Abstract

1. Introduction

Tensor categories should be thought as counterparts of rings in the world of categories ^[1,2,3], i.e., the categorification of groups and rings ^[4,5,6]. They are ubiquitous in noncommutative algebra and representation theory. Tensor categories were introduced by Bénabou ^[7] in 1963 and Lane ^[8] as "categories with multiplication", and its related theories are now widely used in many fields of mathematics, including algebraic geometry ^[9], algebraic topology ^[10], number theory ^[11], operator algebraic theory ^[12], etc. The theory of tensor categories is also seen as a development following from that of Hopf algebras and their representation theory ^[13,14]. As an important invariant in the theory of tensor categories, the concept of a $\mathbb{Z}_+$ -ring can be traced back to Lusztig's work ^[15] in 1987. Later, in ^[16,17], the notion of a $\mathbb{Z}_+$ -module over a $\mathbb{Z}_+$ -ring was introduced. Module categories over multitensor categories were first considered in ^[4,18], and then the notion of an indecomposable module category was introduced in ^[17]. As a categorification of irreducible $\mathbb{Z}_+$ -modules, it is interesting to classify indecomposable exact module categories over a given tensor category. In this process, it is often necessary to first classify all irreducible $\mathbb{Z}_+$ -modules over the Grothendieck ring of a given tensor category.

Typical examples of $\mathbb{Z}_+$ -rings are the representation rings of Hopf algebras ^{[19,20,21,22,23,24]}. Another example is the Grothendieck rings of tensor categories ^{[25,26,27,28]}. It is natural to consider the classification of all irreducible $\mathbb{Z}_+$ -modules over them. For example, Etingof and Khovanov classified irreducible $\mathbb{Z}_+$ -modules over the group ring $\mathbb ZG$ , and showed that indecomposable $\mathbb{Z}_+$ -modules over the representation ring of ${\rm SU}(2)$ , under certain conditions, correspond to affine and infinite Dynkin diagrams ^[16]. Also, there is a lot of related research in the context of near-group fusion categories. For instance, Tambara and Yamagami classified semisimple tensor categories with fusion rules of self-duality for finite abelian groups. Evans, Gannon, and Izumi have contributed to the classification of the near-group $C^{*}$ -categories ^[29,30]. Yuan et al. ^[31] studied irreducible $\mathbb{Z}_+$ -modules of the near-group fusion ring $K\left(\mathbb Z_3, 3\right)$ and so on.

In this paper, we explore the problem of classifying irreducible based modules of rank up to 5 over the complex representation ring $r(S_4)$ , and then discuss their categorification. Furthermore, we overcome the technical difficulty of solving a series of non-negative integer equations using MATLAB. In contrast with the representation ring of $S_3$ , $r(S_n)$ is no longer a near-group fusion ring when $n > 3$ , and the classification of irreducible $\mathbb{Z}_+$ -modules over general $r(S_n)$ seems to be a hopeless task. Hence, our paper attempts to classify irreducible based modules for the non-near-group fusion ring $r(S_4)$ . In fact, the fusion rule of $r(S_n)$ is already a highly nontrivial open problem in combinatorics, namely counting the multiplicities of irreducible components of the tensor product of any two irreducible complex representations of $S_n$ (so called the Kronecker coefficients).

The paper is organized as follows. In Section 2, we recall some basic definitions and propositions. In Section 3, we discuss the irreducible based modules of rank up to 5 over $r(S_4)$ and give the classification of all these based modules (Propositions 3.1–3.5). In Section 4, we first show that any $\mathbb{Z}_+$ -module over the representation ring $r(G)$ of a finite group $G$ categorified by a module category over the representation category ${\rm Rep}(G)$ should be a based module (Theorem 4.2), and then determine which irreducible based modules over $r(S_4)$ can be categorified (Theorem 4.12).

2. Preliminaries

Throughout this paper, all rings are assumed to be associative with unit 1. Let $\mathbb{Z}_+$ denote the set of nonnegative integers. First, we recall the definitions of $\mathbb{Z}_+$ -rings and $\mathbb{Z}_+$ -modules. For more details about these concepts, readers can refer to ^[17,32].

2.1. $\mathbb{Z}_+$ -rings and $\mathbb{Z}_+$ -modules

In this section, we first recall some definitions, and then we exhibit a class of identities for transposed Poisson $n$ -Lie algebras.

Definition 2.1. Let $A$ be a ring which is free as a $\mathbb{Z}$ -module:

(i) A $\mathbb{Z}_+$ -basis of $A$ is a basis

$B = \left \{ b_{i} \right \} _{i\in I},$

such that

$b_{i}b_{j} = \sum\limits_{k\in I} c_{ij}^{k} b_{k},$

where $c_{ij}^{k}\in \mathbb{Z}_+$ .

(ii) A $\mathbb{Z}_+$ -ring is a ring with a fixed $\mathbb{Z}_+$ -basis and with unit 1 being a non-negative linear combination of the basis elements.

(iii) A $\mathbb{Z}_+$ -ring is unital if the unit $1$ is one of its basis elements.

Definition 2.2. Let $A$ be a $\mathbb{Z}_+$ -ring with basis $\left \{ b_{i} \right \}_{i\in I}$ . A $\mathbb{Z}_+$ -module over $A$ is an $A$ -module $M$ with a fixed $\mathbb{Z}$ -basis $\left \{ m_{l} \right \} _{l\in L}$ such that all the structure constants $a_{il}^{k}$ , defined by the equality

$b_{i} m_{l} = \sum\limits_{k} a_{il}^{k} m_{k}$

are non-negative integers.

A $\mathbb{Z}_+$ -module has the following equivalent definition referring to [32, Section 3.4].

Definition 2.3. Let $A$ be a $\mathbb{Z}_+$ -ring with basis $\left \{ b_{i} \right \}_{i\in I}$ . A $\mathbb{Z}_+$ -module $M$ over $A$ means an assignment where each basis $b_{i}$ in $A$ is in one-to-one correspondence with a non-negative integer square matrix $M_i$ such that $M$ forms a representation of $A$ :

$M_{i} M_{j} = \sum\limits_{k\in I} c_{ij}^{k} M_{k}, \; \; \forall \space i, j, k\in I,$

where the unit of $A$ corresponds to the identity matrix. The rank of a $\mathbb{Z}_+$ -module $M$ is equal to the order of the matrix $M_{i}$ .

Definition 2.4. (i) Two $\mathbb{Z}_+$ -modules $M_{1}, \, M_{2}$ over $A$ with bases ${\left \{ m_{i}^{1} \right \} }_{i\in L_{1}}, {\left \{ m_{j}^{2} \right \} }_{j\in L_{2}}$ are equivalent if and only if there exists a bijection $\phi$ : $L_{1}\to L_{2}$ such that the induced $\mathbb{Z}$ -linear map $\tilde{\phi}$ of abelian groups $M_{1}, \, M_{2}$ defined by

$\tilde{\phi} (m_{i}^{1} ) = m_{{\phi} (i)}^{2}$

is an isomorphism of $A$ -modules. In other words, for $a\in A$ , let $a_{M_{1} }$ and $a_{M_{2} }$ be the matrices with respect to the bases ${\left \{ m_{i}^{1} \right \} }_{i\in L_{1}}$ and ${\left \{ m_{j}^{2} \right \} }_{j\in L_{2}}$ , respectively. Then, two $\mathbb{Z}_+$ -modules $M_{1}$ , $M_{2}$ of rank $n$ are equivalent if and only if there exists an $n\times n$ permutation matrix $P$ such that

$a_{M_{2}} = Pa_{M_{1}}P^{-1}, \; \; \; \forall \space a\in A.$

(ii) The direct sum of two $\mathbb{Z}_+$ -modules $M_{1}, \, M_{2}$ over $A$ is the module $M_{1}\oplus M_{2}$ over $A$ whose basis is the union of the bases of $M_{1}$ and $M_{2}$ .

(iii) A $\mathbb{Z}_+$ -module $M$ over $A$ is indecomposable if it is not equivalent to a nontrivial direct sum of $\mathbb{Z}_+$ -modules.

(iv) A $\mathbb{Z}_+$ -submodule of a $\mathbb{Z}_+$ -module $M$ over $A$ with basis $\left \{ m_{l} \right \}_{l\in L}$ is a subset $J\subset L$ such that the abelian subgroup of $M$ generated by ${\left \{ m_{j} \right \} }_{j\in J}$ is an $A$ -submodule.

(v) A $\mathbb{Z}_+$ -module $M$ over $A$ is irreducible if any $\mathbb{Z}_+$ -submodule of $M$ is 0 or $M$ . In other words, the $\mathbb{Z}$ -span of any proper subset of the basis of $M$ is not an $A$ -submodule.

2.2. Based rings and based modules

Let $A$ be a $\mathbb{Z}_+$ -ring with basis $\left \{ b_{i} \right \}_{i\in I}$ , and let $I_{0}$ be the set of $i\in I$ such that $b_{i}$ occurs in the decomposition of 1. Let $\tau$ : $A\to \mathbb Z$ denote the group homomorphism defined by

$\tau (b_{i} ) = \begin{cases}1, & \text{ if } \ i\in I_{0} , \\0, & \text{ if } \ i\notin I_{0} .\end{cases}$

Definition 2.5. A $\mathbb{Z}_+$ -ring with basis $\left \{ b_{i} \right \}_{i\in I}$ is called a based ring if there exists an involution $i \mapsto i^{*}$ of $I$ such that the induced map

$a = \sum\limits_{i\in I} a_{i} b_{i}\mapsto {}a^{*} = \sum\limits_{i\in I} a_{i} b_{i^*}, \; \; \; a_{i}\in \mathbb{Z},$

is an anti-involution of the ring $A$ , and

$\tau (b_{i}b_{j} ) = \begin{cases}1, & { if } \ i = j^{*} , \\0, & { if } \ i\ne j^{*} .\end{cases}$

A fusion ring is a unital based ring of finite rank.

Definition 2.6. A based module over a based ring $A$ with basis $\left \{ b_{i} \right \}_{i\in I}$ is a $\mathbb{Z}_+$ -module $M$ with basis $\left \{ m_{l} \right \}_{l\in L}$ over $A$ such that

$a_{il}^{k} = a_{i^{\ast } k}^{l} ,$

where $a_{il}^{k}$ are defined as in Definition 2.2.

Let $A$ be a unital $\mathbb{Z}_+$ -ring of finite rank with basis $\left \{ b_{i} \right \}_{i\in I}$ , and let $M$ be a $\mathbb{Z}_+$ -module over $A$ with $\mathbb{Z}$ -basis $\left \{ m_{l} \right \} _{l\in L}$ . Take

$b = \sum\limits_{i\in I}b_i.$

For any fixed $m_{l_0}$ , the $\mathbb{Z}_+$ -submodule of $M$ generated by $m_{l_0}$ is the $\mathbb{Z}$ -span of $\left \{m_k\right\}_{k\in Y}$ , where the set $Y$ consists of $k\in L$ such that $m_k$ is a summand of $bm_{l_0}$ . Also, we need the following facts.

Proposition 2.1. [, Proposition 3.4.6] Let $A$ be a based ring of finite rank over $\mathbb{Z}$ . Then there exist only finitely many irreducible $\mathbb{Z}_+$ -modules over $A$ .

Proposition 2.2. [, Lemma 2.1] Let $M$ be a based module over a based ring $A$ . If $M$ is decomposable as a $\mathbb{Z}_+$ -module over $A$ , then $M$ is irreducible as a $\mathbb{Z}_+$ -module over $A$ .

As a result, any $\mathbb{Z}_+$ -module of finite rank over a fusion ring is completely reducible, and then only irreducible $\mathbb{Z}_+$ -modules need to be classified.

In general, the rank of an irreducible $\mathbb{Z}_+$ -module over a fusion ring $A$ may be larger than the rank of $A$ ; e.g., $A = r(D_5)$ for the dihedral group $D_5$ ([, Remark 1]). In this paper, we explore which irreducible based modules over $r(S_4)$ can be categorified by indecomposable exact module categories over the representation category ${\rm Rep}(S_4)$ . Since all these module categories are of rank not greater than 5, we only deal with based modules of rank up to 5 correspondingly.

3. Irreducible based modules over $r(S_4)$

In this section, we will classify the irreducible based modules over the complex representation ring $r(S_4)$ of $S_4$ up to equivalence. $r(S_4)$ is a commutative fusion ring having a $\mathbb{Z}_+$ -basis $\left \{ 1, V_{\psi}, V_{\rho _{1}}, V_{\rho _{2}}, V_{\rho _{3}} \right \}$ with the fusion rule.

$\begin{equation} \begin{array}{c} V_{\psi}^2 = 1, \quad V_{\psi}V_{\rho _{1}} = V_{\rho _{1}}, \quad V_{\psi}V_{\rho _{2}} = V_{\rho _{3}}, \quad V_{\rho _{1}}^2 = 1+V_{\psi}+V_{\rho _{1}}, \\[.5em] V_{\rho_1 }V_{\rho_2 } = V_{\rho_2 }+V_{\rho_3}, \quad V_{\rho _{2}}^2 = 1+ V_{\rho _{1}}+ V_{\rho _{2}}+ V_{\rho _{3}}, \end{array} \end{equation}$

(3.1)

where $1$ , $V_{\psi}$ , and $V_{\rho _{1}}$ denote the trivial representation, sign representation, and 2-dimensional irreducible representation, respectively, while $V_{\rho_2}$ stands for the 3-dimensional standard representation and $V_{\rho_3}$ denotes its conjugate representation. Then we have the following Table 1.

Table 1. The complex character table of

$S_4$ .

