Events or attributes occur at different ages or times but, in some circumstances, for effective planning and policy formulation, the peak point, where the events or attributes has its peak value, is of interest. Usually, the graphs depicting peak values are not symmetrical. In determining the peak point(s) of events that occur over time, a set of αs of α-levels, chosen from an antisymmetric interval (0,1], was used on an ATD matrix. This was done to obtain an RTD matrix which was then aggregated to obtain a CETD matrix. Most authors chose α without any condition. The problem associated with this was that two different sets of α may not necessarily produce the same peak point for the same data set. In this study, the condition to guarantee that the row which had the highest sum (the peak value) in a CETD matrix was invariant, regardless of the set of α-levels, was established. To establish the authenticity of this method, there were experiments conducted and numerical examples were given in this paper.
Citation: Hanyin Zhang, Babatunde Oluwaseun Onasanya, Aishat Omobolanle Ilesanmi, Yuming Feng, Dongfang Yan. The invariance of the peak point(s) in a non-symmetrical graph via CETD matrix under varying α-levels[J]. AIMS Mathematics, 2024, 9(10): 29587-29607. doi: 10.3934/math.20241433
[1] | Wentao Le, Yucai Ding, Wenqing Wu, Hui Liu . New stability criteria for semi-Markov jump linear systems with time-varying delays. AIMS Mathematics, 2021, 6(5): 4447-4462. doi: 10.3934/math.2021263 |
[2] | Xingyue Liu, Kaibo Shi . Further results on stability analysis of time-varying delay systems via novel integral inequalities and improved Lyapunov-Krasovskii functionals. AIMS Mathematics, 2022, 7(2): 1873-1895. doi: 10.3934/math.2022108 |
[3] | Jenjira Thipcha, Presarin Tangsiridamrong, Thongchai Botmart, Boonyachat Meesuptong, M. Syed Ali, Pantiwa Srisilp, Kanit Mukdasai . Robust stability and passivity analysis for discrete-time neural networks with mixed time-varying delays via a new summation inequality. AIMS Mathematics, 2023, 8(2): 4973-5006. doi: 10.3934/math.2023249 |
[4] | Patarawadee Prasertsang, Thongchai Botmart . Improvement of finite-time stability for delayed neural networks via a new Lyapunov-Krasovskii functional. AIMS Mathematics, 2021, 6(1): 998-1023. doi: 10.3934/math.2021060 |
[5] | Zhifeng Lu, Fei Wang, Yujuan Tian, Yaping Li . Lag synchronization of complex-valued interval neural networks via distributed delayed impulsive control. AIMS Mathematics, 2023, 8(3): 5502-5521. doi: 10.3934/math.2023277 |
[6] | Junfeng Zhang, Renjie Fu, Yuanyuan Wu, Bhatti Uzair Aslam . Practical consensus of time-varying fuzzy positive multi-agent systems. AIMS Mathematics, 2024, 9(11): 31119-31141. doi: 10.3934/math.20241500 |
[7] | Imrana Kousar, Saima Nazeer, Abid Mahboob, Sana Shahid, Yu-Pei Lv . Numerous graph energies of regular subdivision graph and complete graph. AIMS Mathematics, 2021, 6(8): 8466-8476. doi: 10.3934/math.2021491 |
[8] | Yude Ji, Xitong Ma, Luyao Wang, Yanqing Xing . Novel stability criterion for linear system with two additive time-varying delays using general integral inequalities. AIMS Mathematics, 2021, 6(8): 8667-8680. doi: 10.3934/math.2021504 |
[9] | Hyung Tae Choi, Jung Hoon Kim . An L∞ performance control for time-delay systems with time-varying delays: delay-independent approach via ellipsoidal D-invariance. AIMS Mathematics, 2024, 9(11): 30384-30405. doi: 10.3934/math.20241466 |
[10] | Yakufu Kasimu, Gulijiamali Maimaitiaili . Non-fragile H∞ filter design for uncertain neutral Markovian jump systems with time-varying delays. AIMS Mathematics, 2024, 9(6): 15559-15583. doi: 10.3934/math.2024752 |
Events or attributes occur at different ages or times but, in some circumstances, for effective planning and policy formulation, the peak point, where the events or attributes has its peak value, is of interest. Usually, the graphs depicting peak values are not symmetrical. In determining the peak point(s) of events that occur over time, a set of αs of α-levels, chosen from an antisymmetric interval (0,1], was used on an ATD matrix. This was done to obtain an RTD matrix which was then aggregated to obtain a CETD matrix. Most authors chose α without any condition. The problem associated with this was that two different sets of α may not necessarily produce the same peak point for the same data set. In this study, the condition to guarantee that the row which had the highest sum (the peak value) in a CETD matrix was invariant, regardless of the set of α-levels, was established. To establish the authenticity of this method, there were experiments conducted and numerical examples were given in this paper.
The first introduction of the word matrix into the mathematics literature was by James Joseph Sylvester, but Cayley was the first author of an expository article on the subject [1]. Since then, a lot has been done on the study and use of matrices. It is also important to note that the notion of the fuzzy set was introduced by Zadeh [2]. Thomason [3] was the first to introduce fuzziness into matrix theory. Since then, there have been diverse uses of fuzzy matrices (Ref. [3,4,5,6,7]). However, in this study, average time-dependent (ATD), revised time-dependent (RTD), and combined effect time-dependent (CETD) matrices will be used to determine the peak age at which some attributes occur, and it can even be extended to analyzing transportation problems such as the peak time (peak point) of traffic and some other problems where peak is of interest. While we provide some basic information, readers can please refer to [8,9,10] for more information on ATD, RTD, and CETD matrices.
When an attribute (of multi-dimension) is observed over a period of time and the various frequencies of occurrences of each dimension are recorded, these observations are grouped into intervals of times according to the researcher's interest. The matrix (or table) obtained by this procedure is called the raw data (RD) matrix. The RD matrix is then transformed into an ATD matrix upon dividing each entry in its row by the corresponding number of years in the time interval. An ATD matrix is a special matrix which represents data that is uniform. In each column of the ATD matrix, the respective mean and standard deviation of the data is found and is used to transform the ATD matrix into special fuzzy matrices (RTD matrices) at different α-levels, using the formula
eij={−1,ifaij≤μj−αδj,0,ifaij∈(μj−αδj,μj+αδj),1,ifaij≥μj+αδj, | (1.1) |
where μj is the mean of the entries in j-th column of the ATD matrix and δj is their standard deviation. The aggregation of RTD matrices at different α-levels produces a CETD matrix.
