ2 can be justified on the fact that Le1andLe2 capture the reverse relation with species diffusion, that is when Le1andLe2 are maximum, species diffusion is lower, which leads to the decrement of the resulting solutal concentrations.

    The thermal buoyancy ratio parameter Λ1 reduces f(η),θ(η),ϕ1(η),ϕ2(η) for both the presence and absence of a magnetic field. The concentration buoyancy ratio parameter Λ2 enhances θ(η) in the presence of a magnetic field but slowly decelerates it in the absence of a magnetic field case (Figure 10). The effect of thermal the buoyancy ratio parameter Λ1 is depicted in Figure 5. From this, we observed that with the increase of the velocity and temperature, Salt 1 and 2 concentration distributions decreased because molecular forces dominated the thermal buoyancy forces. Therefore, the velocity in the momentum boundary layer depreciates in the flow region when the buoyancy forces act in the opposite direction.

    The momentum and concentration boundary layer thicknesses decreased the values of Λ2 in both cases (see Figures 9, 11 and 12).

    Figures 1315 show the influence of the momentum slip parameter α1 on the velocity, temperature and Salt 1 concentration distributions. It is clear that the velocity is a decreasing function of the slip parameter. Physically, when slip occurs, the fluid velocity near the surface is no longer equal to the surface velocity, that is, a velocity slip exists with such an increase in a slip velocity. Furthermore, increasing the value of slip will decrease the flow velocity because, under the slip condition, the pulling of the surface can be only partly transmitted to the fluid. The same phenomena can be observed in the temperature and Salt 1 concentration fields. Figure 16 demonstrates the effect of the thermal slip parameter α2 on temperature. As the thermal slip parameter increases, less heat is transformed from the surface to the fluid and consequently the temperature decreases.

    Figure 17 represents the surface plot of the momentum slip parameter α1 given the skin friction coefficient f(0), Nusselt number θ(0) and Sherwood number ϕ(0) in the absence of the magnetic field parameter M=0 and presence of the magnetic field parameter M=1. Figure 17 shows that the rate of friction factor is −4.256939 in the absence of a magnetic field and −1.454855 in the presence a of magnetic field case. From this we observed that the friction factor coefficient continuously decreases. The opposite phenomena can be observed in the cases of the Nusselt and Sherwood numbers for both the M=0 and M=1 cases (Figures 1820). Figure 21 represents the thermal slip parameter α2 on f(0),θ(0),ϕ(0) for both absence and presence of magnetic field parameter cases. Figures 21 and 22 show that α2 elevates the rate of heat transfer but decelerates the skin friction coefficient for both cases.

    Figure 17.  Surface plot of skin friction coefficient on α1.
    Figure 18.  Surface plot of Nusselt number on α1.
    Figure 19.  Surface plot of Salt 1 Sherwood number on α1.
    Figure 20.  Surface plot of Salt 2 Sherwood number on α1.
    Figure 21.  Surface plot of Nusselt number on α1.
    Figure 22.  Surface plot of Skin friction on α2.

    The concentration buoyancy ratio parameter Λ2 escalates the Salt 1 Sherwood number (Figure 23) and thermal buoyancy ratio parameter Λ1 also enhances the friction factor coefficient (Figure 24) for the M=0andM=1 cases. Figure 25 shows that the Lewis number Le1 reduces the Nusselt number in the M=0 case and increases the Nusselt number in the case of M=1 the same phenomena can be observed in Figure 27 Salt 2 Sherwood number. But the skin friction coefficient increases for both cases of magnetic field parameter settings, as shown in Figure 26. Finally, from Figures 28 and 31 we observed that Le2 reduces the skin friction coefficient but upsurges the Salt 2 Sherwood number; meanwhile Le2 in the absence of a magnetic field and increase in the presence of a magnetic field for the Nusselt number Salt 1 concentration, as shown in Figures 29 and 30.