	$(1)$	$(12)$	$(123)$	$(1234)$	$(12)(34)$
$\chi_1$	$1$	$1$	$1$	$1$	$1$
$\chi_\psi$	$1$	$-1$	$1$	$-1$	$1$
$\chi_{\rho_1}$	$2$	$0$	$-1$	$0$	$2$
$\chi_{\rho_2}$	$3$	$1$	$0$	$-1$	$-1$
$\chi_{\rho_3}$	$3$	$-1$	$0$	$1$	$-1$

| Show Table

DownLoad: CSV

Let $M$ be a based module of $r(S_4)$ with the basis $\left \{ m_{l} \right \} _{l\in L}$ . Let $T, \, Q, \, U$ , and $W$ be the matrices representing the action of $V_{\psi}, \, V_{\rho _{1}}, \, V_{\rho _{2}}$ , and $V_{\rho _{3}}$ on $M$ respectively. They are all symmetric matrices with nonnegative integer entries by Definition 2.6. Let $E$ be the identity matrix. By the fusion rule of $r(S_4)$ , we have

$\begin{align} T^2& = E, \end{align}$

(3.2)

$\begin{align} TQ& = QT = Q, \end{align}$

(3.3)

$\begin{align} TU& = UT = W, \end{align}$

(3.4)

$\begin{align} Q^2& = E+T+Q, \end{align}$

(3.5)

$\begin{align} QU& = U+TU, \end{align}$

(3.6)

$\begin{align} U^2& = E+Q+U+TU. \end{align}$

(3.7)

In particular, since $T^2 = E$ and $T$ has nonnegative integer entries, we know that $T$ is a symmetric permutation matrix.

Convention 3.1. Let $P_n$ be the group of $n\times n$ permutation matrices. Since there is naturally a group isomorphism between $S_n$ and $P_n$ , we will use the cycle notation of permutations to represent permutation matrices.

3.1. Irreducible based modules of rank $\le 3$ over $r(S_4)$

We define a $\mathbb{Z}_+$ -module $M_{1, 1}$ of rank 1 over $r(S_4)$ by letting

$\begin{equation} V_{\psi} \mapsto 1, \quad V_{\rho _{1}}\mapsto 2, \quad V_{\rho _{2}}\mapsto 3, \quad V_{\rho _{3}}\mapsto 3. \end{equation}$

(3.8)

Proposition 3.1. Any irreducible based module of rank $1$ over $r(S_4)$ is equivalent to $M_{1, 1}$ .

Proof. Note that any integral fusion ring $A$ has the unique character ${\rm FPdim}$ : $A\to \mathbb{Z}$ , which takes non-negative values on the $\mathbb{Z}_+$ -basis, so there exists a unique $\mathbb{Z}_+$ -module $M$ of rank 1 over it. Clearly, such $M$ is a based module. Now this argument is available for the situation $A = r(S_4)$ . □

Next, we consider irreducible based modules of rank $2, 3$ . According to the fusion rule of $r(S_4)$ given in (3.1), it is sufficient to only list the representation matrices of $V_{\psi}$ , $V_{\rho _{1}}$ , and $V_{\rho _{2}}$ acting on them. For simplicity, we choose to present our result for the cases of small rank 2 and 3 directly, and then analyze the cases of higher rank 4 and 5 with details.

Proposition 3.2. Let $M$ be an irreducible based module of rank $2$ over $r(S_4)$ . Then $M$ is equivalent to one of the based modules $M_{2, i}, \, 1\leq i\leq 3$ , listed in Table 2.

Table 2. Inequivalent irreducible based modules of rank 2 over

$r(S_4)$ .

	$V_{\psi}$	$V_{\rho _{1}}$	$V_{\rho _{2}}$
$M_{2, 1}$	$\begin{pmatrix} 1&0\\0&1\end{pmatrix}$	$\begin{pmatrix} 2&0\\0&2\end{pmatrix}$	$\begin{pmatrix} 1&2\\2&1\end{pmatrix}$
$M_{2, 2}$	$\begin{pmatrix} 0&1\\1&0\end{pmatrix}$	$\begin{pmatrix} 1&1\\1&1\end{pmatrix}$	$\begin{pmatrix} 2&1\\1&2\end{pmatrix}$
$M_{2, 3}$	$\begin{pmatrix} 0&1\\1&0\end{pmatrix}$	$\begin{pmatrix} 1&1\\1&1\end{pmatrix}$	$\begin{pmatrix} 1&2\\2&1\end{pmatrix}$

| Show Table

DownLoad: CSV

Proposition 3.3. Let $M$ be an irreducible based module of rank $3$ over $r(S_4)$ . Then $M$ is equivalent to one of the based modules $M_{3, i}, \, 1\leq i\leq 3$ , listed in Table 3.

Table 3. Inequivalent irreducible based modules of rank 3 over

$r(S_4)$ .

	$V_{\psi}$	$V_{\rho _{1}}$	$V_{\rho _{2}}$
$M_{3, 1}$	$\begin{pmatrix} 1&0&0\\0&1&0\\0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1\\1&0&1\\1&1&0\\\end{pmatrix}$	$\begin{pmatrix} 1&1&1\\1&1&1\\1&1&1\\\end{pmatrix}$
$M_{3, 2}$	$\begin{pmatrix} 0&1&0\\1&0&0\\0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 0&0&1\\0&0&1\\1&1&1\\\end{pmatrix}$	$\begin{pmatrix} 1&0&1\\0&1&1\\1&1&2\\\end{pmatrix}$
$M_{3, 3}$	$\begin{pmatrix} 0&1&0\\1&0&0\\0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 0&0&1\\0&0&1\\1&1&1\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1\\1&0&1\\1&1&2\\\end{pmatrix}$

| Show Table

DownLoad: CSV

3.2. Irreducible based modules of rank $4, \, 5$ over $r(S_4)$

Proposition 3.4. Let $M$ be an irreducible based module of rank $4$ over $r(S_4)$ . Then $M$ is equivalent to one of the based modules $M_{4, i}, \, 1\leq i\leq 7$ , listed in Table 4.

Table 4. Inequivalent irreducible based modules of rank 4 over

$r(S_4)$ .

	$V_{\psi}$	$V_{\rho _{1}}$	$V_{\rho _{2}}$
$M_{4, 1}$	$\begin{pmatrix} 1&0&0&0\\0&1&0&0\\0&0&1&0\\0&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 0&0&1&1\\0&2&0&0\\1&0&0&1\\1&0&1&0\\\end{pmatrix}$	$\begin{pmatrix} 0&1&0&0\\1&2&1&1\\0&1&0&0\\0&1&0&0\\\end{pmatrix}$
$M_{4, 2}$	$\begin{pmatrix} 1&0&0&0\\0&1&0&0\\0&0&1&0\\0&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 2&0&0&0\\0&2&0&0\\0&0&2&0\\0&0&0&2\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1&1\\1&0&1&1\\1&1&0&1\\1&1&1&0\\\end{pmatrix}$
$M_{4, 3}$	$\begin{pmatrix} 0&1&0&0\\1&0&0&0\\0&0&1&0\\0&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0\\1&1&0&0\\0&0&2&0\\0&0&0&2\\\end{pmatrix}$	$\begin{pmatrix} 1&0&1&1\\0&1&1&1\\1&1&0&1\\1&1&1&0\\\end{pmatrix}$
$M_{4, 4}$	$\begin{pmatrix} 0&1&0&0\\1&0&0&0\\0&0&1&0\\0&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0\\1&1&0&0\\0&0&2&0\\0&0&0&2\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1&1\\1&0&1&1\\1&1&0&1\\1&1&1&0\\\end{pmatrix}$
$M_{4, 5}$	$\begin{pmatrix} 0&1&0&0\\1&0&0&0\\0&0&0&1\\0&0&1&0\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0\\1&1&0&0\\0&0&1&1\\0&0&1&1\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1&1\\1&0&1&1\\1&1&0&1\\1&1&1&0\\\end{pmatrix}$
$M_{4, 6}$	$\begin{pmatrix} 0&1&0&0\\1&0&0&0\\0&0&0&1\\0&0&1&0\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0\\1&1&0&0\\0&0&1&1\\0&0&1&1\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1&1\\1&0&1&1\\1&1&1&0\\1&1&0&1\\\end{pmatrix}$
$M_{4, 7}$	$\begin{pmatrix} 0&1&0&0\\1&0&0&0\\0&0&0&1\\0&0&1&0\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0\\1&1&0&0\\0&0&1&1\\0&0&1&1\\\end{pmatrix}$	$\begin{pmatrix} 1&0&1&1\\0&1&1&1\\1&1&1&0\\1&1&0&1\\\end{pmatrix}$

| Show Table

DownLoad: CSV

Proof. Before giving its detailed proof, we provide the following proof outline first.

$({\rm{i}})$ The symmetric group $S_4$ has 3 conjugacy classes of permutations of order $\le 2$ , so there are 3 representatives for matrix $T$ up to conjugation as follows:

$\begin{equation*} T_1 = E_4, \quad T_2 = (12), \quad T_3 = (12)(34). \end{equation*}$

Consequently, we can take $T = T_r$ for some $r = 1, 2, 3$ as the representation matrix of $V_\psi$ for the based module $M$ up to equivalence.

$({\rm{ii}})$ Use MATLAB to search all solutions of the representation matrices $Q$ and $U$ in the group of nonnegative integer matrix Eqs (3.3)–(3.7) by constraint satisfaction.

$({\rm{iii}})$ Distinguish all conjugacy classes of tuples $(T, Q, U)$ without simultaneous block decomposition. They correspond to the equivalence classes of irreducible based modules over $r(S_4)$ .

□

Proof. Let $M$ be a based module of rank 4 over $r(S_4)$ , with the action of $r(S_4)$ on it given by

$\begin{equation} V_{\psi} \mapsto T, \quad V_{\rho _{1}}\mapsto Q = (a_{ij})_{1\leq i, j\leq4} , \quad V_{\rho _{2}}\mapsto U = (b_{ij})_{1\leq i, j\leq4}, \quad V_{\rho _{3}}\mapsto W = TU, \nonumber \end{equation}$

where $a_{ij} = a_{ji}$ , $b_{ij} = b_{ji}$ .

The symmetric group $S_4$ has two conjugacy classes of permutations of order 2. One conjugacy class of 6 permutations includes $(12)$ , and the other one of 3 permutations includes $(12)(34)$ . As previously seen, $T$ is the unit or an element of order 2 in $P_4$ , so we have 10 candidates for $T$ , and each of them is conjugate to one of the following 3 matrices:

$\begin{equation*} T_1 = E_4, \quad T_2 = (12) , \quad T_3 = (12)(34) . \end{equation*}$

Hence, for the based module $M$ determined by the pair $(T, Q, U)$ , there exists a $4\times 4$ permutation matrix $P$ such that

$T' = PTP^{-1}$

is one of the above $T_r$ 's $(1\leq r\leq 3)$ . Correspondingly, let

$Q' = PQP^{-1} , \; \; \; U' = PUP^{-1}.$

Then we get a based module $M'$ determined by the pair $(T', Q', U')$ and equivalent to $M$ as based modules by Definition 2.4 (ⅰ). So, we have reduced the proof to the situation when $T = T_r$ .

Case 1. $T = T_1 = E_4$ .

Since $Q$ satisfies Eq (3.5), we obtain the following system of integer equations:

$\begin{equation*} \left\{\begin{array}{l} a_{11}^2+a_{12}^2+a_{13}^2+a_{14}^2 = 2+a_{11}, \\ a_{11}a_{12}+a_{12}a_{22}+a_{13}a_{23}+a_{14}a_{24} = a_{12}, \\ a_{11}a_{13}+a_{12}a_{23}+a_{13}a_{33}+a_{14}a_{34} = a_{13}, \\ a_{11}a_{14}+a_{12}a_{24}+a_{13}a_{34}+a_{14}a_{44} = a_{14}, \\ a_{12}^2+a_{22}^2+a_{23}^2+a_{24}^2 = 2+a_{22}, \\ a_{12}a_{13}+a_{22}a_{23}+a_{23}a_{33}+a_{24}a_{34} = a_{23}, \\ a_{12}a_{14}+a_{22}a_{24}+a_{23}a_{34}+a_{24}a_{44} = a_{24}, \\ a_{13}^2+a_{23}^2+a_{33}^2+a_{34}^2 = 2+a_{33}, \\ a_{13}a_{14}+a_{23}a_{24}+a_{33}a_{34}+a_{34}a_{44} = a_{34}, \\ a_{14}^2+a_{24}^2+a_{34}^2+a_{44}^2 = 2+a_{44}. \end{array}\right. \end{equation*}$

We use MATLAB to figure out all the solutions of $Q$ as follows:

$\begin{array}{l} Q_1 = \begin{pmatrix} 0&0&1&1 \\ 0&2&0&0 \\ 1&0&0&1 \\ 1&0&1&0 \end{pmatrix}, \quad Q_2 = \begin{pmatrix} 0&1&0&1 \\ 1&0&0&1 \\ 0&0&2&0 \\ 1&1&0&0 \end{pmatrix}, \quad Q_3 = \begin{pmatrix} 0&1&1&0 \\ 1&0&1&0 \\ 1&1&0&0 \\ 0&0&0&2 \end{pmatrix}, \\[2em] Q_4 = \begin{pmatrix} 2&0&0&0 \\ 0&0&1&1 \\ 0&1&0&1 \\ 0&1&1&0 \end{pmatrix}, \quad Q_5 = \begin{pmatrix} 2&0&0&0 \\ 0&2&0&0 \\ 0&0&2&0 \\ 0&0&0&2 \end{pmatrix}. \end{array}$

Next, we calculate $U$ after taking $Q$ as one $Q_k$ $\left (1\le k\le5 \right)$ .

Case 1.1. $Q = Q_1$ .