The CETD matrix is used, most times, to determine the peak value of the occurrence of events or attributes over time. Many researchers have used these fuzzy matrices in the field of health, sociology, and transportation, to mention just a few. In particular, [11,12,13] used the CETD matrix approach to analyze the personality of individuals. Also, it was used in [14] to determine the maximum age group affected by cardiovascular disease in some men. In [15], the CETD matrix was used to determine the maximum age at which the problem of housemaid occurs. It has been used in [16] to study the peak age when issues of divorce come up, and it was used in [17] to study the peak age when self-actualization occurs. The CETD matrix has also been used to study traffic flow [18]. The CETD matrix is used in a number of ways to analyze health related issues [19,20,21,22] and it was also used to analyze the effect of computer use on the vision of women [23].
Since it is not certain for one α-level (just one RTD matrix) to give a precise result, all the authors (Ref. [14,15,16,17,18,19,20,21,22,23]) choose three to four α-levels, from an antisymmetric interval (0,1], and then aggregate the results. This means three or more values of α leads to three or more RTD matrices. The sum of all the RTD matrices form the CETD matrix. The highest row sum of the CETD matrix actually gives the required peak value. As noted above, the determination of this peak value is done with the choice of some values of α without any explanation on the criteria for the selection. No researcher, to the best of our knowledge, has ever shown if choosing and applying another set of values for α will guarantee the same peak point. It was opined that the values of the entries in the RTD matrix is determined in some undisclosed special way [10]. Most authors choose α without any condition. The problem associated with this is that two different sets of α may not necessarily produce the same peak point for the same dataset. Our research indeed shows that some conditions should be applied in the choice of α levels to preserve the point of the CETD matrix possessing the peak value. So, we have established the condition which guarantees that the peak point (the class at which peak value occurs for an attribute) obtained in a CETD matrix is invariant.
The worry that one could have whether the row with the peak point for a set of chosen values for α will be different for another set is eliminated as this paper established the condition to guarantee the invariance of peak point(s).
This section gives basic definitions and/or information needed in the sequel.
Definition 2.1. ([24]) Partition P={[x0,x1],[x1,x2],⋯,[xi−1,xi],⋯,[xn−1,xn]} of the interval [a,b] is a finite-ordered set of points in R such that a=x0<x1<x2<⋯<xi−1<xi<⋯<xn−1<xn=b.
Definition 2.2. ([24]) The length of the subinterval Ii=[xi−1,xi] of a partition
P={[x0,x1],[x1,x2],⋯,[xi−1,xi],⋯,[xn−1,xn]} |
of the interval [a,b] is δxi=xi−xi−1.
Definition 2.3. A partition is said to be uniform if all its subintervals are of the same length, that is,
xi−xi−1=α∈R,∀i∈[1,n], |
where α is a real constant.
Remark 2.4. P={[xi−1,xi]} is a collection of subintervals Ii=[xi−1,xi](i=1,2,3,⋯,n) of [a,b] which are not disjoint but a partition is supposed to be a disjoint or nonoverlapping collection. Hence, we will give another definition of partition of an interval [a,b] in Section 3.
Definition 3.1. The set P={[x0,x1],(x1,x2],(x2,x3],⋯,(xn−1,xn]}, which is a collection of finite-ordered sets of points in R (uniform subintervals of the interval I=[a,b]) such that a=x0<x1<x2<x3<⋯<xn−1<xn=b, is a partition of I.
Remark 3.2. Hence, we can look at {(xi−1,xi]}ni=1 as a uniform partition of the interval I=(x0,xn]. Also, note that the use of uniform partition ensures that αs are sufficiently far from each other so that the multiplying effects are significant and uniform on the data collected. Otherwise, it will produce a biased effect as will be seen in an example given later.
Remark 3.3. Let Is=(as,bs]⊂(0,1] be a cell in the uniform partition {(xi−1,xi]}ni=1 of (0,1], where 1≤s≤n. Then,
(ⅰ) ⋃Is=(0,1],
(ⅱ) It∩Il=∅, if t≠l, and
(ⅲ) |bs−as|=constant for all s.
Example 3.4. (ⅰ) The set {(0,0.25],(0.25,0.50],(0.50,0.75],(0.75,1]} is a uniform partition of (0,1].
(ⅱ) The set
{(0,0.125],(0.125,0.25],(0.25,0.375],(0.375,0.50],(0.50,0.625],(0.625,0.75],(0.75,0.875],(0.875,1]} |
of subsets of (0,1] is a uniform partition of it.
As noted above, all researchers who use the CETD matrix to find a peak point make choices of α in the interval (0,1] arbitrarily. We have found out that if a set of chosen α are interchanged with another set, without any condition, the peak point in the CETD matrix is not always necessarily the same as can be seen later in our example. We need to establish the condition on the choice of α which will make the peak point invariant.
Remark 3.5. Besides, as shall be required to know later in a part of this work, in a row of a matrix, if we have [1−110−1−1], the total number of 0 and/or -1 is 4 and the total number of 0 and/or 1 is 3. In this case, most entries are 0 and/or -1. On the other hand, if in a row we have [1110−1−1], the total number of 0 and/or -1 is 3 and the total number of 0 and/or 1 is 4, in which case most entries are 0 and/or 1.
Theorem 3.6. Given an ATD matrix, if α1<α2<α3<⋯<αn are applied in the increasing order to generate the RTD matrices Aαs such that αs∈(as,bs] (for 1≤s≤n) and {(xi−1,xi]}ni=1 is a uniform partition of (0,1], then some eij which were -1 and 1 become 0 and the total number of 0 and/or 1 in the row with highest sum in the newer RTD matrix is more than the total number of -1 and/or 0.
Proof. For α1<α2<α3<⋯<αn, (μj−α1δj,μj+α1δj)⊂(μj−α2δj,μj+α2δj)⊂(μj−α3δj,μj+α3δj)⊂⋯⊂(μj−αnδj,μj+αnδj). This implies that, for aij∈(μj−α1δj,μj+α1δj), eij=0 for α1 RTD matrix and also for other RTD matrices obtained by other αs since aij∈(μj−αsδj,μj+αsδj). Furthermore, for some aij∉(μj−α1δj,μj+α1δj), we now have such aij∈(μj−α2δj,μj+α2δj)⊂(μj−α3δj,μj+α3δj)⊂⋯⊂(μj−αnδj,μj+αnδj) and their corresponding eij which were, respectively, 1 and -1 in RTD matrix Aα1 becoming 0 in RTD matrix Aα2,Aα3,Aα4,⋯,Aαn, so that the total number of 0 and 1 in RTD matrix Aαt, for 2≤t≤n, have now increased and the total number of 0 and -1 have rather decreased for αt.