    Figure 23.  Surface plot of Salt 1 Sherwood number on Λ2.
    Figure 24.  Surface plot of skin friction coefficient on Λ1.
    Figure 25.  Surface plot of Nusselt number on Le1.
    Figure 26.  Surface plot of Salt 1 Sherwood number on Le1.
    Figure 27.  Surface plot of Salt 2 Sherwood number on Le1.
    Figure 28.  Surface plot of skin friction coefficient on Le2.
    Figure 29.  Surface plot of Nusselt number on Le2.
    Figure 30.  Surface plot of Salt 1 Sherwood number on Le2.
    Figure 31.  Surface plot of Salt 2 Sherwood number on Le2.

    A theoretical study has been conducted for laminar incompressible triple diffusive boundary layer flow in the presence and absence of a hydromagnetic fluid. Momentum and thermal slip effects have been incorporated into model. The transformed boundary layer equations for heat and momentum conservation have been solved by using Lie group transformation analysis. The present investigation has shown the following:

    1. The momentum slip parameter α1 improve the Nusselt number and Salt 1 and 2 Sherwood number in the presence and absence of a magnetic field.

    2. The thermal slip parameter increases, less heat is transformed from the surface to the fluid and consequently the temperature decreases.

    3. The momentum slip parameter reduces the skin friction coefficient for M=0, but increases in the case of M=1.

    4. The Lewis number Le1 enhances the Salt 1 Sherwood number for M=0andM=1. The opposite behavior can be observed for the Salt 2 Sherwood number.

    5. The thermal slip parameter α2 enhances the Nusselt number in both the presence and absence of the magnetic field parameter.

    6. The thermal and concentration buoyancy ratio parameters are upsurge the friction factor, Nusselt number and Salts 1 and 2 Sherwood numbers in both cases of magnetic field the parameter M=0andM=1.

    7. With the increase of the velocity and temperature, Salt 1 and 2 concentration distributions decreased because molecular forces dominate the thermal buoyancy forces.

    The authors declare that they have no competing interests.