Since $U$ satisfies Eq (3.6), we get

$\begin{equation*} \begin{split} b_{12}& = b_{23} = b_{24}, \\ b_{11}& = b_{13} = b_{14} = b_{33} = b_{34} = b_{44}. \end{split} \end{equation*}$

Then, by Eq (3.7), we have

$\begin{equation*} \left\{\begin{array}{l} 3b_{11}^2+b_{12}^2 = 2b_{11}+1, \\ 3b_{11}b_{12}+b_{12}b_{22} = 2b_{12}, \\ 3b_{12}^2+b_{22}^2 = 2b_{22}+3. \end{array}\right. \end{equation*}$

The solutions of $U$ given by MATLAB are as follows:

$\begin{equation*} U_1 = \begin{pmatrix} 0&1&0&0 \\ 1&2&1&1 \\ 0&1&0&0 \\ 0&1&0&0 \end{pmatrix}, \quad U_2 = \begin{pmatrix} 1&0&1&1 \\ 0&3&0&0 \\ 1&0&1&1 \\ 1&0&1&1 \end{pmatrix}. \end{equation*}$

It is easy to check that the based module determined by $\left (T_1, Q_1, U_1\right)$ is an irreducible based module denoted as $M_{4, 1}$ , while the based module determined by $\left (T_1, Q_1, U_2\right)$ is reducible.

Note that there exists a permutation matrix $P = (14)(23)$ such that

$PQ_1P^{-1} = Q_2.$

Let

$U'_1 = PU_1P^{-1}.$

There is an irreducible based module $N'$ determined by the pair $\big (T_1, Q_2, U'_1\big)$ and equivalent to $M_{4, 1}$ by Definition 2.4 (ⅰ). Conversely, any irreducible based module with representation matrices $T_1$ and $Q_2$ is equivalent to $M_{4, 1}$ . The same analysis tells us that irreducible based modules with representation matrices $T_1$ and $Q_3$ (or $Q_4$ ) are also equivalent to $M_{4, 1}$ .

Case 1.2. $Q = Q_5$ .

Since $U$ satisfies Eqs (3.6) and (3.7), we get a system of integer equations as follows:

$\begin{equation*} \left\{\begin{array}{l} b_{11}^2+b_{12}^2+b_{13}^2+b_{14}^2 = 2b_{11}+3, \\ b_{11}b_{12}+b_{12}b_{22}+b_{13}b_{23}+b_{14}b_{24} = 2b_{12}, \\ b_{11}b_{13}+b_{12}b_{23}+b_{13}b_{33}+b_{14}b_{34} = 2b_{13}, \\ b_{11}b_{14}+b_{12}b_{24}+b_{13}b_{34}+b_{14}b_{44} = 2b_{14}, \\ b_{12}^2+b_{22}^2+b_{23}^2+b_{24}^2 = 2b_{22}+3, \\ b_{12}b_{13}+b_{22}b_{23}+b_{23}b_{33}+b_{24}b_{34} = 2b_{23}, \\ b_{12}b_{14}+b_{22}b_{24}+b_{23}b_{34}+b_{24}b_{44} = 2b_{24}, \\ b_{13}^2+b_{23}^2+b_{33}^2+b_{34}^2 = 2b_{33}+3, \\ b_{13}b_{14}+b_{23}b_{24}+b_{33}b_{34}+b_{34}b_{44} = 2b_{34}, \\ b_{14}^2+b_{24}^2+b_{34}^2+b_{44}^2 = 2b_{44}+3. \\ \end{array}\right. \end{equation*}$

Thus, the solutions of $U$ by MATLAB are as follows:

$\begin{align*} &U_1 = \begin{pmatrix} 0&1&1&1 \\ 1&0&1&1 \\ 1&1&0&1 \\ 1&1&1&0\end{pmatrix}, \quad U_2 = \begin{pmatrix} 1&0&0&2 \\ 0&1&2&0 \\ 0&2&1&0 \\ 2&0&0&1\end{pmatrix}, \quad U_3 = \begin{pmatrix}1&0&2&0 \\ 0&1&0&2 \\ 2&0&1&0 \\ 0&2&0&1\end{pmatrix}, \quad U_4 = \begin{pmatrix}1&2&0&0 \\ 2&1&0&0 \\ 0&0&1&2 \\ 0&0&2&1\end{pmatrix}, \\[2em] &U_5 = \begin{pmatrix} 1&0&2&0 \\ 0&3&0&0 \\ 2&0&1&0 \\ 0&0&0&3\end{pmatrix}, \quad U_6 = \begin{pmatrix} 1&0&0&2 \\ 0&3&0&0 \\ 0&0&3&0 \\ 2&0&0&1\end{pmatrix}, \quad U_7 = \begin{pmatrix}1&2&0&0 \\ 2&1&0&0 \\ 0&0&3&0 \\ 0&0&0&3\end{pmatrix}, \quad U_8 = \begin{pmatrix}3&0&0&0 \\ 0&3&0&0 \\ 0&0&1&2 \\ 0&0&2&1\end{pmatrix}, \\ &U_9 = \begin{pmatrix} 3&0&0&0 \\ 0&1&2&0 \\ 0&2&1&0 \\ 0&0&0&3\end{pmatrix}, \quad U_{10} = \begin{pmatrix} 3&0&0&0 \\ 0&1&0&2 \\ 0&0&3&0 \\ 0&2&0&1\end{pmatrix}, \quad U_{11} = \begin{pmatrix}3&0&0&0 \\ 0&3&0&0 \\ 0&0&3&0 \\ 0&0&0&3\end{pmatrix}. \end{align*}$

Since $T_1$ and $Q_5$ are diagonal and the solutions $U_t$ $\left (2\le t\le11 \right)$ are block diagonal with at least two blocks, only the based module determined by $(T_1, Q_5, U_1)$ is irreducible, denoted as $M_{4, 2}$ .

Case 2. $T = T_2 = (12)$ .

Since $Q$ satisfies Eq (3.3), we get

$\begin{equation*} Q = \begin{pmatrix} a_{11}&a_{11}&a_{13}&a_{14} \\ a_{11}&a_{11}&a_{13}&a_{14}\\ a_{13}&a_{13}&a_{33}&a_{34} \\ a_{14}&a_{14}&a_{34}&a_{44} \end{pmatrix}. \end{equation*}$

Since $Q$ also satisfies Eq (3.5), we have the following system of integer equations:

$\begin{equation*} \left\{\begin{array}{l} 2a_{11}^2+a_{13}^2+a_{14}^2 = a_{11}+1, \\ 2a_{11}a_{13}+a_{13}a_{33}+a_{14}a_{34} = a_{13}, \\ 2a_{11}a_{14}+a_{13}a_{34}+a_{14}a_{44} = a_{14}, \\ 2a_{13}^2+a_{33}^2+a_{34}^2 = a_{33}+2, \\ 2a_{13}a_{14}+a_{33}a_{34}+a_{34}a_{44} = a_{34}, \\ 2a_{14}^2+a_{34}^2+a_{44}^2 = a_{44}+2. \\ \end{array}\right. \end{equation*}$

Hence, the solutions of $Q$ by MATLAB are as follows:

$\begin{array}{l} Q_1 = \begin{pmatrix} 0&0&0&1 \\ 0&0&0&1 \\ 0&0&2&0 \\ 1&1&0&1\end{pmatrix}, \quad Q_2 = \begin{pmatrix} 0&0&1&0 \\ 0&0&1&0 \\ 1&1&1&0 \\ 0&0&0&2\end{pmatrix}, \quad Q_3 = \begin{pmatrix}1&1&0&0 \\ 1&1&0&0 \\ 0&0&2&0 \\ 0&0&0&2\end{pmatrix}. \end{array}$

Since $U$ satisfies Eq (3.4), we get

$\begin{equation*} U = \begin{pmatrix} b_{11}&b_{12}&b_{13}&b_{14}\\ b_{12}&b_{11}&b_{13}&b_{14}\\ b_{13}&b_{13}&b_{33}&b_{34} \\ b_{14}&b_{14}&b_{34}&b_{44} \end{pmatrix}. \end{equation*}$

Next, we calculate $U$ after taking $Q$ as one $Q_k$ $\left (1\le k\le3 \right)$ .

Case 2.1. $Q = Q_1$ .

Since $U$ satisfies Eqs (3.6) and (3.7), the solutions of $U$ given by MATLAB are as follows:

$\begin{array}{l} U_1 = \begin{pmatrix} 0&1&0&1 \\ 1&0&0&1 \\ 0&0&3&0 \\ 1&1&0&2\end{pmatrix}, \quad U_2 = \begin{pmatrix} 1&0&0&1 \\ 0&1&0&1 \\ 0&0&3&0 \\ 1&1&0&2\end{pmatrix}. \end{array}$

Since $T_2$ , $Q_1$ and all the solutions $U_t$ for $t = 1, 2$ are block diagonal with at least two blocks, the based modules determined by each pair $(T_2, Q_1, U_t)$ are reducible.

Note that there exists a permutation matrix $P = (12)(34)$ such that

$PQ_1P^{-1} = Q_2.$

Let

$U'_t = PU_tP^{-1}.$

Then each based module $N_t$ determined by the pair $\left (T_2, Q_2, U'_t\right)$ is reducible. Namely, any based module with representation matrices $T_2$ and $Q_2$ is reducible.

Case 2.2. $Q = Q_3$ .

Since $U$ satisfies Eqs (3.6) and (3.7), we have

$\begin{array}{l} U_1 = \begin{pmatrix} 0&1&1&1 \\ 1&0&1&1 \\ 1&1&0&1 \\ 1&1&1&0\end{pmatrix}, \quad U_2 = \begin{pmatrix} 1&0&1&1 \\ 0&1&1&1 \\ 1&1&0&1 \\ 1&1&1&0\end{pmatrix}, \quad U_3 = \begin{pmatrix}1&2&0&0 \\ 2&1&0&0 \\ 0&0&1&2 \\ 0&0&2&1\end{pmatrix}, \\[2em] U_4 = \begin{pmatrix}1&2&0&0 \\ 2&1&0&0 \\ 0&0&3&0 \\ 0&0&0&3\end{pmatrix}, \quad U_5 = \begin{pmatrix} 2&1&0&0 \\ 1&2&0&0 \\ 0&0&1&2 \\ 0&0&2&1\end{pmatrix}, \quad U_6 = \begin{pmatrix} 2&1&0&0 \\ 1&2&0&0 \\ 0&0&3&0 \\ 0&0&0&3\end{pmatrix}. \end{array}$

Since $T_2$ , $Q_3$ and the solutions $U_s$ $(3\le s\le 6)$ are block diagonal with at least two blocks, only the based module determined by $(T_2, Q_3, U_1)$ and $(T_2, Q_3, U_2)$ are irreducible, denoted as $M_{4, 3}$ and $M_{4, 4}$ , respectively. It is easy to check that $M_{4, 3}$ and $M_{4, 4}$ are inequivalent based modules.

Case 3. $T = T_3 = (12)(34)$ .

Since $Q$ satisfies Eq (3.3), we get

$\begin{equation*} Q = \begin{pmatrix} a_{11}&a_{11}&a_{13}&a_{13} \\ a_{11}&a_{11}&a_{13}&a_{13}\\ a_{13}&a_{13}&a_{33}&a_{33} \\ a_{13}&a_{13}&a_{33}&a_{33} \end{pmatrix}. \end{equation*}$

Then, by Eq (3.5), we have the following system of integer equations:

$\begin{equation*} \left\{\begin{array}{l} 2a_{11}^2+2a_{13}^2 = a_{11}+1, \\ 2a_{11}a_{13}+2a_{13}a_{33} = a_{13}, \\ 2a_{13}^2+2a_{33}^2 = a_{33}+1. \end{array}\right. \end{equation*}$

$Q$ has the following unique solution:

$\begin{equation*} Q_1 = \begin{pmatrix} 1&1&0&0\\ 1&1&0&0\\ 0&0&1&1\\ 0&0&1&1 \end{pmatrix}. \end{equation*}$

Since $U$ satisfies Eq (3.4), we get

$\begin{equation*} U = \begin{pmatrix} b_{11}&b_{12}&b_{13}&b_{14}\\ b_{12}&b_{11}&b_{14}&b_{13}\\ b_{13}&b_{14}&b_{33}&b_{34} \\ b_{14}&b_{13}&b_{34}&b_{33} \end{pmatrix}. \end{equation*}$

Since $U$ also satisfies Eqs (3.6) and (3.7), we obtain the solutions of $U$ by MATLAB as follows:

$\begin{array}{l} U_1 = \begin{pmatrix} 0&1&1&1 \\ 1&0&1&1 \\ 1&1&0&1 \\ 1&1&1&0\end{pmatrix}, \quad U_2 = \begin{pmatrix} 0&1&1&1 \\ 1&0&1&1 \\ 1&1&1&0 \\ 1&1&0&1\end{pmatrix}, \quad U_3 = \begin{pmatrix}1&0&1&1 \\ 0&1&1&1 \\ 1&1&1&0 \\ 1&1&0&1\end{pmatrix}, \quad U_4 = \begin{pmatrix}1&0&1&1\\ 0&1&1&1 \\ 1&1&0&1 \\ 1&1&1&0\end{pmatrix}, \\[2em] U_5 = \begin{pmatrix} 1&2&0&0 \\ 2&1&0&0 \\ 0&0&1&2 \\ 0&0&2&1\end{pmatrix}, \quad U_6 = \begin{pmatrix} 1&2&0&0 \\ 2&1&0&0 \\ 0&0&2&1 \\ 0&0&1&2\end{pmatrix}, \quad U_7 = \begin{pmatrix}2&1&0&0 \\ 1&2&0&0 \\ 0&0&1&2 \\ 0&0&2&1\end{pmatrix}, \quad U_8 = \begin{pmatrix}2&1&0&0 \\ 1&2&0&0 \\ 0&0&2&1 \\ 0&0&1&2\end{pmatrix}. \end{array}$

Clearly, $T_3$ , $Q_1$ and the solutions $U_s$ are block diagonal with at least two blocks, but the based module determined by the pair $\left (T_3, Q_1, U_t\right)$ is irreducible, denoted as $M_{4, s}$ , where $5\le s \le8, 1\le t\le4$ . Define the $\mathbb Z$ -module isomorphism $\phi$ : $M_{4, 6}\to M_{4, 8}$ by

$\begin{equation*} \phi(v_1^1) = v_4^2, \quad \phi(v_2^1) = v_3^2, \quad \phi(v_3^1) = v_2^2, \quad\phi(v_4^1) = v_1^2. \end{equation*}$

It is easy to see that $M_{4, 6}$ is equivalent to $M_{4, 8}$ as based modules over $r(S_4)$ under $\phi$ . Then, we can check that $\left \{ M_{4, s} \right \} _{5\le s \le7}$ are inequivalent irreducible based modules. □

Finally, we construct two based modules $M_{5, i}\ \left (i = 1, 2 \right)$ over $r(S_4)$ with the actions of $r(S_4)$ on them presented in Table 5.