Remark 3.7. As the practice has commonly been with many authors, choosing most α from a cell of the partition is not appropriate to guarantee the invariance of peak point. For an instance, author choosing α=0.06,0.1,0.25,0.75 in a partition {(0,0.25],(0.25,0.5],(0.5,0.75],(0.75,1]} is not appropriate.
Theorem 3.8. The shape of the graph (not usually symmetrical) and the peak value of the CETD matrix is NOT INVARIANT if most αs are chosen from a cell (as,bs] of the uniform partition {(xi−1,xi]}ni=0 of (0,1].
Proof. Let {(as,bs]} be a partition of (0,1] and {αs}ns=1 be the α-levels chosen to generate the RTD matrices Aαs=(esij), where 1≤i≤m and 1≤j≤w. Assume that most αs are chosen from a particular cell (as,bs]. Let
B=n∑s=1Aαs=(n∑s=1esij)=(bij) | (3.1) |
be the CETD matrix resulting from addition of Aαs. Let k-th row have the highest sum PB in B. Then, in each Aαs matrix, it is such that
w∑j=1eskj≥w∑j=1esij⇒bkj≥bij⇒w∑j=1bkj=PB≥w∑j=1bij,i≠k. | (3.2) |
Hence, either all or most eskj∈Aαs are such that eskj≥0 and there are fewer eskj<0. In this case, in the ATD matrix, most akj are such that akj>μ−αsδ and fewer akj≤μ−αsδ. However, in the other rows when i≠k, most esij∈Aαs are such that esij=−1 and ekj≥0 are fewer; hence, in the ATD matrix, most aij are such that aij<μ−αsδ and fewer aij≥μ−αsδ.
Suppose further that {αt}nt=1 are the α-levels chosen to generate the RTD matrices Aαt=(etij), where 1≤i≤m and 1≤j≤w. Also, suppose that most of the αt are chosen from a particular (at,bt] such that (without loss of generality) at<bt<as<bs, in which case αt<αs. Then,
μ−αsδ<μ−αtδ<μ+αtδ<μ+αsδ. | (3.3) |
If the k-th row retains its peak value P¯B in the resulting CETD matrix
¯B=n∑t=1Aαt=(n∑t=1etij)=(¯bij), | (3.4) |
then it should be that most etkj∈Aαt are such that etkj≥0. Note that in the ATD matrix we could now have some akj such that μ−αs≤akj<μ−αtδ, so that some more eskj∈Aαs which were nonnegative in the RTD matrix Aαs could now become negative in the RTD Aαt. Also, all such akj such that μ+αt<μ−αsδ≤akj in RTD matrix Aαs retain the value 1 in the RTD matrix Aαt. Hence, etkj≥0 are now fewer in Aαt than in Aαs. So, we can have an ϵ≥1 such that
P¯B=w∑j=1¯bkj=w∑j=1bkj−ϵ<w∑j=1bkj=PB. | (3.5) |
This is a contradiction to the assumption that the CETD matrix ¯B retains the peak value obtained in the CETD matrix B. This inevitably distorts the shape of the graph obtained earlier.
Theorem 3.9. Given an ATD matrix, if α1<α2<α3⋯<αn are applied in the increasing order to generate the RTD matrices Aαs such that αs∈(as,bs] (for 1≤s≤n) and {(xi−1,xi]}ni=0 is a uniform partition of (0,1], then the row with the highest sum in the resulting CETD matrix retains the maximum sum for different set of αs.
Proof. Assume that an RTD matrix is obtained at level α1 and that the k-th row of the CETD matrix has the maximum sum. Since, in such an RTD matrix, any row i≠k in which eij are mostly -1 cannot have the maximum row sum, it certainly has its sum less or equal to each of the other rows in which entries are not mostly -1. Hence, there are two possible cases of the row(s) with maximum sum(s) in it:
Case 1. ekj=1 for most or all entries in row k.
Then,
akj≥μj+α1δj | (3.6) |
for most or all the entries in row k over columns j in the ATD matrix Aα1. If we choose α2 such that α1<α2, then the corresponding akj in the ATD matrix is such that either
μj+α1δj≤akj<μj+α2δj, | (3.7) |
in which case the corresponding ekj, which was 1 in the RTD matrix Aα1 is now 0 in the new RTD matrix Aα2, or
akj≥μj+α2δj, | (3.8) |
in which case the corresponding ekj which was 1 in Aα1, still remains 1 in the new RTD matrix Aα2. So, ekj is mostly 1 and 0 in the k-th row of the new RTD matrix Aα2. Note that the inequalities (3.7) and (3.8) hold for all αs leading to RTD matrices Aαs, for 2≤s≤n. Let
n∑s=1(esij)=(bij), | (3.9) |
be the component-wise sum of the entries of all the RTD matrices Aαs, where bij is the entry in the new CETD matrix obtained due to αs. Then, for bij in the CETD matrix, we have the sum
∑jbij | (3.10) |
of the i-th row in the CETD matrix. Since most entries in row k of each of the RTD matrices are mostly 0 and 1, by Theorems 3.6 and 3.8,
∑jbkj≥∑jbij,∀i≠k, | (3.11) |
in which case row k has the maximum sum in the CETD matrix.
Case 2. When most ekj are 0 and 1.
For ekj=0,
akj∈(μj−α1δj,μj+α1δj)⊂(μj−α2δj,μj+α2δj) |
so that corresponding ekj=0 remains the same in the new RTD matrix.
On the other hand, for ekj=1, either
μj+α1δj≤akj<μj+α2δj, | (3.12) |
in which case the corresponding ekj in the new RTD matrix becomes 0, or
akj≥μj+α2δj>μj+α1δj, | (3.13) |
in which case the corresponding ekj in the new RTD matrix becomes 1 so that ekj is mostly 0 and 1 in the k-th row of the ATD matrices. Also, note that the inequalities (3.12) and (3.13) hold for all αs leading to RTD matrices Aαs, for 2≤s≤n. Hence, by Theorems 3.6 and 3.8,
∑jbkj≥∑jbij,∀i≠k. | (3.14) |
Thus, row k has the maximum sum in the CETD matrix.