    [1] S. Lie, Sophus 1884 Differential Invariants Paper (Translation by M. Acherman, Comments by R. Hermann), Math. Sci. Press, Brookline, Mass., 1976.
    [2] L. V. Ovsiannikov, Group analysis of differential equations, Academic Press, New York, 1982. https://doi.org/10.1016/B978-0-12-531680-4.50012-5
    [3] M. M. Bhatti, S. Jun, C. M. Khalique, A. Shahid, L. Fasheng, M. S. Mohamed, Lie group analysis and robust computational approach to examine mass transport process using Jeffrey fluid model, Appl. Math. Comput., 421 (2022), 126936. https://doi.org/10.1016/j.amc.2022.126936 doi: 10.1016/j.amc.2022.126936
    [4] H. sümer, Y. aksoy, Similarity Solutions of a non-Newtonian Fluid's Momentum and Thermal Boundary Layers: Cross Fluid Model, Afyon Kocatepe Üniversitesi Fen Ve Mühendislik Bilimleri Dergisi, 22 (2022), 222–239. https://doi:10.35414/akufemubid.1028006
    [5] N. A. Shah, A. Wakif, E. R. El-Zahar, S. Ahmad, S. J Yook, Numerical simulation of a thermally enhanced EMHD flow of a heterogeneous micropolar mixture comprising (60%)-ethylene glycol (EG), (40%)-water (W), and copper oxide nanomaterials (CuO), Case Stud. Therm. Eng., 35 (2022), 102046. https://doi.org/10.1016/j.csite.2022.102046 doi: 10.1016/j.csite.2022.102046
    [6] K. U. Rehman, W. Shatanawi, K. Abodayeh, T. A. M. Shatnawi, A group theoretic analysis of mutual interactions of heat and mass transfer in a thermally slip Semi-Infinite domain, Appl. Sci., 12 (2022). https://doi.org/10.3390/app12042000 doi: 10.3390/app12042000
    [7] V. Nagendramma, P. Durgaprasad, N. Sivakumar, B. M. Rao, C. S. Raju, N. A. Shah, et al., Dynamics of triple diffusive free convective MHD fluid flow: Lie group transformation, Mathematics, 10 (2022), 2456. https://doi.org/10.3390/math10142456 doi: 10.3390/math10142456
    [8] M. J. Babu, Y. S. Rao, A. S. Kumar, C. S. K. Raju, S. A. Shehzad, T. Ambreen, et al., Squeezed flow of polyethylene glycol and water based hybrid nanofluid over a magnetized sensor surface: A statistical approach, Int. Commun. Heat Mass Transf., 135 (2022), 106136. https://doi.org/10.1016/j.icheatmasstransfer.2022.106136. doi: 10.1016/j.icheatmasstransfer.2022.106136
    [9] C. S. K. Raju, N. A. Ahammad, K. Sajjan, N. A. Shah, S. J. Yook, M. D. Kumar, Nonlinear movements of axisymmetric ternary hybrid nanofluids in a thermally radiated expanding or contracting permeable Darcy Walls with different shapes and densities: Simple linear regression, Int. Comm. Heat Mass, 135 (2022), 106110. https://doi.org/10.1016/j.icheatmasstransfer.2022.106110 doi: 10.1016/j.icheatmasstransfer.2022.106110
    [10] P. Rana, M. J. Uddin, Y. Gupta, A. I. M. Ismail, Two-component modeling for non-Newtonian nanofluid slip flow and heat transfer over sheet: Lie group approach, Appl. Math. Mech., 37 (2016), 1325–1340. https://doi.org/10.1007/s10483-016-2140-9 doi: 10.1007/s10483-016-2140-9
    [11] C. H. Amanulla, N. Nagendra, M. S. N. Reddy, Numerical study of thermal and momentum slip effects on MHD Williamson nanofluid from an isothermal sphere, J. Nanofluids, 6 (2017), 1111–1126. https://doi.org/10.1166/jon.2017.1405 doi: 10.1166/jon.2017.1405
    [12] X. Zhang, Y. Yang, T. Li, Y. Zhang, H. Wang, H. Fujita, CMC: A consensus multi-view clustering model for predicting Alzheimer's disease progression, Comput. Meth. Prog. Bio., 199 (2021), 105895. https://doi.org/10.1016/j.cmpb.2020.105895 doi: 10.1016/j.cmpb.2020.105895
    [13] S. Batool, G. Rasool, N. Alshammari, I. Khan, H. Kaneez, N. Hamadneh, Numerical analysis of heat and mass transfer in micropolar nanofluids flow through lid driven cavity: Finite volume approach, Case Stud. Therm. Eng., 37 (2022), 102233. https://doi.org/10.1016/j.csite.2022.102233 doi: 10.1016/j.csite.2022.102233