Table 5. Inequivalent irreducible based modules of rank 5 over

$r(S_4)$ .

	$V_{\psi}$	$V_{\rho _{1}}$	$V_{\rho _{2}}$
$M_{5, 1}$	$\begin{pmatrix} 0&1&0&0&0\\ 1&0&0&0&0\\ 0&0&0&1&0\\ 0&0&1&0&0\\ 0&0&0&0&1\\ \end{pmatrix}$	$\begin{pmatrix} 0&0&0&0&1\\ 0&0&0&0&1\\ 0&0&1&1&0\\ 0&0&1&1&0\\ 1&1&0&0&1\\ \end{pmatrix}$	$\begin{pmatrix} 0&0&0&1&0\\ 0&0&1&0&0\\ 0&1&1&1&1\\ 1&0&1&1&1\\ 0&0&1&1&0\\ \end{pmatrix}$
$M_{5, 2}$	$\begin{pmatrix} 0&1&0&0&0\\ 1&0&0&0&0\\ 0&0&0&1&0\\ 0&0&1&0&0\\ 0&0&0&0&1\\ \end{pmatrix}$	$\begin{pmatrix} 1&1&0&0&0\\ 1&1&0&0&0\\ 0&0&1&1&0\\ 0&0&1&1&0\\ 0&0&0&0&2\\ \end{pmatrix}$	$\begin{pmatrix} 0&0&0&1&1\\ 0&0&1&0&1\\ 0&1&0&0&1\\ 1&0&0&0&1\\ 1&1&1&1&1\\ \end{pmatrix}$

| Show Table

DownLoad: CSV

Proposition 3.5. Let $M$ be an irreducible based module of rank $5$ over $r(S_4)$ . Then $M$ is equivalent to one of the based modules $M_{5, i}\, (i = 1, 2)$ , listed in Table 5.

Proof. Let $M$ be a based module of rank 5 over $r(S_4)$ , with the action of $r(S_4)$ on it given by

$\begin{equation*} V_{\psi} \mapsto T, \quad V_{\rho _{1}}\mapsto Q = (a_{ij})_{1\leq i, j\leq5} , \quad V_{\rho _{2}}\mapsto U = (b_{ij})_{1\leq i, j\leq5}, \quad V_{\rho _{3}}\mapsto W = TU, \end{equation*}$

where $a_{ij} = a_{ji}$ , $b_{ij} = b_{ji}$ .

First, by a similar argument applied in the case of rank 4, we only need to deal with one of the following 3 cases for $T$ :

$\begin{equation*} T_1 = E_5, \quad T_2 = (12) , \quad T_3 = (12)(34) . \end{equation*}$

Case 1. $T = T_1 = E_5$ .

There are 11 solutions of $Q$ satisfying Eq (3.5), but only two conjugacy classes by permutation matrices with their representatives given as follows:

$\begin{equation*} Q_1 = \begin{pmatrix} 0&1&1&0&0 \\ 1&0&1&0&0 \\ 1&1&0&0&0 \\ 0&0&0&2&0 \\ 0&0&0&0&2 \end{pmatrix}, \quad Q_2 = \begin{pmatrix} 2&0&0&0&0 \\ 0&2&0&0&0 \\ 0&0&2&0&0 \\ 0&0&0&2&0 \\ 0&0&0&0&2 \end{pmatrix}. \end{equation*}$

Next, we calculate $U$ after taking $Q$ as one $Q_k$ $\left (k = 1, 2 \right)$ .

Case 1.1. $Q = Q_1$ .

There are 4 solutions of $U$ satisfying Eqs (3.6) and (3.7) as follows:

$\begin{equation*} U_1 = \begin{pmatrix} 0&0&0&1&0 \\ 0&0&0&1&0 \\ 0&0&0&1&0 \\ 1&1&1&2&0 \\ 0&0&0&0&3 \end{pmatrix}, \ \ U_2 = \begin{pmatrix} 0&0&0&0&1 \\ 0&0&0&0&1 \\ 0&0&0&0&1 \\ 0&0&0&3&0 \\ 1&1&1&0&2 \end{pmatrix}, \ \ U_3 = \begin{pmatrix} 1&1&1&0&0 \\ 1&1&1&0&0 \\ 1&1&1&0&0 \\ 0&0&0&3&0 \\ 0&0&0&0&3 \\ \end{pmatrix}, \ \ U_4 = \begin{pmatrix} 1&1&1&0&0 \\ 1&1&1&0&0 \\ 1&1&1&0&0 \\ 0&0&0&1&2 \\ 0&0&0&2&1 \end{pmatrix}. \end{equation*}$

Case 1.2. $Q = Q_2$ .

There are 31 solutions of $U$ satisfying Eqs (3.6) and (3.7), but only 4 conjugacy classes by permutation matrices and their representatives as follows:

$\begin{equation*} U_1 = \begin{pmatrix} 0&1&1&1&0 \\ 1&0&1&1&0 \\ 1&1&0&1&0 \\ 1&1&1&0&0 \\ 0&0&0&0&3 \end{pmatrix}, \ \ U_2 = \begin{pmatrix} 1&0&0&2&0 \\ 0&1&2&0&0 \\ 0&2&1&0&0 \\ 2&0&0&1&0 \\ 0&0&0&0&3 \end{pmatrix}, \ \ U_3 = \begin{pmatrix} 1&2&0&0&0 \\ 2&1&0&0&0 \\ 0&0&3&0&0 \\ 0&0&0&3&0 \\ 0&0&0&0&3 \\ \end{pmatrix}, \ \ U_4 = \begin{pmatrix} 3&0&0&0&0 \\ 0&3&0&0&0 \\ 0&0&3&0&0 \\ 0&0&0&3&0 \\ 0&0&0&0&3 \end{pmatrix}. \end{equation*}$

Each pair $(T_1, Q_k, U_r)$ above determines a based module, but is not irreducible for any $1\le r\le4$ .

Case 2. $T = T_2 = (12)$ .

There are 5 solutions of $Q$ satisfying Eq (3.5), but only 3 conjugacy classes with the following representatives:

$\begin{equation*} Q_1 = \begin{pmatrix} 0&0&0&0&1 \\ 0&0&0&0&1 \\ 0&0&2&0&0 \\ 0&0&0&2&0 \\ 1&1&0&0&1 \end{pmatrix}, \quad Q_2 = \begin{pmatrix} 1&1&0&0&0 \\ 1&1&0&0&0 \\ 0&0&0&1&1 \\ 0&0&1&0&1 \\ 0&0&1&1&0 \end{pmatrix}, \quad Q_3 = \begin{pmatrix} 1&1&0&0&0 \\ 1&1&0&0&0 \\ 0&0&2&0&0 \\ 0&0&0&2&0 \\ 0&0&0&0&2 \end{pmatrix}. \end{equation*}$

Next, we calculate $U$ after choosing $Q$ .

Case 2.1. $Q = Q_1$ .

There are 4 solutions of $U$ satisfying Eqs (3.6) and (3.7) as follows:

$\begin{equation*} U_1 = \begin{pmatrix} 0&1&0&0&1 \\ 1&0&0&0&1 \\ 0&0&1&2&0 \\ 0&0&2&1&0 \\ 1&1&0&0&2 \end{pmatrix}, \ \ U_2 = \begin{pmatrix} 0&1&0&0&1 \\ 1&0&0&0&1 \\ 0&0&3&0&0 \\ 0&0&0&3&0 \\ 1&1&0&0&2 \end{pmatrix}, \ \ U_3 = \begin{pmatrix} 1&0&0&0&1 \\ 0&1&0&0&1 \\ 0&0&1&2&0 \\ 0&0&2&1&0 \\ 1&1&0&0&2 \\ \end{pmatrix}, \ \ U_4 = \begin{pmatrix} 1&0&0&0&1 \\ 0&1&0&0&1 \\ 0&0&3&0&0 \\ 0&0&0&3&0 \\ 1&1&0&0&2 \end{pmatrix}. \end{equation*}$

Case 2.2. $Q = Q_2$ .

There are 2 solutions of $U$ satisfying Eqs (3.6) and (3.7) as follows:

$\begin{equation*} U_1 = \begin{pmatrix} 1&2&0&0&0 \\ 2&1&0&0&0 \\ 0&0&1&1&1 \\ 0&0&1&1&1 \\ 0&0&1&1&1 \end{pmatrix}, \ \ U_2 = \begin{pmatrix} 2&1&0&0&0 \\ 1&2&0&0&0 \\ 0&0&1&1&1 \\ 0&0&1&1&1 \\ 0&0&1&1&1 \end{pmatrix}. \end{equation*}$

Case 2.3. $Q = Q_3$ .

There are 14 solutions of $U$ satisfying Eqs (3.6) and (3.7), but only 6 conjugacy classes by permutation matrices with their representatives given as follows:

$\begin{array}{l} U_1 = \begin{pmatrix} 0&1&1&1&0 \\ 1&0&1&1&0 \\ 1&1&0&1&0 \\ 1&1&1&0&0 \\ 0&0&0&0&3 \end{pmatrix}, \quad U_2 = \begin{pmatrix} 1&0&1&1&0 \\ 0&1&1&1&0 \\ 1&1&0&1&0 \\ 1&1&1&0&0 \\ 0&0&0&0&3 \end{pmatrix}, \quad U_3 = \begin{pmatrix} 1&2&0&0&0 \\ 2&1&0&0&0 \\ 0&0&1&2&0 \\ 0&0&2&1&0 \\ 0&0&0&0&3 \end{pmatrix}, \\[3em] U_4 = \begin{pmatrix} 2&1&0&0&0 \\ 1&2&0&0&0 \\ 0&0&1&2&0 \\ 0&0&2&1&0 \\ 0&0&0&0&3 \end{pmatrix}, \quad U_5 = \begin{pmatrix} 1&2&0&0&0 \\ 2&1&0&0&0 \\ 0&0&3&0&0 \\ 0&0&0&3&0 \\ 0&0&0&0&3 \\ \end{pmatrix}, \quad U_6 = \begin{pmatrix} 2&1&0&0&0 \\ 1&2&0&0&0 \\ 0&0&3&0&0 \\ 0&0&0&3&0 \\ 0&0&0&0&3 \end{pmatrix}. \end{array}$

Through analysis, all based modules derived from Case 2 are reducible.

Case 3. $T = T_3 = (12)(34)$ .

There are 3 solutions of $Q$ satisfying Eq (3.5) as follows:

$\begin{equation*} Q_1 = \begin{pmatrix} 0&0&0&0&1 \\ 0&0&0&0&1 \\ 0&0&1&1&0 \\ 0&0&1&1&0 \\ 1&1&0&0&1 \end{pmatrix}, \quad Q_2 = \begin{pmatrix} 1&1&0&0&0 \\ 1&1&0&0&0 \\ 0&0&1&1&0 \\ 0&0&1&1&0 \\ 0&0&0&0&2 \end{pmatrix}, \quad Q_3 = \begin{pmatrix} 1&1&0&0&0 \\ 1&1&0&0&0 \\ 0&0&0&0&1 \\ 0&0&0&0&1 \\ 0&0&1&1&1 \end{pmatrix}. \end{equation*}$

Next, we calculate $U$ after fixing $Q$ .

Case 3.1. $Q = Q_1$ .

There are 6 solutions of $U$ satisfying Eqs (3.6) and (3.7) as follows:

$\begin{array}{l} U_1 = \begin{pmatrix} 0&0&0&1&0 \\ 0&0&1&0&0 \\ 0&1&1&1&1 \\ 1&0&1&1&1 \\ 0&0&1&1&0 \end{pmatrix}, \quad U_2 = \begin{pmatrix} 0&0&1&0&0 \\ 0&0&0&1&0 \\ 1&0&1&1&1 \\ 0&1&1&1&1 \\ 0&0&1&1&0 \end{pmatrix}, \quad U_3 = \begin{pmatrix} 0&1&0&0&1 \\ 1&0&0&0&1 \\ 0&0&1&2&0 \\ 0&0&2&1&0 \\ 1&1&0&0&2 \end{pmatrix}, \\[3em] U_4 = \begin{pmatrix} 0&1&0&0&1 \\ 1&0&0&0&1 \\ 0&0&2&1&0 \\ 0&0&1&2&0 \\ 1&1&0&0&2 \end{pmatrix}, \quad U_5 = \begin{pmatrix} 1&0&0&0&1 \\ 0&1&0&0&1 \\ 0&0&1&2&0 \\ 0&0&2&1&0 \\ 1&1&0&0&2 \\ \end{pmatrix}, \quad U_6 = \begin{pmatrix} 1&0&0&0&1 \\ 0&1&0&0&1 \\ 0&0&2&1&0 \\ 0&0&1&2&0 \\ 1&1&0&0&2 \end{pmatrix}. \end{array}$

Each pair $(T_3, Q_1, U_r)$ $\left (1\le r\le6 \right)$ above determines a based module, but only the based modules with representation matrices $U_1$ and $U_2$ are irreducible. Such two irreducible based modules are denoted by $M_{5, 1}$ and $M'_{5, 1}$ , with the corresponding $\mathbb Z$ -basis $\left \{ v_1^k, v_2^k, v_3^k, v_4^k, v_5^k\right \}$ for $k = 1, 2$ , respectively. Define the $\mathbb Z$ -module isomorphism $\phi$ : $M_{5, 1}\to M'_{5, 1}$ by

$\begin{equation*} \phi(v_s^1) = v_s^2, \quad \phi(v_3^1) = v_4^2, \quad \phi(v_4^1) = v_3^2, \quad s = 1, 2, 5. \end{equation*}$

Then it is easy to see that $M_{5, 1}$ is equivalent to $M'_{5, 1}$ as based modules over $r(S_4)$ under $\phi$ .