● Uniformly partition the interval (0,1] into n cells {(xi−1,xi]}ni=1 for n≥3;
● Choose equal number of αi from each cell (xi−1,xi] to have the set {αi}ni=1;
● Compute the RTD matrix with the {αi}ni=1;
● Find the CETD matrix as the sum of all the RTD matrices resulting from {αi}ni=1.
Example 5.1. In this example, three of the four α-levels are chosen close to each other in cell of the uniform partition {(0,0.25],(0.25,0.5],(0.5,0.75],(0.75,1]} to show that this produces a biased effect. Different crimes are represented on the tables with Ci,i=1,2,3,4,5,6. Stealing = C1, Assault = C2, Affray = C3, Abduction = C4, Burglary = C5, and Cheating = C6.
From Tables 1 and 2, we can obtain the RTD matrices for the set of αs as 0.06,0.1,0.25, and 0.75.
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 21 | 31 | 5 | 5 | 5 | 8 |
1997-2002 | 32 | 29 | 20 | 8 | 8 | 9 |
2003-2008 | 45 | 28 | 15 | 10 | 8 | 10 |
2009-2015 | 46 | 30 | 10 | 12 | 11 | 11 |
2015-2020 | 44 | 30 | 10 | 11 | 11 | 12 |
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 7.00 | 10.33 | 1.67 | 1.67 | 1.67 | 2.67 |
1997-2002 | 5.33 | 4.83 | 3.33 | 1.33 | 1.33 | 1.5 |
2003-2008 | 7.5 | 4.67 | 2.50 | 1.67 | 1.33 | 1.67 |
2009-2015 | 7.67 | 5.00 | 1.67 | 2.00 | 1. 83 | 1.83 |
2015-2020 | 7.33 | 5.00 | 1.67 | 1.83 | 1.83 | 2.00 |
Average | 6.97 | 5.97 | 2.17 | 1.70 | 1.60 | 1.93 |
S.D | 0.95 | 2.44 | 0.74 | 0.25 | 0.25 | 0.45 |
The RTD matrix for α=0.06 is
[01−1−111−1−11−1−1−11−11−1−1−11−1−111−11−1−1111][1−4−202]. | (5.1) |
The RTD matrix for α=0.1 is
[01−1−111−1−11−1−1−11−11−1−1−11−1−111−11−1−1111][1−4−202]. | (5.2) |
The RTD matrix for α=0.25 is
[01−1011−1−11−1−1−11−110−1−11−1−11101−1−1110][2−4−111]. | (5.3) |
The RTD matrix for α=0.75 is
[010001−101−1−1−10000−10000110000010][2−3−121]. | (5.4) |
The CETD matrix is given below
[04−3−234−4−34−4−4−43−33−2−4−33−3−34423−3−3342][6−15−636]. | (5.5) |
The graph depicting the peak value of CETD matrix for α=0.06,0.1,0.25,0.75 is in Figure 1.
Remark 5.2. It should be noted that, for the set of αs as 0.06,0.1,0.25, and 0.75, the column matrix given beside each matrix is the row sum of the matrix. It should also be noted that the effect of choosing most α-levels close to each other from a cell of the partition as pointed out in Remark 3.7 is the reason why matrices (5.1) and (5.2) are the same. As a matter of fact, it is not so much different from (5.3). In what follows, we will choose two different sets of α-level (α=0.2,0.4,0.6,0.8 and α=0.25,0.45,0.75,0.9) so that αs in each set is from each cell of the partition {(0,0.25],(0.25,0.5],(0.5,0.75],(0.75,1]}.
For the set of α=0.2,0.4,0.6,0.8, the RTD matrix for α=0.2 is
[01−1011−1−11−1−1−11−110−1−11−1−111−11−1−1110][2−4−101]. | (5.6) |
The RTD matrix for α=0.4 is
[01−1001−1−11−1−1−11−110−1−110−111000−1110][1−4−121]. | (5.7) |
The RTD matrix for α=0.6 is
[01−1001−101−1−1−10000−1010−111000−1010][1−3−120]. | (5.8) |
The RTD matrix for α=0.8 is
[010001−101−1−1−10000−10000110000010][2−3−121]. | (5.9) |
The CETD matrix is given below
[04−3014−4−24−4−4−42−220−4−23−1−344−11−1−3240][6−14−463]. | (5.10) |
The graph depicting the peak value of CETD matrix for α=0.2,0.4,0.6,0.8 is in Figure 2.
However, consider α=0.25,0.45,0.75,0.9, which has a similar spread as α=0.2,0.4,0.6,0.8. The CETD matrix with the row sum for α=0.25,0.45,0.75,0.9 is given as
[04−2014−4−24−4−4−42−210−4−22−1−24401−1−2240][7−14−574]. | (5.11) |
The graph depicting the peak value of the CETD matrix for α=0.25,0.45,0.75,0.9 is given in Figure 3.
Remark 5.3. It can be seen from Figures 1 and 2 that the class having the peak values and the shapes of the graphs obtained from the row sums of the CETD matrices using different set of αs are different. However, considering another set of αs, 0.25,0.45,0.75,0.9, chosen similarly as α=0.2,0.4,0.6,0.8, respectively, from the same cell, the class (which in some cases can be age-group) with the peak value in Figure 3 is the same as the class with the peak value in Figure 2. As a matter of fact, the CETD matrix (5.5) has its peaks at row 1 and row 5, but CETD matrix (5.10) has its peaks at row 1 and row 4 (i.e., a change also occurred in peak point). However, CETD matrix (5.11) has its peaks at row 1 and row 4, and the graph (Figure 3) retains the same shape as the graph (Figure 2) of CETD matrix (5.10) because they have relatively the same spread of αs.
Example 5.4. The attribute openness of the example in [11] will be used now. We apply our method and show that the class having the peak value is invariant under our condition.
From Tables 3 and 4, we can obtain the RTD matrices for a set of αs as 0.2,0.32,0.57 and 0.8.