    [14] A. Maneengam, H. Laidoudi, A. Abderrahmane, G. Rasool, K. Guedri, W. Weera, et al., Entropy generation in 2D Lid-Driven porous container with the presence of obstacles of different shapes and under the influences of Buoyancy and Lorentz Forces, Nanomaterials, 12 (2022), 2206. https://doi.org/10.3390/nano12132206 doi: 10.3390/nano12132206
    [15] M. S. Bhutta, T. Xuebang, S. Akram, C. Yidong, X. Ren, M. Fasehullah, et al., Development of novel hybrid 2D-3D graphene oxide diamond micro composite polyimide films to ameliorate electrical & thermal conduction, J. Ind. Eng. Chem., 114 (2022), 108–114. https://doi.org/10.1016/j.jiec.2022.06.036 doi: 10.1016/j.jiec.2022.06.036
    [16] G. Rasool, N. A. Shah, E. R. El-Zahar, A. Wakif, Numerical investigation of EMHD nanofluid flows over a convectively heated riga pattern positioned horizontally in a Darcy-Forchheimer porous medium: Application of passive control strategy and generalized transfer laws, Waves and Random Complex Media, 2022. https://doi.org/10.1080/17455030.2022.2074571. doi: 10.1080/17455030.2022.2074571
    [17] G. Rasool, A. M. Saeed, I. L. Animasaun, A. Abderrahmane, K. Guedri, et al., Darcy-Forchheimer flow of water conveying multi-walled carbon nanoparticles through a vertical Cleveland Z-Staggered Cavity Subject to entropy generation, Micromachines, 13 (2022), 744. https://doi.org/10.3390/mi13050744 doi: 10.3390/mi13050744
    [18] U. Arif, M. A. Memon, R. S. Saif, A. S. EI-Shafay, M. Nawaz, T. Muhammed, Triple diffusion with heat transfer under different effects on magnetized hyperbolic tangent nanofluid flow, J. P. Mech. Eng., 3 (2022), https://doi.org/10.1177/09544089221079139. doi: 10.1177/09544089221079139
    [19] P. M. Patil, S. Benawadi, B. Shanker, Influence of mixed convection nanofluid flow over a rotating sphere in the presence of diffusion of liquid hydrogen and ammonia, Math. Comp. Simulat., 194 (2022), 764–781. https://doi.org/10.10.1016/j.matcom.2021.12.022 doi: 10.10.1016/j.matcom.2021.12.022
    [20] M. Nawaz, M. Awais, Triple diffusion of species in fluid regime using tangent hyperbolic rheology, J. Therm. Anal. Calorim., 146 (2021), 775–785, https://doi.org/10.1007/s10973-020-10026-0. doi: 10.1007/s10973-020-10026-0
    [21] A. Manjappa, G. B. Jayanna, P. B. Chandrappa, Triple diffusive flow of Casson nanofluid with buoyancy forces and nonlinear thermal radiation over a horizontal plate, Heat Transfer, 47 (2018), 957–973. https://doi.org/10.1002/htj.21360 doi: 10.1002/htj.21360
    [22] P. M. Patil, A. Shashikant, E. Momoniat, C. Harley, Numerical simulation of unsteady triple diffusive mixed convection in NaCl-water and Sucrose-water solutions, Int. J. Heat Mass Transf., 126 (2018), 147–155. https://doi.org/10.1016/j.ijheatmasstransfer.2018.05.166 doi: 10.1016/j.ijheatmasstransfer.2018.05.166
    [23] P. M. Patil, A. Shashikant, P. S. Hiremath, Influence of liquid hydrogen and nitrogen on MHD triple diffusive mixed convection nanoliquid flow in presence of surface roughness, Int. J. Hydrog. Energ., 43 (2018), 20101–20117. https://doi.org/10.1016/j.ijhydene.2018.09.033 doi: 10.1016/j.ijhydene.2018.09.033
    [24] P. Y. Xiong, M. Nazeer, F. Hussain, M. I. Khan, A. Saleem, S. Qayyum, et al., Two-phase flow of couple stress fluid thermally effected slip boundary conditions: Numerical analysis with variable liquids properties, Alex. Eng. J., 61 (2022), 3821–3830. https://doi.org/10.1016/j.aej.2021.09.012. doi: 10.1016/j.aej.2021.09.012