Case 3.2. $Q = Q_2$ .

There are 10 solutions of $U$ satisfying Eqs (3.6) and (3.7), but only 7 conjugacy classes with their representatives given as follows:

$\begin{array}{l} U_1 = \begin{pmatrix} 0&0&0&1&1 \\ 0&0&1&0&1 \\ 0&1&0&0&1 \\ 1&0&0&0&1 \\ 1&1&1&1&1 \end{pmatrix}, \ \ U_2 = \begin{pmatrix} 0&1&1&1&0 \\ 1&0&1&1&0 \\ 1&1&0&1&0 \\ 1&1&1&0&0 \\ 0&0&0&0&3 \\ \end{pmatrix}, \ \ U_3 = \begin{pmatrix} 0&1&1&1&0 \\ 1&0&1&1&0 \\ 1&1&1&0&0 \\ 1&1&0&1&0 \\ 0&0&0&0&3 \\ \end{pmatrix}, \ \ U_4 = \begin{pmatrix} 1&0&1&1&0 \\ 0&1&1&1&0 \\ 1&1&1&0&0 \\ 1&1&0&1&0 \\ 0&0&0&0&3 \\ \end{pmatrix}, \end{array}$

$\begin{array}{l} U_5 = \begin{pmatrix} 1&2&0&0&0 \\ 2&1&0&0&0 \\ 0&0&1&2&0 \\ 0&0&2&1&0 \\ 0&0&0&0&3 \end{pmatrix}, \ \ U_6 = \begin{pmatrix} 1&2&0&0&0 \\ 2&1&0&0&0 \\ 0&0&2&1&0 \\ 0&0&1&2&0 \\ 0&0&0&0&3 \end{pmatrix}, \ \ U_7 = \begin{pmatrix} 2&1&0&0&0 \\ 1&2&0&0&0 \\ 0&0&2&1&0 \\ 0&0&1&2&0 \\ 0&0&0&0&3 \end{pmatrix}. \end{array}$

Each pair $(T_3, Q_2, U_t)$ $\left (2\le t\le7 \right)$ above determines a based module, but only the based module with representation matrix $U_1$ is irreducible. We denote it by $M_{5, 2}$ .

Also, the based modules obtained by taking $Q = Q_3$ are equivalent to the based module $M_{5, 1}$ found in Case 3.1. □

4. Categorified based modules by module categories over ${ Rep}(S_4)$

In this section, we will apply the knowledge of module categories over the complex representation category of a finite group to find which based modules over $r(S_4)$ can be categorified by module categories over the representation category ${\rm Rep}(S_4)$ of $S_4$ . For the details about module categories over tensor categories, see, e.g., [32, Section 7].

First, we recall the required result for the upcoming discussion. For any finite group $G$ , the second cohomology group $H^2(G, {{\mathbb C}}^*)$ is known to be a finite abelian group called the Schur multiplier and classifies central extensions of $G$ . The notion of a universal central extension of a finite group was first investigated by Schur in ^[34].

Let ${\rm Rep}(G, \alpha)$ denote the semisimple abelian category of projective representations of $G$ with the multiplier $\alpha\in Z^2(G, {{\mathbb C}}^*)$ . Equivalently, ${\rm Rep}(G, \alpha)$ is the representation category of the twisted group algebra ${{\mathbb C}} G_\alpha$ of $G$ with multiplication

$g\cdot_\alpha h = \alpha(g, h)gh, \quad g, h\in G.$

In particular,

${\rm Rep}(G, \alpha) = {\rm Rep}(G),$

when taking $\alpha = 1$ .

Let $\alpha \in Z^2(G, {{\mathbb C}}^*)$ represent an element of order $d$ in $H^2(G, {{\mathbb C}}^*)$ . Define

${\rm Rep}^\alpha(G) = \bigoplus \limits_{j = 0}^{d-1}{\rm Rep}(G, \alpha^j).$

According to the result in ^[35], we know that ${\rm Rep}^\alpha(G)$ becomes a fusion category with the tensor product of two projective representations in ${\rm Rep}(G, \alpha^i)$ and ${\rm Rep}(G, \alpha^j)$ respectively lying in ${\rm Rep}(G, \alpha^{i+j})$ , and the dual object in ${\rm Rep}(G, \alpha^i)$ lying in ${\rm Rep}(G, \alpha^{d-i})$ . Correspondingly, we have the fusion ring

$\begin{equation} r^\alpha(G) = \bigoplus \limits_{j = 0}^{d-1}r(G, \alpha^j). \end{equation}$

(4.1)

Now let $H$ be a subgroup of $G$ and $\alpha \in Z^2(H, {{\mathbb C}}^*)$ . The category ${\rm Rep}(H, \alpha)$ is a module category over ${\rm Rep}(G)$ by applying the restriction functor ${\rm Res}_H^{G}$ : ${\rm Rep}(G)\to {\rm Rep}(H)$ .

Theorem 4.1. [, Theorem 3.2] The indecomposable exact module categories over the representation category ${\rm Rep}(G)$ are of the form ${\rm Rep}(H, \alpha)$ and are classified by conjugacy classes of pairs $(H, [\alpha])$ .

Consequently, by [32, Proposition 7.7.2], we know the following:

Proposition 4.1. The Grothendieck group

$r(H, \alpha) = {\rm Gr}({\rm Rep}(H, \alpha))$

is an irreducible $\mathbb{Z}_+$ -module over $r(G)$ .

Next, we show that any $\mathbb{Z}_+$ -module over the complex representation ring $r(G)$ of a finite group $G$ categorified in this way is a based module.

Theorem 4.2. Let $G$ be a finite group, $H$ a subgroup of $G$ , and $\alpha \in Z^2(H, {{\mathbb C}}^*)$ . The $\mathbb{Z}_+$ -module $r(H, \alpha)$ over $r(G)$ is a based module.

Proof. Let $\left \{ {\psi}_i \right \} _{i\in I}$ be the $\mathbb{Z}_+$ -basis of $r(G)$ . Take $r^\alpha(H)$ defined in Eq (4.1) as a $\mathbb{Z}_+$ -module over $r(G)$ with the $\mathbb{Z}$ -basis $\left \{ {\chi}_k \right \} _{k\in J}$ such that

$\psi_i.\chi_k = \sum\limits_l a_{ik}^l \chi_l, \quad a_{ik}^l\in \mathbb{Z}_+.$

On the other hand, we write the fusion rule of the fusion ring $r^\alpha(H)$ as follows:

$\begin{equation*} \chi_i\chi_j = \sum\limits_{k = 1}^{s} n_{ij}^k\chi_k, \quad n_{ij}^k\in \mathbb{Z}_+. \end{equation*}$

Since the number $n_{ij}^{k^*}$ is invariant under cyclic permutations of $i, j, k$ , we have

$n_{ij}^k = n_{k^*i}^{j^*} = n_{i^*k}^{j}.$

By the restriction rule, we interpret $r(G)$ as a subring of $r^\alpha(H)$ and write down

$\psi_i = \sum\limits_j r_{ij} \chi_j, \quad r_{ij}\in \mathbb{Z}_+.$

Then

$\psi_i.\chi_k = \sum\limits_j r_{ij} \chi_j\chi_k = \sum\limits_{j, \, l} r_{ij}n_{jk}^l \chi_l.$

By comparing the coefficients, we see that

$a_{ik}^l = \sum\limits_{j} r_{ij}n_{jk}^l = \sum\limits_{j} r_{ij}n_{j^*l}^k = \sum\limits_{j} r_{i^*j^*}n_{j^*l}^k = \sum\limits_{j} r_{i^*j}n_{jl}^k = a_{i^*l}^k,$

so $r^\alpha(H)$ is a based module over $r(G)$ , and $r(H, \alpha)$ is clearly a based submodule of $r^\alpha(H)$ . Equivalently, any $\mathbb{Z}_+$ -module over $r(G)$ categorified by a module category ${\rm Rep}(H, \alpha)$ over ${\rm Rep}(G)$ must be a based module. □

By Theorem 4.2, we only need to focus on those inequivalent irreducible based modules $M_{i, j}$ over $r(S_4)$ collected in Section 3, each of which is possibly categorified by a module category ${\rm Rep}(H, \alpha)$ for some $H < S_4$ and $\alpha \in Z^2(H, {{\mathbb C}}^*)$ .

All the non-isomorphic subgroups of the symmetric group $S_4$ are as follows:

$({\rm{i}})$ The symmetric group $S_3$ ;

$({\rm{ii}})$ The cyclic groups $\mathbb Z_i, \, 1\leq i\leq 4$ ;

$({\rm{iii}})$ The Klein 4-group $K_4$ ;

$({\rm{iv}})$ The alternating group $A_4$ ;

$({\rm{v}})$ The dihedral group $D_4$ ;

$({\rm{vi}})$ The symmetric group $S_4$ itself.

Correspondingly, the Schur multipliers we consider here are given as follows (see e.g., ^[36]):

$H^2(\mathbb Z_n, {{\mathbb C}}^*)\cong H^2(S_3, {{\mathbb C}}^*)\cong 0, \ n\geq 1, \quad \ H^2(K_4, {{\mathbb C}}^*)\cong H^2(D_4, {{\mathbb C}}^*)\cong H^2(A_4, {{\mathbb C}}^*)\cong H^2(S_4, {{\mathbb C}}^*)\cong\mathbb Z_2.$

As a result, we only need to consider the following two situations:

(1) Module category ${\rm Rep}(H)$ for any subgroup $H < S_4$ ;

(2) Module category ${\rm Rep}(H, \alpha)$ for any subgroup $H < S_4$ and nontrivial twist $\alpha \in Z^2(H, {{\mathbb C}}^*)$ .

4.1. The module categories over ${ Rep}(S_4)$ with trivial twists

(ⅰ) First, we consider the representation category ${\rm Rep}(S_3)$ as a module category over ${\rm Rep}(S_4)$ .

Theorem 4.3. $r(S_3) = {\rm Gr}({\rm Rep}(S_3))$ is an irreducible based module over $r(S_4) = {\rm Gr}({\rm Rep}(S_4))$ equivalent to the based module $M_{3, 2}$ in Table 3.

Proof. According to the branching rule of symmetric groups (see e.g., [37, Theorem 2.8.3]), we have the following restriction rules:

$\begin{align*} {\rm Res}_{S_3}^{S_4} \left ( 1 \right ) = 1, \; \; \; {\rm Res}_{S_3}^{S_4} \left ( V_{\psi} \right ) = \chi, \; \; \; {\rm Res}_{S_3}^{S_4} \left ( V_{\rho_{1}} \right ) = V, \; \; \; {\rm Res}_{S_3}^{S_4} \left ( V_{\rho_{2}} \right ) = 1+V, \; \; \; {\rm Res}_{S_3}^{S_4} \left ( V_{\rho_{3}} \right ) = \chi+V, \end{align*}$

where $\chi$ and $V$ denote the sign representation and the standard representation in ${\rm Rep}({S_3})$ , respectively. Hence, we get the representation matrices of basis elements of $r(S_4)$ acting on $r({S_3})$ as follows:

$\begin{align*} 1 \mapsto E_3, \quad V_{\psi} \mapsto \begin{pmatrix}0& 1 &0 \\1&0 &0 \\0&0 &1\end{pmatrix}, \quad V_{\rho _{1}}\mapsto \begin{pmatrix}0& 0 &1 \\0& 0 &1 \\1& 1&1 \end{pmatrix}, \quad V_{\rho _{2}}\mapsto \begin{pmatrix}1& 0 &1 \\0& 1 &1 \\1& 1&2 \end{pmatrix}, \quad V_{\rho _{3}}\mapsto \begin{pmatrix}0& 1 &1 \\1& 0 &1 \\1& 1&2 \end{pmatrix}. \end{align*}$

We see that $r(S_3)$ is an irreducible based module $M_{3, 2}$ according to . In other words, the based module $M_{3, 2}$ can be categorified by the module category ${\rm Rep}({S_3})$ over ${\rm Rep}(S_4)$ . □

Remark 4.1. Since the roles of the standard representation and its dual in $r(S_4)$ are symmetric, we can exchange the notations $V_{\rho_{2}}$ and $V_{\rho_{3}}$ for them to get the following restriction rules instead:

$\begin{equation*} {\rm Res}_{S_3}^{S_4} \left ( V_{\rho_{2}} \right ) = \chi+V, \quad {\rm Res}_{S_3}^{S_4} \left ( V_{\rho_{3}} \right ) = 1+V. \end{equation*}$

Therefore, we get another action of $r(S_4)$ on $r({S_3})$ such that $r(S_3)$ is an irreducible based module over $r(S_4)$ equivalent to the based module $M_{3, 3}$ according to . In other words, the based module $M_{3, 3}$ can also be categorified by the module category ${\rm Rep}({S_3})$ over ${\rm Rep}(S_4)$ .

(ⅱ) Second, we consider ${\rm Rep}(\mathbb{Z}_4)$ as a module category over ${\rm Rep}(S_4)$ .