Age | O1 | O2 | O3 | O4 | O5 | O6 |
10-17 | 22 | 23 | 19 | 25 | 27 | 16 |
18-24 | 22 | 24 | 20 | 21 | 18 | 13 |
25-29 | 22 | 24 | 24 | 21 | 21 | 24 |
30-39 | 17 | 17 | 14 | 19 | 23 | 20 |
40-49 | 11 | 20 | 20 | 12 | 23 | 18 |
50-59 | 7 | 13 | 14 | 5 | 21 | 13 |
60-75 | 4 | 13 | 8 | 4 | 20 | 8 |
Age | O1 | O2 | O3 | O4 | O5 | O6 |
10-17 | 2.75 | 2.88 | 2.38 | 3.13 | 3.38 | 2.00 |
18-24 | 3.14 | 3.43 | 2.86 | 3.00 | 2.57 | 1.86 |
25-29 | 4.40 | 4.80 | 4.80 | 4.20 | 4.20 | 4.80 |
30-39 | 1.70 | 1.70 | 1.40 | 1.90 | 2.30 | 2.00 |
40-49 | 1.10 | 2.00 | 2.00 | 1.20 | 2.30 | 1.80 |
50-59 | 0.70 | 1.30 | 1.40 | 0.50 | 2.10 | 1.30 |
60-75 | 0.25 | 0.81 | 0.50 | 0.25 | 1.25 | 0.50 |
Average | 2.01 | 2.42 | 2.19 | 2.03 | 2.59 | 2.04 |
Standard Deviation | 1.49 | 1.38 | 1.38 | 1.48 | 0.95 | 1.33 |
The RTD matrix for α=0.2 is
[110110111100111111−1−1−10−10−1−10−1−10−1−1−1−1−1−1−1−1−1−1−1−1][446−4−4−6−6]. | (5.12) |
The RTD matrix for α=0.32 is
[1101101111001111110−1−1000−100−100−1−1−1−1−1−1−1−1−1−1−1−1][446−2−2−6−6]. | (5.13) |
The RTD matrix for α=0.57 is
[00011011010011111100−1000−100000−1−1−1−100−1−1−1−1−1−1][236−1−1−4−6]. | (5.14) |
The RTD matrix for α=0.8 is
[000010000000111111000000000000−1−10−100−1−1−1−1−1−1][10600−3−6]. | (5.15) |
The CETD matrix with the row sum is given below
[220340332300444444−1−2−30−10−3−10−2−10−4−4−3−4−2−2−4−4−4−4−4−4][111124−7−7−19−24]. | (5.16) |
The graph depicting the peak value of CETD matrix for α=0.2,0.32,0.57,0.8 is in Figure 4.
If we choose another set of αs, say, 0.25,0.45,0.68, and 0.85, the RTD matrix for α=0.25 is
[1101101111001111110−1−10−10−1−10−1−10−1−1−1−1−1−1−1−1−1−1−1−1][446−3−4−6−6]. | (5.17) |
The RTD matrix for α=0.45 is
[1001101111001111110−1−1000−100−100−1−1−1−1−1−1−1−1−1−1−1−1][346−2−2−6−6]. | (5.18) |
The RTD matrix for α=0.68 is
[000110110000111111000000000000−1−10−100−1−1−1−1−1−1][22600−3−6]. | (5.19) |
The RTD matrix for α=0.85 is
[000000000000111111000000000000−100−100−1−1−1−1−1−1][00600−2−6]. | (5.20) |
The CETD matrix with the row sum is given below
[2103303322004444440−2−20−10−2−10−2−10−4−3−2−4−2−2−4−4−4−4−4−4][91024−5−6−17−24]. | (5.21) |
The graph depicting the peak value of CETD matrix for α=0.25,0.45,0.68,0.85 is in Figure 5.
Remark 5.5. It can be seen that Figures 4 and 5 have the same shape and peak points because the spread of α is the same. In what follows, we will like to show that, even when the age groups are refined, the class(es) having the peak vale(s) in the refinement is/are invariant under our condition.
Example 5.6. Tables 5 and 6 in this example are, respectively, the refinements of Tables 1 and 2.
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 21 | 31 | 5 | 5 | 5 | 8 |
1997-2002 | 32 | 29 | 20 | 8 | 8 | 9 |
2003-2005 | 19 | 19 | 8 | 4 | 4 | 6 |
2006-2008 | 26 | 9 | 7 | 6 | 4 | 4 |
2009-2011 | 22 | 18 | 4 | 5 | 6 | 5 |
2012-2015 | 30 | 14 | 6 | 7 | 6 | 6 |
2016-2020 | 38 | 28 | 10 | 10 | 9 | 12 |
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 7.00 | 10.33 | 1.67 | 1.67 | 1.67 | 2.67 |
1997-2002 | 5.33 | 4.83 | 3.33 | 1.33 | 1.33 | 1.5 |
2003-2005 | 6.33 | 6.33 | 2.67 | 1.33 | 1.33 | 2.00 |
2006-2008 | 8.67 | 3.00 | 2.33 | 2.00 | 1.33 | 1.33 |
2009-2011 | 7.33 | 6.00 | 1.33 | 1.67 | 2.00 | 1.67 |
2012-2015 | 7.50 | 3.50 | 1.50 | 1.75 | 1.50 | 1.50 |
2016-2020 | 7.60 | 5.60 | 2.00 | 2.00 | 1.80 | 2.40 |
Average | 7.11 | 5.66 | 2.12 | 1.68 | 1.57 | 1.87 |
S.D | 1.05 | 2.41 | 0.71 | 0.28 | 0.27 | 0.51 |
From Tables 5 and 6, we can obtain the RTD matrices for the set of αs as 0.2,0.4,0.7, and 0.8.
The RTD matrix for α=0.2 is
[01−1011−1−11−1−1−1−111−1−111−111−1−110−101−11−1−11−1−1100111][2−4000−24]. | (5.22) |
The RTD matrix for α=0.4 is
[01−1001−101−1−1−1−101−1−101−101−1−100−10100−1−100−1100111][1−3−2−10−34]. | (5.23) |
The RTD matrix for α=0.7 is
[010001−101−1−1−1−101−1−101−101−1−100−10100−1−100−1000111][2−3−2−10−33]. | (5.24) |
The RTD matrix for α=0.8 is
[010001−101−1−10000−1−101−101−1−100−10100−1−1000000111][2−2−2−10−23]. | (5.25) |
The CETD matrix with the row sum is given below
[04−2014−4−14−4−4−3−313−4−414−414−4−410−404−11−4−41−1−3200444][7−12−6−30−1014]. | (5.26) |
The graph depicting the peak value of CETD matrix for α=0.2,0.4,0.7,0.8 is in Figure 6.
