Time-Resolved 3D cardiopulmonary MRI reconstruction using spatial transformer network

1.
Division of Pediatric Cardiology, Department of Pediatrics, The University of Texas Southwestern Medical Center, Dallas, TX, USA
2.
Department of Radiology, The University of Texas Southwestern Medical Center, Dallas, TX, USA
3.
Advanced Imaging Research Center, The University of Texas Southwestern Medical Center, Dallas, TX, USA
4.
Department of Biomedical Engineering, University of Wisconsin, Madison, WI, USA
5.
Department of Medical Physics, University of Wisconsin School of Medicine and Public Health, Madison, WI, USA
6.
Department of Radiology, University of Wisconsin School of Medicine and Public Health, Madison, WI, USA

Academic Editor: Shangce Gao

Received: 15 June 2023 Revised: 25 July 2023 Accepted: 27 July 2023 Published: 04 August 2023

The accurate visualization and assessment of the complex cardiac and pulmonary structures in 3D is critical for the diagnosis and treatment of cardiovascular and respiratory disorders. Conventional 3D cardiac magnetic resonance imaging (MRI) techniques suffer from long acquisition times, motion artifacts, and limited spatiotemporal resolution. This study proposes a novel time-resolved 3D cardiopulmonary MRI reconstruction method based on spatial transformer networks (STNs) to reconstruct the 3D cardiopulmonary MRI acquired using 3D center-out radial ultra-short echo time (UTE) sequences. The proposed reconstruction method employed an STN-based deep learning framework, which used a combination of data-processing, grid generator, and sampler. The reconstructed 3D images were compared against the start-of-the-art time-resolved reconstruction method. The results showed that the proposed time-resolved 3D cardiopulmonary MRI reconstruction using STNs offers a robust and efficient approach to obtain high-quality images. This method effectively overcomes the limitations of conventional 3D cardiac MRI techniques and has the potential to improve the diagnosis and treatment planning of cardiopulmonary disorders.
- cardiopulmonary MRI,
- spatial transformer network,
- 3D UTE sequence
Citation: Qing Zou, Zachary Miller, Sanja Dzelebdzic, Maher Abadeer, Kevin M. Johnson, Tarique Hussain. Time-Resolved 3D cardiopulmonary MRI reconstruction using spatial transformer network[J]. Mathematical Biosciences and Engineering, 2023, 20(9): 15982-15998. doi: 10.3934/mbe.2023712

Related Papers:

Abstract

The accurate visualization and assessment of the complex cardiac and pulmonary structures in 3D is critical for the diagnosis and treatment of cardiovascular and respiratory disorders. Conventional 3D cardiac magnetic resonance imaging (MRI) techniques suffer from long acquisition times, motion artifacts, and limited spatiotemporal resolution. This study proposes a novel time-resolved 3D cardiopulmonary MRI reconstruction method based on spatial transformer networks (STNs) to reconstruct the 3D cardiopulmonary MRI acquired using 3D center-out radial ultra-short echo time (UTE) sequences. The proposed reconstruction method employed an STN-based deep learning framework, which used a combination of data-processing, grid generator, and sampler. The reconstructed 3D images were compared against the start-of-the-art time-resolved reconstruction method. The results showed that the proposed time-resolved 3D cardiopulmonary MRI reconstruction using STNs offers a robust and efficient approach to obtain high-quality images. This method effectively overcomes the limitations of conventional 3D cardiac MRI techniques and has the potential to improve the diagnosis and treatment planning of cardiopulmonary disorders.