Theorem 4.4. $r(\mathbb{Z}_4) = {\rm Gr}({\rm Rep}(\mathbb{Z}_4))$ is an irreducible based module over $r(S_4)$ equivalent to the based module $M_{4, 5}$ in Table 4.

Proof. Let

$\mathbb{Z}_4 = \left \{ 1, g, g^2, g^3 \right \}$

be the cyclic group of order $4$ , with four non-isomorphic 1-dimensional irreducible representations denoted by $U_i, \, i = 0, 1, 2, 3$ . Let $U_0 = 1$ represent the trivial representation, and

$\begin{equation*} \chi_{U_1}(g) = \sqrt{-1} , \quad \chi_{U_2}(g) = -1, \quad\chi_{U_3}(g) = -\sqrt{-1}. \end{equation*}$

On the other hand, we consider $\mathbb{Z}_4$ as the subgroup of $S_4$ generated by $g = (1234)$ . Then, by the character table of $S_4$ (Table 1), we have

$\begin{align*} \chi_\psi(g^i)& = (-1)^i, \quad \chi_{\rho_1}(g^i) = 1+(-1)^i, \\ \chi_{\rho_2}(g^i)& = (-1)^i+(\sqrt{-1})^i+(-\sqrt{-1})^i, \\ \chi_{\rho_3}(g^i)& = 1+(\sqrt{-1})^i+(-\sqrt{-1})^i. \end{align*}$

So, the restriction rule of $r(S_4)$ on $r(\mathbb{Z}_4)$ is given as follows:

$\begin{align*} {\rm Res}_{\mathbb{Z}_4}^{S_4} \left ( 1 \right )& = 1, \quad {\rm Res}_{\mathbb{Z}_4}^{S_4} \left ( V_{\psi} \right ) = U_2, \quad {\rm Res}_{\mathbb{Z}_4}^{S_4} \left ( V_{\rho_{1}} \right ) = 1+U_2, \\ {\rm Res}_{\mathbb{Z}_4}^{S_4} \left ( V_{\rho_{2}} \right )& = U_1+U_2+U_3, \quad\quad{\rm Res}_{\mathbb{Z}_4}^{S_4} \left ( V_{\rho_{3}} \right ) = 1+U_1+U_3. \end{align*}$

Then, we get the representation matrices of basis elements of $r(S_4)$ acting on $r(\mathbb{Z}_4)$ as follows:

$\begin{align*} &1 \mapsto E_4, \space V_{\psi} \mapsto \begin{pmatrix}0& 0 &1 &0\\0& 0 &0&1\\1& 0&0&0\\0&1&0&0\end{pmatrix}, \space V_{\rho _{1}}\mapsto \begin{pmatrix}1&0&1&0\\0&1&0&1\\1&0&1&0\\0&1&0&1\end{pmatrix}, \space &V_{\rho _{2}}\mapsto \begin{pmatrix}0&1&1&1\\1&0&1&1\\1&1&0&1\\1&1&1&0 \end{pmatrix}, \space V_{\rho_{3}}\mapsto \begin{pmatrix}1&1&0&1\\1&1&1&0\\0&1&1&1\\1&0&1&1\end{pmatrix}. \end{align*}$

Let $\left \{ w_i\right \}_{1\leq i\leq 4}$ be the stated $\mathbb{Z}$ -basis of $M_{4, 5}$ , and define a $\mathbb{Z}$ -linear map $\varphi$ : $M_{4, 5}\to r(\mathbb{Z}_4)$ by

$\begin{equation*} \varphi (w_1) = U_3, \quad \varphi (w_2) = U_1, \quad \varphi (w_3) = U_2, \quad\varphi (w_4) = 1. \end{equation*}$

Then, it is easy to check that $\varphi$ is an isomorphism of $r(S_{4})$ -modules, so $M_{4, 5}$ is equivalent to $r(\mathbb{Z}_4)$ as based modules by Definition 2.4 (ⅰ). In other words, the based module $M_{4, 5}$ can be categorified by the module category ${\rm Rep}(\mathbb{Z}_4)$ over ${\rm Rep}(S_4)$ . □

Remark 4.2. By the same argument as in Remark 4.1, $V_{\rho _{2}}$ and $V_{\rho _{3}}$ can be required to satisfy the following restriction rules instead:

$\begin{equation*} {\rm Res}_{\mathbb{Z}_4}^{S_4} \left ( V_{\rho_{2}} \right ) = 1+U_1+U_3, \quad{\rm Res}_{\mathbb{Z}_4}^{S_4} \left ( V_{\rho_{3}} \right ) = U_1+U_2+U_3. \end{equation*}$

Therefore, we get another action of $r(S_4)$ on $r({\mathbb{Z}_4})$ such that $r(\mathbb{Z}_4)$ is an irreducible based module over $r(S_4)$ equivalent to the based module $M_{4, 7}$ according to . In other words, the based module $M_{4, 7}$ can also be categorified by the module category ${\rm Rep}(\mathbb{Z}_4)$ over ${\rm Rep}(S_4)$ .

Also, one can similarly check that the module category ${\rm Rep}(\mathbb{Z}_2)$ over ${\rm Rep}(S_4)$ categorifies the based modules $M_{2, 2}$ and $M_{2, 3}$ , while ${\rm Rep}(\mathbb{Z}_3)$ over ${\rm Rep}(S_4)$ categorifies the based module $M_{3, 1}$ .

(ⅲ) Now we consider ${\rm Rep}(K_4)$ as a module category over ${\rm Rep}(S_4)$ .

Theorem 4.5. $r(K_4) = {\rm Gr}({\rm Rep}(K_4))$ is an irreducible based module over $r(S_4)$ equivalent to the based module $M_{4, 7}$ in Table 4.

Proof. We consider $K_4$ as the subgroup of $S_4$ generated by $(12)$ and $(34)$ , and it has four non-isomorphic 1-dimensional irreducible representations $Y_0 = 1$ and $Y_1, Y_2, Y_3$ such that

$\begin{align*} &\chi_{Y_1}((12)) = -1, \quad \chi_{Y_1}((34)) = 1;\quad\; \; \chi_{Y_2}((12)) = 1, \\ &\chi_{Y_2}((34)) = -1;\quad \chi_{Y_3}((12)) = -1, \quad \chi_{Y_3}((34)) = -1. \end{align*}$

On the other hand, by the character table of $S_4$ (Table 1), we have

$\begin{align*} &\chi_\psi((12)) = \chi_\psi((34)) = -1, \quad \chi_\psi((12)(34)) = 1;\\ &\chi_{\rho_1}((12)) = \chi_{\rho_1}((34)) = 0, \quad \chi_{\rho_1}((12)(34)) = 2;\\ &\chi_{\rho_2}((12)) = \chi_{\rho_2}((34)) = 1, \quad \chi_{\rho_2}((12)(34)) = -1;\\ &\chi_{\rho_3}((12)) = \chi_{\rho_3}((34)) = -1, \quad \chi_{\rho_3}((12)(34)) = -1. \end{align*}$

So, we have the following restriction rules:

$\begin{align*} {\rm Res}_{K_4}^{S_4} \left ( 1 \right )& = 1, \quad {\rm Res}_{K_4}^{S_4} \left ( V_{\psi} \right ) = Y_3, \quad {\rm Res}_{K_4}^{S_4} \left ( V_{\rho_{1}} \right ) = 1+Y_3, \\ {\rm Res}_{K_4}^{S_4} \left ( V_{\rho_{2}} \right )& = 1+Y_1+Y_2, \quad\quad {\rm Res}_{K_4}^{S_4} \left ( V_{\rho_{3}} \right ) = Y_1+Y_2+Y_3. \end{align*}$

Then we get the representation matrices of basis elements of $r(S_4)$ acting on $r(K_4)$ as follows:

$\begin{align*} &1 \mapsto E_4, \quad V_{\psi} \mapsto \begin{pmatrix}0& 0 &0 &1\\0& 0 &1&0 \\0&1&0&0\\1&0&0&0\end{pmatrix}, \quad V_{\rho _{1}}\mapsto \begin{pmatrix}1&0&0&1\\0&1&1&0\\0&1&1&0\\1&0&0&1 \end{pmatrix}, \\ &V_{\rho _{2}}\mapsto \begin{pmatrix}1&1&1&0\\1&1&0&1\\1&0&1&1\\0&1&1&1\end{pmatrix}, \quad\quad V_{\rho_{3}}\mapsto \begin{pmatrix}0&1&1&1\\1&0&1&1\\1&1&0&1\\1&1&1&0 \end{pmatrix}. \end{align*}$

Let $\left \{ w_i\right \}_{1\leq i\leq 4}$ be the stated $\mathbb{Z}$ -basis of $M_{4, 7}$ listed in Table 4. Then

$\begin{equation*} w_1\mapsto Y_2, \quad w_2\mapsto Y_1, \quad w_3\mapsto 1, \quad w_4\mapsto Y_3, \end{equation*}$

defines an equivalence of $\mathbb{Z}_+$ -modules between $M_{4, 7}$ and $r(K_4)$ . In other words, the irreducible based module $M_{4, 7}$ can be categorified by the module category ${\rm Rep}(K_4)$ over ${\rm Rep}(S_4)$ . □

Remark 4.3. In a manner analogous to the argument in Remark 4.1, it follows that the irreducible based module $M_{4, 5}$ can also be categorified by the module category ${\rm Rep}(K_4)$ over ${\rm Rep}(S_4)$ .

(ⅳ) We consider ${\rm Rep}(A_4)$ as a module category over ${\rm Rep}(S_4)$ .

Theorem 4.6. $r(A_4) = {\rm Gr}({\rm Rep}(A_4))$ is an irreducible based module over $r(S_4)$ equivalent to the based module $M_{4, 1}$ in Table 4.

Proof. We know that $A_4$ has three non-isomorphic 1-dimensional irreducible representations and one 3-dimensional irreducible representation, denoted by $N_0, N_1, N_2$ , and $N_3$ , respectively, where $N_0 = 1$ represents the trivial representation, and

$\begin{align*} &\chi_{N_1}((123)) = \omega , \quad \chi_{N_1}((12)(34)) = 1;\quad \chi_{N_2}((123)) = \omega^2, \quad \chi_{N_2}((12)(34)) = 1;\\ &\chi_{N_3}((123)) = \chi_{N_3}((132)) = 0, \quad\ \chi_{N_3}((12)(34)) = -1, \quad\ \omega = \frac{-1+\sqrt{-3} }{2}. \end{align*}$

On the other hand, the character table of $S_4$ (Table 1) tells us that

$\begin{align*} &\chi_\psi((123)) = 1, \quad\; \; \chi_\psi((12)(34)) = 1;\quad \chi_{\rho_1}((123)) = -1, \quad \chi_{\rho_1}((12)(34)) = 2;\\ &\chi_{\rho_2}((123)) = 0, \quad \chi_{\rho_2}((12)(34)) = -1;\quad \chi_{\rho_3}((123)) = 0, \quad \chi_{\rho_3}((12)(34)) = -1. \end{align*}$

So, we have the following restriction rules:

$\begin{align*} {\rm Res}_{A_4}^{S_4} \left ( 1 \right ) = {\rm Res}_{A_4}^{S_4} \left ( V_{\psi} \right ) = 1, \quad {\rm Res}_{A_4}^{S_4} \left ( V_{\rho_{1}} \right ) = N_1+N_2, \quad {\rm Res}_{A_4}^{S_4} \left ( V_{\rho_{2}} \right ) = {\rm Res}_{A_4}^{S_4} \left ( V_{\rho_{3}} \right ) = N_3. \end{align*}$

Hence, we get the representation matrices of basis elements of $r(S_4)$ acting on $r(A_4)$ as follows:

$\begin{align*} 1 \mapsto E_4, \quad V_{\psi} \mapsto E_4, \quad V_{\rho _{1}}\mapsto \begin{pmatrix}0& 1 &1 &0\\1& 0 &1&0 \\1& 1&0&0\\0&0&0&2 \end{pmatrix}, \quad V_{\rho _{2}}, V_{\rho_{3}}\mapsto \begin{pmatrix}0& 0 &0 &1\\0& 0 &0 &1\\0& 0 &0 &1\\1&1&1&2 \end{pmatrix}. \end{align*}$

Then, $r(A_4)$ is an irreducible based module over $r(S_4)$ equivalent to $M_{4, 1}$ listed in . In other words, the irreducible based module $M_{4, 1}$ can be categorified by the module category ${\rm Rep}(A_4)$ over ${\rm Rep}(S_4)$ . □

(ⅴ) Next, we consider ${\rm Rep}(D_4)$ as a module category over ${\rm Rep}(S_4)$ .

Theorem 4.7. $r(D_4) = {\rm Gr}({\rm Rep}(D_4))$ is an irreducible based module over $r(S_4)$ equivalent to the based module $M_{5, 2}$ in Table 5.