If we choose another set of αs, say, 0.1,0.3,0.6, and 0.78, the RTD matrix for α=0.1 is
[−11−1011−1−11−1−1−1−111−1−111−111−1−111−101−11−1−11−1−110−1111][1−4001−23]. | (5.27) |
The RTD matrix for α=0.3 is
[01−1001−1−11−1−1−1−101−1−101−111−1−100−101−11−1−100−1100111][2−4−20−1−24]. | (5.28) |
The RTD matrix for α=0.6 is
[01−1001−101−1−1−1−101−1−101−101−1−100−10100−1−100−1000111][1−3−2−10−33]. | (5.29) |
The RTD matrix for α=0.78 is
[010001−101−1−10000−1−101−101−1−100−10100−1−1000000111][2−2−2−10−23]. | (5.30) |
The CETD matrix with the row sum is given below
[−14−3024−4−24−4−4−3−313−4−414−424−4−411−404−22−4−41−1−320−1444][6−13−6−20−913]. | (5.31) |
The graph depicting the peak value of CETD matrix for α=0.1,0.3,0.6,0.78 is in Figure 7.
Remark 5.7. It can be seen that Figures 6 and 7 have the same shape and pick points becuse the spread of α is the same.
In Example 2, we have used our data to construct the RD matrix (Table 1) and the ATD matrix (Table 2). Considering the uniform partition {(0,0.25],(0.25,0.5],(0.5,0.75],(0.75,1]} and choosing α-levels 0.06,0.1,0.25,0.75, it is obvious that 0.06,0.1,0.25 are from the cell (0,0.25] of the partition. This CETD has its highest row sums in rows 1 and 5. These classes (or rows) depicting the peak values are not guaranteed when another set of α-levels are arbitrarily chosen as in the case of α=0.2,0.4,0.6,0.8, where the CETD matrix has its highest row sum in rows 1 and 4. Hence, the experiment does not guarantee consistency in the class depicting peak values for arbitrary choice of α-levels. Meanwhile, still using the same tables, considering the levels α=0.2,0.4,0.6,0.8, where at most one α-level was chosen from each cell of the partition, the class depicting peak values are in rows 1 and 4 of the CETD matrix. When another set of α-levels are chosen such that only at most one α-level is chosen from each cell of the partition as in the case of α=0.25,0.45,0.75,0.9, the CETD matrix also has the groups depicting peak values in rows 1 and 4. Comparing Figures 1–3, it can be concluded that Figures 2 and 3 have maintained the same classes for their peak values.
Repeating this method for an existing example, using Tables 3 and 4 and two different sets of α-levels, chosen according to our rule, namely, α=0.2,0.32,0.57,0.8 and α=0.25,0.45,0.68,0.85, it can be seen in Figures 4 and 5 that these sets of α-levels maintain peak values within the same age group. Besides, when Tables 1 and 2 are refined, the two sets of α-levels chosen according to our rule, namely, α=0.1,0.3,0.6,0.78 and α=0.2,0.4,0.7,0.8, maintain the peak at the same age group.
This paper has established the condition which guarantees that the peak point in a CETD matrix is not affected by the changes in the set {αs}. Hence, given that the interval (0,1] has a uniform partition into n cells, the set of n α-levels should be chosen such that, at most, one α-level in the set is chosen from each cell of the partition. If the experiment is repeated for as many sets of α-levels as preferred, the class depicting the peak value will not change.
In the next research, rather than devote much time and computational rigor to finding RTD matrices for different α, it is worth investigating if there is a single algorithm that excuses the steps of using different α to obtain RTD matrices. Also, it will be more appropriate to develop algorithms to obtain RTD matrices whose entries are truly in the range [0,1] and not merely {−1,0,1}. This idea can now be used in analyzing behaviors and characteristics which are age or time dependent in military personnel, agriculture, and logistics management, just to mention a few.
Babatunde Oluwaseun Onasanya: Conceptualization, formal analysis; Yuming Feng: Resources; Aishat Omobolanle Ilesanmi: Data curation; Babatunde Oluwaseun Onasanya and Aishat Omobolanle Ilesanmi: Writing-original draft; Dongfang Yan: Writing-review & editing, supervision; Hanyin Zhang, Dongfang Yan and Yuming Feng: Funding acquisition. All authors have read and approved the final version of the manuscript for publication.
This work is sponsored by the Natural Science Foundation of Chongqing, P.R. China (2024NSCQ-LZX0121, 2024NSCQ-LZX0120, 2023TIAD-ZXX0017, CSTB2023NSCQ-LZX0135), the Scientific and Technological Research Program of Chongqing Municipal Education Commission, P.R. China (KJZD-K202301023), the Scientific and Technological Research Program of Wanzhou District, P.R. China (WZSTC-20230309), the National Natural Science Foundation of China (12201086), and Program of Chongqing Municipal Education Commission, P.R. China (KJQN202201209, 233356).
The authors declare that they have no conflict of interests.