    [25] O. A. Bég, T. Bég, W. A. Khan, M. J. Uddin, Multiple slip effects on nanofluid dissipative flow in a converging/diverging channel: A numerical study, Heat Transfer, 51 (2022), 1040–1061. https://doi.org/10.1002/htj.22341. doi: 10.1002/htj.22341
    [26] L. Su, B. He, G. Wang, R. Xiao, W. Yu, Simultaneously developing flow and heat transfer in circular and parallel-plates microchannels with velocity slip and temperature jump, International J. Therm. Sci., 177 (2022), 107590. https://doi.org/10.1016/j.ijthermalsci.2022.107590 doi: 10.1016/j.ijthermalsci.2022.107590
    [27] K. N. Sneha, U. S. Mahabaleshwar, Y. Sheikhnejad, Heat and Mass Transfer of Walters' Liquid B Flow Over A Porous Stretching/Shrinking Plate with Mass Transpiration and Slip, Transport in Porous Media, (2022). https://doi.org/10.1007/s11242-022-01758-8 doi: 10.1007/s11242-022-01758-8
    [28] A. Sabu, A. Wakif, S. Areekara, A. Mathew, N. A. Shah, Significance of nanoparticles' shape and thermo-hydrodynamic slip constraints on mhd alumina-water nanoliquid flows over a rotating heated disk: The passive control approach, Int. Commun. Heat Mass Transf., 129 (2021), 105711. https://doi.org/10.1016/j.icheatmasstransfer.2021.105711 doi: 10.1016/j.icheatmasstransfer.2021.105711
    [29] O. K. Koriko, K. S. Adegbie, N. A. Shah, I. L. Animasaun, M. A. Olotu, Numerical solutions of the partial differential equations for investigating the significance of partial slip due to lateral velocity and viscous dissipation: The case of blood-gold Carreau nanofluid and dusty fluid, Numer. Meth. Part. D. E., (2021), 1–29. https://doi.org/10.1002/num.22754 doi: 10.1002/num.22754
    [30] E. Seid, E. Hailen, T. Walelign, Multiple slip, Soret and Dufour effects in fluid flow near a vertical stretching sheet in the presence of magnetic nanoparticles, Int. J. Therm., 13 (2022), 100136. https://doi.org/10.1016/j.ijft.2022.100136 doi: 10.1016/j.ijft.2022.100136
    [31] M. Turkyilmazoglu, Velocity Slip and Entropy Generation Phenomena in Thermal Transport Through Metallic Porous Channel, J. Non-Equil. Thermody., 45 (2020). https://doi.org/10.1515/jnet-2019-0097 doi: 10.1515/jnet-2019-0097
    [32] F. L. Paiva, A. R. Secchi, V. Calado, J. Maia, S. Khani, Slip and momentum transfer mechanisms mediated by Janus rods at polymer interfaces, Soft Matter, 16 (2020), 6662–6672. https://doi.org/10.1039/D0SM00858C doi: 10.1039/D0SM00858C
    [33] A. Majeed, F. M. Noori, A. Zeeshan, T. Mahmood, S. U. Rehman, I. Khan, Analysis of activation energy in magnetohydrodynamic flow with chemical reaction and second order momentum slip model, Case Stud. Therm. Eng., 12 (2018), 765–773. https://doi.org/10.1016/j.csite.2018.10.007 doi: 10.1016/j.csite.2018.10.007
    [34] A. Majeed, A. Zeeshan, F. M. Noori, Numerical study of Darcy-Forchheimer model with activation energy subject to chemically reactive species and momentum slip of order two, AIP Adv., 9 (2019), 045035. https://doi.org/10.1063/1.5095546 doi: 10.1063/1.5095546
    [35] M. Ferdows, M. J. Uddin, A. A. Afify, Scaling group transformation for MHD boundary layer free convective heat and mass transfer flow past a convectively heated nonlinear radiating stretching sheet, Int. J. Heat Mass Transf., 56 (2013), 181–187.
  • Reader Comments
  • © 2023 the Author(s), licensee AIMS Press. This is an open access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0)
通讯作者: 陈斌, bchen63@163.com
  • 1.

    沈阳化工大学材料科学与工程学院 沈阳 110142

  1. 本站搜索
  2. 百度学术搜索
  3. 万方数据库搜索
  4. CNKI搜索

Metrics

Article views(1583) PDF downloads(76) Cited by(0)

Figures and Tables

Figures(31)  /  Tables(1)

/

DownLoad:  Full-Size Img  PowerPoint
Return
Return

Catalog