Proof. The dihedral group

$D_4 = \langle r, s\, |\, r^4 = s^2 = (rs)^2 = 1\rangle$

has four 1-dimensional irreducible representations and one 2-dimensional irreducible representation up to isomorphism, denoted by $W_0, W_1, W_2, W_3$ , and $W_4$ , respectively. Let $W_0 = 1$ stand for the trivial representation, and

$\begin{align*} &\chi_{W_1}(r) = 1 , \quad\; \; \chi_{W_1}(s) = -1; \quad\chi_{W_2}(r) = -1, \quad \chi_{W_2}(s) = 1;\\ &\chi_{W_3}(r) = -1, \quad\chi_{W_3}(s) = -1; \quad \chi_{W_4}(r) = \chi_{W_4}(s) = \chi_{W_4}(rs) = 0. \end{align*}$

On the other hand, we consider $D_4$ as the subgroup of $S_4$ by taking $r = (1234)$ and $s = (12)(34)$ . Then $rs = (13)$ . By the character table of $S_4$ (Table 1), we have

$\begin{align*} &\chi_\psi((1234)) = -1, \quad \chi_\psi((12)(34)) = 1, \quad \chi_\psi((13)) = -1;\\ &\chi_{\rho_1}((1234)) = 0, \quad \chi_{\rho_1}((12)(34)) = 2, \quad \chi_{\rho_1}((13)) = 0;\\ &\chi_{\rho_2}((1234)) = -1, \quad \chi_{\rho_2}((12)(34)) = -1, \quad \chi_{\rho_2}((13)) = 1;\\ &\chi_{\rho_3}((1234)) = 1, \quad \chi_{\rho_3}((12)(34)) = -1, \quad \chi_{\rho_3}((13)) = -1. \end{align*}$

So, we have the following restriction rules:

$\begin{align*} {\rm Res}_{D_4}^{S_4} \left ( 1 \right )& = 1, \quad {\rm Res}_{D_4}^{S_4} \left ( V_{\psi} \right ) = W_2, \quad {\rm Res}_{D_4}^{S_4} \left ( V_{\rho_{1}} \right ) = 1+W_2, \\ {\rm Res}_{D_4}^{S_4} \left ( V_{\rho_{2}} \right )& = W_3+W_4, \quad\quad {\rm Res}_{D_4}^{S_4} \left ( V_{\rho_{3}} \right ) = W_1+W_4. \end{align*}$

Then we get the representation matrices of basis elements of $r(S_4)$ acting on $r(D_4)$ as follows:

$\begin{align*} &1 \mapsto E_5, \quad V_{\psi} \mapsto \begin{pmatrix}0& 0 &1 &0&0\\0& 0 &0&1&0 \\1& 0&0&0&0\\0&1&0&0&0\\0&0&0&0&1 \end{pmatrix}, \quad V_{\rho _{1}}\mapsto \begin{pmatrix}1&0&1&0&0\\0&1&0&1&0\\1&0&1&0&0\\0&1&0&1&0\\0&0&0&0&2 \end{pmatrix}, \\ &\; \; \; \; \; \; V_{\rho _{2}}\mapsto \begin{pmatrix}0&0&0&1&1\\0&0&1&0&1\\0&1&0&0&1\\1&0&0&0&1\\1&1&1&1&1 \end{pmatrix}, \quad V_{\rho_{3}}\mapsto \begin{pmatrix}0&1&0&0&1\\1&0&0&0&1\\0&0&0&1&1\\0&0&1&0&1\\1&1&1&1&1 \end{pmatrix}. \end{align*}$

Then $r(D_4)$ is an irreducible based module over $r(S_4)$ equivalent to $M_{5, 2}$ listed in . In other words, the irreducible based module $M_{5, 2}$ can be categorified by the module category ${\rm Rep}(D_4)$ over ${\rm Rep}(S_4)$ . □

(ⅵ) Finally, we consider ${\rm Rep}(S_4)$ as a module category over itself.

Theorem 4.8. The regular $\mathbb{Z}_+$ -module $r(S_4)$ over itself is equivalent to the irreducible based module $M_{5, 1}$ in Table 5.

Proof. Let $r(S_4)$ be the regular $\mathbb{Z}_+$ -module over itself with the $\mathbb{Z}$ -basis $\left \{ 1, V_{\psi}, V_{\rho_{1}}, V_{\rho_{2}}, V_{\rho_{3}} \right \}$ , and the action of $r(S_4)$ on it is given as follows:

$\begin{align*} &1 \mapsto E_5, \quad V_{\psi} \mapsto \begin{pmatrix} 0&1&0&0&0 \\ 1&0&0&0&0 \\ 0&0&1&0&0 \\ 0&0&0&0&1 \\ 0&0&0&1&0 \end{pmatrix}, \quad V_{\rho _{1}}\mapsto \begin{pmatrix} 0&0&1&0&0 \\ 0&0&1&0&0 \\ 1&1&1&0&0 \\ 0&0&0&1&1 \\ 0&0&0&1&1 \end{pmatrix}, \\ &\; \; \; \; \; \; \; V_{\rho _{2}}\mapsto \begin{pmatrix} 0&0&0&1&0 \\ 0&0&0&0&1 \\ 0&0&0&1&1 \\ 1&0&1&1&1 \\ 0&1&1&1&1 \end{pmatrix}, \quad V_{\rho _{3}}\mapsto \begin{pmatrix} 0&0&0&0&1 \\ 0&0&0&1&0 \\ 0&0&0&1&1 \\ 0&1&1&1&1 \\ 1&0&1&1&1 \end{pmatrix}. \end{align*}$

Then, the regular $\mathbb{Z}_+$ -module $r(S_4)$ over itself is equivalent to $M_{5, 1}$ listed in . In other words, the irreducible based module $M_{5, 1}$ over $r(S_4)$ can be categorified by the module category ${\rm Rep}(S_4)$ over itself. □

Remark 4.4. Following the argument presented in Remark 4.1, if we exchange the notations $V_{\rho _{2}}$ and $V_{\rho _{3}}$ with their restriction rules given in the proof of Theorems 4.7 and 4.8, we see that $r(D_4)$ and $r(S_4)$ are still equivalent to $M_{5, 2}$ and $M_{5, 1}$ , respectively.

4.2. The module categories over ${ Rep}(S_4)$ with nontrivial twists

Lastly, we consider the module category ${\rm Rep}(H, \alpha)$ over ${\rm Rep}(S_4)$ , where $H$ is a subgroup of $S_4$ with $\alpha$ representing the unique nontrivial cohomological class in $H^2(H, {{\mathbb C}}^*)$ . All non-isomorphic irreducible projective representations of $H$ with the multiplier $\alpha$ form a $\mathbb Z$ -basis of $r(H, \alpha)$ , whose cardinality is the number of $\alpha$ -regular conjugacy classes by [38, Theorem 6.1.1].

First, we consider the twisted group algebra of $K_4$ . There is only one irreducible projective representation with respect to $\alpha$ up to isomorphism, see, e.g., [, Appendix D.1]. Hence, $r(K_4, \alpha)$ is a based module of rank $1$ over $r(S_4)$ equivalent to $M_{1, 1}$ defined in (3.8). Namely, the based module $M_{1, 1}$ can also be categorified by ${\rm Rep}(K_4, \alpha)$ .

Second, we consider the twisted group algebra of $D_4$ .

Theorem 4.9. $r(D_4, \alpha) = {\rm Gr}({\rm Rep}(D_4, \alpha))$ is an irreducible based module over $r(S_4)$ equivalent to the based module $M_{2, 3}$ in Table 2.

Proof. Let

$D_4 = \langle r, s\, |\, r^4 = s^2 = (rs)^2 = 1\rangle .$

Let $\alpha\in Z^2(D_4, {{\mathbb C}}^*)$ be the 2-cocycle defined by

$\begin{equation} \alpha (r^is^j, r^{i'}s^{j'}) = (\sqrt{-1})^{ji'}.\nonumber \end{equation}$

Here, $i, i'\in {\left \{ 0, 1, 2, 3 \right \} }, \, j, j'\in\left \{ {0, 1} \right \}$ . As shown in [, Section 3.7], this is a unitary 2-cocycle representing the unique non-trivial cohomological class in $H^2(D_4, {{\mathbb C}}^*)$ . According to [, Section 3], there exist two (2-dimensional) non-isomorphic irreducible projective representations of $D_4$ with respect to $\alpha$ , which are given by

$\begin{equation} \begin{aligned} \pi_{l}: D_4 & \rightarrow \mathrm{GL}_{2}(\mathbb{C}), \\ r^{i} s^{j} & \mapsto A_{l}^{i} B^{j}, \end{aligned}\nonumber \end{equation}$

where

$A_l = \begin{pmatrix}(\sqrt{-1})^l &0 \\ 0&(\sqrt{-1})^{1-l}\end{pmatrix} , \; \; \; B = \begin{pmatrix}0 &1 \\1 &0\end{pmatrix} , \; \; \; l = 1, 2.$

Also, for irreducible representations $W_0$ – $W_4$ of $D_4$ mentioned in the proof of Theorem 4.7, we have

$\begin{equation} W_0\otimes \pi_l = W_1\otimes\pi_l = \pi_l, \quad W_2\otimes \pi_l = W_3\otimes \pi_l = \pi_{3-l}, \quad W_4\otimes \pi_l = \pi_1+\pi_2.\nonumber \end{equation}$

Next, using the previous restriction rule of $r(S_4)$ on $r(D_4)$ , we get the representation matrices of basis elements of $r(S_4)$ acting on $r(D_4, \alpha)$ as follows:

$\begin{equation} \begin{aligned} 1 \mapsto E_2, \quad V_{\psi} \mapsto \begin{pmatrix} 0 &1 \\ 1&0 \end{pmatrix}, \quad V_{\rho_1} \mapsto \begin{pmatrix} 1 &1 \\ 1&1 \end{pmatrix}, \quad V_{\rho_2} \mapsto \begin{pmatrix} 1&2 \\ 2&1 \end{pmatrix}, \quad V_{\rho_3} \mapsto \begin{pmatrix} 2&1 \\ 1&2 \end{pmatrix}.\nonumber \end{aligned} \end{equation}$

Then, $r(D_4, \alpha)$ is an irreducible based module over $r(S_4)$ equivalent to $M_{2, 3}$ listed in . In other words, the irreducible based module $M_{2, 3}$ can be categorified by the module category ${\rm Rep}(D_4, \alpha)$ over ${\rm Rep}(S_4)$ . □

Remark 4.5. As discussed in Remark 4.1, it follows that the irreducible based module $M_{2, 2}$ can also be categorified by the module category ${\rm Rep}(D_4, \alpha)$ over ${\rm Rep}(S_4)$ .

Next, we consider the twisted group algebras of $A_4$ and $S_4$ . By [, Theorem 6.1.1], $A_4$ has three (2-dimensional) non-isomorphic irreducible projective representations, denoted as $V_{\gamma _{1}}, V_{\gamma _{2}}$ , and $V_{\gamma _{3}}$ , respectively. Similarly, $S_4$ has two (2-dimensional) non-isomorphic irreducible projective representations $V_{\xi_1}, V_{\xi_2}$ , and one (4-dimensional) irreducible projective representation $V_{\xi_3}$ . We give the character table for projective representations of $A_4$ and $S_4$ in and , respectively, where primes are used to differentiate between the two classes splitting from a single conjugacy class of $A_4$ in its double cover $\tilde A_4$ , and the same applies to $S_4$ ; subscripts distinguish between the two classes splitting from the conjugacy classes $(31)^{'}$ and $(31)^{''}$ in the double cover $\tilde S_4$ of $S_4$ , respectively. For more details, see [41, Section 4].

Table 6. The character table for irreducible projective representations of

$A_4$ .

	$(1^4)^{'}$	$(1^4)^{''}$	$(2^2)$	$(31)^{'}_1$	$(31)^{''}_1$	$(31)^{'}_2$	$(31)^{''}_2$
$\chi_{\gamma _{1}}$	$2$	$-2$	$0$	$1$	$-1$	$1$	$-1$
$\chi_{\gamma _{2}}$	$2$	$-2$	$0$	$\omega$	$-\omega$	$\omega^2$	$-\omega^2$
$\chi_{\gamma _{3}}$	$2$	$-2$	$0$	$\omega^2$	$-\omega^2$	$\omega$	$-\omega$

| Show Table

DownLoad: CSV

Table 7. The character table for irreducible projective representations of

$S_4$ .

	$(1^4)^{'}$	$(1^4)^{''}$	$(2 1^2)$	$(2^2)$	$(3 1)^{'}$	$(31)^{''}$	$(4)^{'}$	$(4)^{''}$
$\chi_{\xi_1}$	$2$	$-2$	$0$	$0$	$1$	$-1$	$\sqrt{2}$	$-\sqrt{2}$
$\chi_{\xi_2}$	$2$	$-2$	$0$	$0$	$1$	$-1$	$-\sqrt{2}$	$\sqrt{2}$
$\chi_{\xi_3}$	$4$	$-4$	$0$	$0$	$-1$	$1$	$0$	$0$

| Show Table

DownLoad: CSV

In Table 6, we denote

$\omega = e^{2\pi\sqrt{-1}/3} = \frac{-1+\sqrt{-3}}{2}.$

Then we have the following theorems.

Theorem 4.10. $r(A_4, \alpha) = {\rm Gr}({\rm Rep}(A_4, \alpha))$ is an irreducible based module over $r(S_4)$ equivalent to the based module $M_{3, 1}$ in Table 3.

Proof. For the irreducible representations $N_0, N_1, N_2$ , and $N_3$ of $A_4$ mentioned in the proof of Theorem 4.6, we obtain the following tensor product rule in $r^\alpha(A_4)$ by computing the values of products of characters:

$\begin{align*} &N_0 \otimes V_{\gamma_i } = V_{\gamma_{i} }, \quad N_1 \otimes V_{\gamma_j } = V_{\gamma_{j+1} }, \quad N_1 \otimes V_{\gamma_3 } = V_{\gamma_{1} };\quad N_2 \otimes V_{\gamma_1 } = V_{\gamma_{3} }, \\ & N_2 \otimes V_{\gamma_2 } = V_{\gamma_{1} }, \quad\ N_2 \otimes V_{\gamma_3 } = V_{\gamma_{2} };\quad\ N_3 \otimes V_{\gamma_i } = V_{\gamma_{1} }+V_{\gamma_{2} }+V_{\gamma_{3} }, \end{align*}$

where $i = 1, 2, 3$ , $j = 1, 2$ . Next, by combining this with the previous restriction rule of $r(S_4)$ on $r(A_4)$ , we obtain

$1, V_{\psi} \mapsto E_3, \quad V_{\rho_1} \mapsto \begin{pmatrix} 0 &1 &1\\ 1 &0 &1\\ 1 &1 &0 \end{pmatrix}, \quad V_{\rho_2}, V_{\rho_3} \mapsto \begin{pmatrix} 1 &1 &1\\ 1 &1 &1\\ 1 &1 &1 \end{pmatrix}.$

Then $r(A_4, \alpha)$ is an irreducible based module over $r(S_4)$ equivalent to $M_{3, 1}$ listed in . In other words, the irreducible based module $M_{3, 1}$ can be categorified by ${\rm Rep}(A_4, \alpha)$ . □

Theorem 4.11. $r(S_4, \alpha) = {\rm Gr}({\rm Rep}(S_4, \alpha))$ is an irreducible based module over $r(S_4)$ equivalent to the based module $M_{3, 3}$ in Table 3.