[1] |
W. Richard, Jr. Feldmann, Arthur Cayley-founder of matrix theory, Math. Teach., 55 (1962), 482–484. https://doi.org/10.5951/MT.55.6.0482 doi: 10.5951/MT.55.6.0482
![]() |
[2] |
L. A. Zadeh, Fuzzy sets, Inform. Control, 8 (1965), 338–353. https://doi.org/10.1016/S0019-9958(65)90241-X doi: 10.1016/S0019-9958(65)90241-X
![]() |
[3] |
M. G. Thomason, Convergence of powers of a fuzzy matrix, J. Math. Anal. Appl., 57 (1977), 476–480. https://doi.org/10.1016/0022-247X(77)90274-8 doi: 10.1016/0022-247X(77)90274-8
![]() |
[4] | A. R. Meenakshi, M. Kaliraja, An applications of inter-valued fuzzy matrices in medical diagnosis, Int. J. Math. Anal., 5 (2011), 1791–1802. |
[5] |
S. Elizabeth, I. Sujatha, Applications of fuzzy membership matrix in medical diagnosis and decision making, Appl. Math. Sci., 7 (2013), 6297–6307. https://doi.org/10.12988/ams.2013.38485 doi: 10.12988/ams.2013.38485
![]() |
[6] |
M. Pal, Fuzzy mathematics with fuzzy rows and fuzzy columns, J. Intell. Fuzzy Syst., 33 (2015), 561–573. https://doi.org/10.3233/IFS-151780 doi: 10.3233/IFS-151780
![]() |
[7] | T. O. Sangodapo, Y. Feng, An application of improved method of fuzzy matrix composition in medical diagnosis, Ital. J. Pure Appl. Math., 48 (2022), 1093–1103. |
[8] | W. B. V. Kandasamy, F. Smarandache, K. Ilanthenral, Special fuzzy matrices theory for social scientists, Ann Arbor: InfoLearnQuest, 2007. |
[9] | W. B. V. Kandasamy, F. Smarandache, K. Ilanthenral, Elementary fuzzy matrix theory and fuzzy models for social scientists, Los Angeles: Automaton, 2007. |
[10] | W. B. V. Kandasamy, F. Smarandache, K. Ilanthenral, Innovative uses of matrices, Ohio: Educational Publisher Inc., 2012. |
[11] | A. V. Devadoss, M. C. J. Anand, A. Felix, A CETD matrix approach to analyze the dimension of personality of person, In: Proceedings of International Conference on Computational Science and Computational Intelligence, Las Vegas, NV, USA, 2014, 40–45. |
[12] |
A. V. Devadoss, M. C. J. Anand, Dimensions of personality of women in Chennai using CETD matrix, Int. J. Comput. Appl., 50 (2012), 10–17. https://doi.org/10.5120/7766-0845 doi: 10.5120/7766-0845
![]() |
[13] |
A. V. Devadoss, A. Felix, Dimensions of personality of men in Chennai Using CETD matrix, Indian J. Appl. Res., 3 (2013), 486–492. https://doi.org/10.15373/2249555X/AUG2013/156 doi: 10.15373/2249555X/AUG2013/156
![]() |
[14] | N. Sarala, S. Sneha, Estimation of maximum age group affected by cardiovascular disease (CVD) for men in Nagapattinam town by using fuzzy matrix, Int. J. Adv. Tre. Eng. Sci. Technol., 2 (2017), 10–13. |
[15] | A. Saraswathi, N. Lakshmipathy, A. P. Govindarajan, An application of combined effect time dependent CETD matrix, The 11th National Conference on Mathematical Techniques and Applications, AIP Conf. Proc., 2019. https://doi.org/10.1063/1.5112359 |
[16] | R. S. Porchelvi, M. Slochana, An analysis of facts, causes and consequences of divorce using fuzzy matrix, Int. J. Adv. Res. Sci. Eng., 7 (2018), 6–12. |
[17] | D. Ajay, M. Slochana, Analysis of self actualization using CETD matrix, Int. J. Sci. Dev. Res., 5 (2020), 167–172. |
[18] |
G. Kuppuswami, R. Sujatha, W. B. V. Kandasamy, Study of traffic flow using CETD matrix, Indian J. Sci. Technol., 8 (2015), 1–5. https://doi.org/10.17485/ijst/2015/v8i24/80191 doi: 10.17485/ijst/2015/v8i24/80191
![]() |
[19] | A. V. Devadoss, A. Felix, I. Anbarasi, Women teachers affected by stress in Chennai schools using CETD marix, Indo-Bhutan International Conference On Gross National Happiness, 2 (2013), 189–195. |
[20] | K. Radhika, A. Alexander, S. Mariyappan, Risk factor of breast cancer using CETD marix-an analysis, Int. J. Appl. Eng. Res., 14 (2019), 67–73. |
[21] |
H. L. Sithic, R. Umarani, Fuzzy matrix theory as a knowledge discovery in health care domain, Proc. Comput. Sci., 47 (2015), 282–291. https://doi.org/10.1016/j.procs.2015.03.208 doi: 10.1016/j.procs.2015.03.208
![]() |
[22] | S. Narayanamoorthy, M. V. Smitha, K. Sivakamasundari, Fuzzy CETD matrix to estimate the maximum age group victims of pesticide endosulfan problems faced in Kerala, Int. J. Math. Comput. Appl. Res., 3 (2013), 227–232. |
[23] | A. V. Devadoss, M. C. J. Anand, Analysis of women computer users affected by a computer vision syndrome (CVS) using CETD matrix, Int. J. Sci. Eng. Res., 4 (2013), 1–6. |
[24] | C. O. Aguilar, An introduction to real analysis, New York: Suny Geneseo, 2022. |
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 21 | 31 | 5 | 5 | 5 | 8 |
1997-2002 | 32 | 29 | 20 | 8 | 8 | 9 |
2003-2008 | 45 | 28 | 15 | 10 | 8 | 10 |
2009-2015 | 46 | 30 | 10 | 12 | 11 | 11 |
2015-2020 | 44 | 30 | 10 | 11 | 11 | 12 |
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 7.00 | 10.33 | 1.67 | 1.67 | 1.67 | 2.67 |
1997-2002 | 5.33 | 4.83 | 3.33 | 1.33 | 1.33 | 1.5 |
2003-2008 | 7.5 | 4.67 | 2.50 | 1.67 | 1.33 | 1.67 |
2009-2015 | 7.67 | 5.00 | 1.67 | 2.00 | 1. 83 | 1.83 |
2015-2020 | 7.33 | 5.00 | 1.67 | 1.83 | 1.83 | 2.00 |
Average | 6.97 | 5.97 | 2.17 | 1.70 | 1.60 | 1.93 |
S.D | 0.95 | 2.44 | 0.74 | 0.25 | 0.25 | 0.45 |
Age | O1 | O2 | O3 | O4 | O5 | O6 |
10-17 | 22 | 23 | 19 | 25 | 27 | 16 |
18-24 | 22 | 24 | 20 | 21 | 18 | 13 |
25-29 | 22 | 24 | 24 | 21 | 21 | 24 |
30-39 | 17 | 17 | 14 | 19 | 23 | 20 |
40-49 | 11 | 20 | 20 | 12 | 23 | 18 |
50-59 | 7 | 13 | 14 | 5 | 21 | 13 |
60-75 | 4 | 13 | 8 | 4 | 20 | 8 |
Age | O1 | O2 | O3 | O4 | O5 | O6 |
10-17 | 2.75 | 2.88 | 2.38 | 3.13 | 3.38 | 2.00 |
18-24 | 3.14 | 3.43 | 2.86 | 3.00 | 2.57 | 1.86 |
25-29 | 4.40 | 4.80 | 4.80 | 4.20 | 4.20 | 4.80 |
30-39 | 1.70 | 1.70 | 1.40 | 1.90 | 2.30 | 2.00 |
40-49 | 1.10 | 2.00 | 2.00 | 1.20 | 2.30 | 1.80 |
50-59 | 0.70 | 1.30 | 1.40 | 0.50 | 2.10 | 1.30 |
60-75 | 0.25 | 0.81 | 0.50 | 0.25 | 1.25 | 0.50 |
Average | 2.01 | 2.42 | 2.19 | 2.03 | 2.59 | 2.04 |
Standard Deviation | 1.49 | 1.38 | 1.38 | 1.48 | 0.95 | 1.33 |
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 21 | 31 | 5 | 5 | 5 | 8 |
1997-2002 | 32 | 29 | 20 | 8 | 8 | 9 |
2003-2005 | 19 | 19 | 8 | 4 | 4 | 6 |
2006-2008 | 26 | 9 | 7 | 6 | 4 | 4 |
2009-2011 | 22 | 18 | 4 | 5 | 6 | 5 |
2012-2015 | 30 | 14 | 6 | 7 | 6 | 6 |
2016-2020 | 38 | 28 | 10 | 10 | 9 | 12 |
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 7.00 | 10.33 | 1.67 | 1.67 | 1.67 | 2.67 |
1997-2002 | 5.33 | 4.83 | 3.33 | 1.33 | 1.33 | 1.5 |
2003-2005 | 6.33 | 6.33 | 2.67 | 1.33 | 1.33 | 2.00 |
2006-2008 | 8.67 | 3.00 | 2.33 | 2.00 | 1.33 | 1.33 |
2009-2011 | 7.33 | 6.00 | 1.33 | 1.67 | 2.00 | 1.67 |
2012-2015 | 7.50 | 3.50 | 1.50 | 1.75 | 1.50 | 1.50 |
2016-2020 | 7.60 | 5.60 | 2.00 | 2.00 | 1.80 | 2.40 |
Average | 7.11 | 5.66 | 2.12 | 1.68 | 1.57 | 1.87 |
S.D | 1.05 | 2.41 | 0.71 | 0.28 | 0.27 | 0.51 |
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 21 | 31 | 5 | 5 | 5 | 8 |
1997-2002 | 32 | 29 | 20 | 8 | 8 | 9 |
2003-2008 | 45 | 28 | 15 | 10 | 8 | 10 |
2009-2015 | 46 | 30 | 10 | 12 | 11 | 11 |
2015-2020 | 44 | 30 | 10 | 11 | 11 | 12 |
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 7.00 | 10.33 | 1.67 | 1.67 | 1.67 | 2.67 |
1997-2002 | 5.33 | 4.83 | 3.33 | 1.33 | 1.33 | 1.5 |
2003-2008 | 7.5 | 4.67 | 2.50 | 1.67 | 1.33 | 1.67 |
2009-2015 | 7.67 | 5.00 | 1.67 | 2.00 | 1. 83 | 1.83 |
2015-2020 | 7.33 | 5.00 | 1.67 | 1.83 | 1.83 | 2.00 |
Average | 6.97 | 5.97 | 2.17 | 1.70 | 1.60 | 1.93 |
S.D | 0.95 | 2.44 | 0.74 | 0.25 | 0.25 | 0.45 |
Age | O1 | O2 | O3 | O4 | O5 | O6 |
10-17 | 22 | 23 | 19 | 25 | 27 | 16 |
18-24 | 22 | 24 | 20 | 21 | 18 | 13 |
25-29 | 22 | 24 | 24 | 21 | 21 | 24 |
30-39 | 17 | 17 | 14 | 19 | 23 | 20 |
40-49 | 11 | 20 | 20 | 12 | 23 | 18 |
50-59 | 7 | 13 | 14 | 5 | 21 | 13 |
60-75 | 4 | 13 | 8 | 4 | 20 | 8 |
Age | O1 | O2 | O3 | O4 | O5 | O6 |
10-17 | 2.75 | 2.88 | 2.38 | 3.13 | 3.38 | 2.00 |
18-24 | 3.14 | 3.43 | 2.86 | 3.00 | 2.57 | 1.86 |
25-29 | 4.40 | 4.80 | 4.80 | 4.20 | 4.20 | 4.80 |
30-39 | 1.70 | 1.70 | 1.40 | 1.90 | 2.30 | 2.00 |
40-49 | 1.10 | 2.00 | 2.00 | 1.20 | 2.30 | 1.80 |
50-59 | 0.70 | 1.30 | 1.40 | 0.50 | 2.10 | 1.30 |
60-75 | 0.25 | 0.81 | 0.50 | 0.25 | 1.25 | 0.50 |
Average | 2.01 | 2.42 | 2.19 | 2.03 | 2.59 | 2.04 |
Standard Deviation | 1.49 | 1.38 | 1.38 | 1.48 | 0.95 | 1.33 |
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 21 | 31 | 5 | 5 | 5 | 8 |
1997-2002 | 32 | 29 | 20 | 8 | 8 | 9 |
2003-2005 | 19 | 19 | 8 | 4 | 4 | 6 |
2006-2008 | 26 | 9 | 7 | 6 | 4 | 4 |
2009-2011 | 22 | 18 | 4 | 5 | 6 | 5 |
2012-2015 | 30 | 14 | 6 | 7 | 6 | 6 |
2016-2020 | 38 | 28 | 10 | 10 | 9 | 12 |
Years | C1 | C2 | C3 | C4 | C5 | C6 |
1994-1996 | 7.00 | 10.33 | 1.67 | 1.67 | 1.67 | 2.67 |
1997-2002 | 5.33 | 4.83 | 3.33 | 1.33 | 1.33 | 1.5 |
2003-2005 | 6.33 | 6.33 | 2.67 | 1.33 | 1.33 | 2.00 |
2006-2008 | 8.67 | 3.00 | 2.33 | 2.00 | 1.33 | 1.33 |
2009-2011 | 7.33 | 6.00 | 1.33 | 1.67 | 2.00 | 1.67 |
2012-2015 | 7.50 | 3.50 | 1.50 | 1.75 | 1.50 | 1.50 |
2016-2020 | 7.60 | 5.60 | 2.00 | 2.00 | 1.80 | 2.40 |
Average | 7.11 | 5.66 | 2.12 | 1.68 | 1.57 | 1.87 |
S.D | 1.05 | 2.41 | 0.71 | 0.28 | 0.27 | 0.51 |