Proof. Let $\alpha$ be a nontrivial 2-cocycle in $Z^2(S_4, {{\mathbb C}}^*)$ (see e.g., [, Section 3.2.4]). By checking products of characters, we get the following tensor product rule in $r^\alpha(S_4)$ :

$\begin{align*} 1 \otimes V_{\xi_i } = V_{\xi_{i} };\; \; \; V_\psi \otimes V_{\xi_j } = V_{\xi_{3-j} }, \; \; \; V_\psi \otimes V_{\xi_3 } = V_{\xi_{3} };\; \; \; V_{\rho_1} \otimes V_{\xi_j } = V_{\xi_{3} }, \; \; \; V_{\rho_1} \otimes V_{\xi_3 } = V_{\xi_{1} }+ V_{\xi_{2} }+V_{\xi_{3} };\\ V_{\rho_2} \otimes V_{\xi_j } = V_{\xi_{3-j} }+ V_{\xi_{3} }, \; \; \; V_{\rho_2} \otimes V_{\xi_3 } = V_{\rho_3} \otimes V_{\xi_3 } = V_{\xi_{1} }+ V_{\xi_{2} }+2V_{\xi_{3} };\; \; \; V_{\rho_3} \otimes V_{\xi_j } = V_{\xi_{j} }+ V_{\xi_{3} };\; \; \; \; \; \end{align*}$

where $i = 1, 2, 3$ , $j = 1, 2$ . Thus, we get

$1 \mapsto E_3, \quad V_{\psi} \mapsto \begin{pmatrix} 0 &1 &0\\ 1 &0 &0\\ 0 &0 &1 \end{pmatrix}, \quad V_{\rho_1} \mapsto \begin{pmatrix} 0 &0 &1\\ 0 &0 &1\\ 1 &1 &1 \end{pmatrix}, \quad V_{\rho_2} \mapsto \begin{pmatrix} 0 &1 &1\\ 1 &0 &1\\ 1 &1 &2 \end{pmatrix}, \quad V_{\rho_3} \mapsto \begin{pmatrix} 1 &0 &1\\ 0 &1 &1\\ 1 &1 &2 \end{pmatrix}.$

Then $r(S_4, \alpha)$ is an irreducible based module over $r(S_4)$ equivalent to $M_{3, 3}$ listed in . In other words, the irreducible based module $M_{3, 3}$ over $r(S_4)$ can be categorified by ${\rm Rep}(S_4, \alpha)$ . □

In summary, we have the following classification theorem.

Theorem 4.12. The inequivalent irreducible based modules over $r(S_4)$ are

$M_{1, 1}, \; \; \; {\left \{ M_{2, i}\right \} } _{i = 1, 2, 3} , \; \; \; {\left \{ M_{3, j}\right \} } _{j = 1, 2, 3} , \; \; \; {\left \{ M_{4, s}\right \} } _{1\le s\le 7} \; \; \; \mathit{\text{and}}\; \; \; {\left \{ M_{5, t}\right \} } _{t = 1, 2},$

among which

$M_{1, 1} , \; \; \; {\left \{ M_{2, i}\right \} } _{i = 2, 3} , \; \; \; {\left \{ M_{3, j}\right \} } _{j = 1, 2, 3}, \; \; \; {\left \{ M_{4, s}\right \} } _{s = 1, 5, 7} \; \; \; \mathit{\text{and}}\; \; \; {\left \{ M_{5, t}\right \} } _{t = 1, 2}$

can be categorified by module categories over ${\rm Rep}(S_4)$ ; see Table 8.

Table 8. Inequivalent irreducible based modules over

$r(S_4)$ .

		$V_{\psi}$	$V_{\rho _{1}}$	$V_{\rho _{2}}$	Categorification
Rank 1	$M_{1, 1}$	$1$	$2$	$3$	${\rm Rep}(\mathbb Z_1)$ , ${\rm Rep}(K_4, \alpha)$
Rank 2	$M_{2, 1}$	$\begin{pmatrix} 1&0\\0&1\end{pmatrix}$	$\begin{pmatrix} 2&0\\0&2\end{pmatrix}$	$\begin{pmatrix} 1&2\\2&1\end{pmatrix}$	No
	$M_{2, 2}$	$\begin{pmatrix} 0&1\\1&0\end{pmatrix}$	$\begin{pmatrix} 1&1\\1&1\end{pmatrix}$	$\begin{pmatrix} 2&1\\1&2\end{pmatrix}$	${\rm Rep}(\mathbb Z_2)$ , ${\rm Rep}(D_4, \alpha)$
	$M_{2, 3}$	$\begin{pmatrix} 0&1\\1&0\end{pmatrix}$	$\begin{pmatrix} 1&1\\1&1\end{pmatrix}$	$\begin{pmatrix} 1&2\\2&1\end{pmatrix}$	${\rm Rep}(\mathbb Z_2)$ , ${\rm Rep}(D_4, \alpha)$
Rank 3	$M_{3, 1}$	$\begin{pmatrix} 1&0&0\\0&1&0\\0&0&1\end{pmatrix}$	$\begin{pmatrix} 0&1&1\\1&0&1\\1&1&0\end{pmatrix}$	$\begin{pmatrix} 1&1&1\\1&1&1\\1&1&1\end{pmatrix}$	${\rm Rep}(\mathbb Z_3)$ , ${\rm Rep}(A_4, \alpha)$
	$M_{3, 2}$	$\begin{pmatrix} 0&1&0\\1&0&0\\0&0&1\end{pmatrix}$	$\begin{pmatrix} 0&0&1\\0&0&1\\1&1&1\\\end{pmatrix}$	$\begin{pmatrix} 1&0&1\\0&1&1\\1&1&2\\\end{pmatrix}$	${\rm Rep}(S_3)$
	$M_{3, 3}$	$\begin{pmatrix} 0&1&0\\1&0&0\\0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 0&0&1\\0&0&1\\1&1&1\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1\\1&0&1\\1&1&2\\\end{pmatrix}$	${\rm Rep}(S_3)$ , ${\rm Rep}(S_4, \alpha)$
Rank 4	$M_{4, 1}$	$\begin{pmatrix} 1&0&0&0\\0&1&0&0\\0&0&1&0\\0&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 0&0&1&1\\0&2&0&0\\1&0&0&1\\1&0&1&0\\\end{pmatrix}$	$\begin{pmatrix} 0&1&0&0\\1&2&1&1\\0&1&0&0\\0&1&0&0\\\end{pmatrix}$	${\rm Rep}(A_4)$
	$M_{4, 2}$	$\begin{pmatrix} 1&0&0&0\\0&1&0&0\\0&0&1&0\\0&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 2&0&0&0\\0&2&0&0\\0&0&2&0\\0&0&0&2\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1&1\\1&0&1&1\\1&1&0&1\\1&1&1&0\\\end{pmatrix}$	No
	$M_{4, 3}$	$\begin{pmatrix} 1&0&0&0\\0&1&0&0\\0&0&1&0\\0&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0\\1&1&0&0\\0&0&2&0\\0&0&0&2\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1&1\\1&0&1&1\\1&1&0&1\\1&1&1&0\\\end{pmatrix}$	No
	$M_{4, 4}$	$\begin{pmatrix} 0&1&0&0\\1&0&0&0\\0&0&1&0\\0&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0\\1&1&0&0\\0&0&2&0\\0&0&0&2\\\end{pmatrix}$	$\begin{pmatrix} 1&0&1&1\\0&1&1&1\\1&1&0&1\\1&1&1&0\\\end{pmatrix}$	No
	$M_{4, 5}$	$\begin{pmatrix} 0&1&0&0\\1&0&0&0\\0&0&0&1\\0&0&1&0\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0\\1&1&0&0\\0&0&1&1\\0&0&1&1\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1&1\\1&0&1&1\\1&1&0&1\\1&1&1&0\\\end{pmatrix}$	${\rm Rep}(\mathbb Z_4), \, {\rm Rep}(K_4)$
	$M_{4, 6}$	$\begin{pmatrix} 0&1&0&0\\1&0&0&0\\0&0&0&1\\0&0&1&0\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0\\1&1&0&0\\0&0&1&1\\0&0&1&1\\\end{pmatrix}$	$\begin{pmatrix} 0&1&1&1\\1&0&1&1\\1&1&1&0\\1&1&0&1\\\end{pmatrix}$	No
	$M_{4, 7}$	$\begin{pmatrix} 0&1&0&0\\1&0&0&0\\0&0&0&1\\0&0&1&0\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0\\1&1&0&0\\0&0&1&1\\0&0&1&1\\\end{pmatrix}$	$\begin{pmatrix} 1&0&1&1\\0&1&1&1\\1&1&1&0\\1&1&0&1\\\end{pmatrix}$	${\rm Rep}(\mathbb Z_4), \, {\rm Rep}(K_4)$
Rank 5	$M_{5, 1}$	$\begin{pmatrix} 0&1&0&0&0\\1&0&0&0&0\\0&0&0&1&0\\0&0&1&0&0\\0&0&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 0&0&0&0&1\\0&0&0&0&1\\0&0&1&1&0\\0&0&1&1&0\\1&1&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 0&0&0&1&0\\0&0&1&0&0\\0&1&1&1&1\\1&0&1&1&1\\0&0&1&1&0\\\end{pmatrix}$	${\rm Rep}(S_4)$
	$M_{5, 2}$	$\begin{pmatrix} 0&1&0&0&0\\1&0&0&0&0\\0&0&0&1&0\\0&0&1&0&0\\0&0&0&0&1\\\end{pmatrix}$	$\begin{pmatrix} 1&1&0&0&0\\1&1&0&0&0\\0&0&1&1&0\\0&0&1&1&0\\0&0&0&0&2\\\end{pmatrix}$	$\begin{pmatrix} 0&0&0&1&1\\0&0&1&0&1\\0&1&0&0&1\\1&0&0&0&1\\1&1&1&1&1\\\end{pmatrix}$	${\rm Rep}(D_4)$

| Show Table

DownLoad: CSV

5. Conclusions

The analysis in this paper shows that the classification of the irreducible based modules of rank up to 5 over the complex representation ring $r(S_4)$ . We also showed that any $\mathbb{Z}_+$ -modules over the representation ring $r(G)$ categorified by a module category over the representation category ${\rm Rep}(G)$ must be a based module. At the end, we present the categorification of based modules over $r(S_4)$ by module categories over the complex representation category ${\rm Rep}(S_4)$ of $S_4$ , using projective representations of specific subgroups of $S_4$ . We expect that the studies developed here will be helpful in investigations of the structures of module categories over fusion categories. Our future study will focus on the existence of any irreducible based module of rank $\geq 6$ over $r(S_4)$ and classifying irreducible $\mathbb Z_+$ -modules over $r(S_4)$ , especially for high-rank cases. Also, some other small finite groups may be interesting to consider, e.g., the dihedral group $D_5$ .

Author contributions

Wenxia Wu: Writing-original draft and editing, conceptualization, software, methodology; Yunnan Li: Topic selection, writing-review and editing, funding acquisition, methodology, supervision. All authors have read and approved the final version of the manuscript for publication.

Use of AI tools declaration

The authors declare they have not used Artificial Intelligence (AI) tools in the creation of this article.

Acknowledgments

We would like to thank Zhiqiang Yu for helpful discussion. This work is supported by Guangdong Basic and Applied Basic Research Foundation (2022A1515010357).

Conflict of interest

The authors declare that there are no conflicts of interest.

References

[1]	Z. Hu, W. Ma, S. Ruan, Analysis of SIR epidemic models with nonlinear incidencerate and treatment, Math. Biosci., 238 (2012), 12–20. https://doi.org/10.1016/j.mbs.2012.03.010 doi: 10.1016/j.mbs.2012.03.010
[2]	M. Khan, Q. Badshah, S. Islam, I. Khan, S. Shafie, S. Khan, Global dynamics of SEIRS epidemic model with non-linear generalized incidences and preventive vaccination, Adv. Differ. Equ., 2015 (2015), 88. https://doi.org/10.1186/s13662-015-0429-3 doi: 10.1186/s13662-015-0429-3
[3]	F. Rihan, H. Alsakaji, Dynamics of a stochastic delay differential model for COVID-19 infection with asymptomatic infected and interacting people: case study in the UAE, Results Phys., 28 (2021), 104658. https://doi.org/10.1016/j.rinp.2021.104658 doi: 10.1016/j.rinp.2021.104658
[4]	M. Abdoon, A. Alzahrani, Comparative analysis of influenza modeling using novel fractional operators with real data, Symmetry, 16 (2024), 1126. https://doi.org/10.3390/sym16091126 doi: 10.3390/sym16091126
[5]	C. Qin, J. Du, Y. Hui, Dynamical behavior of a stochastic predator-prey model with Holling-type Ⅲ functional response and infectious predator, AIMS Mathematics, 7 (2022), 7403–7418. https://doi.org/10.3934/math.2022413 doi: 10.3934/math.2022413
[6]	T. Kar, S. Jana, Application of three controls optimally in a vector-borne disease-mathematical study, Commun. Nonlinear Sci., 18 (2013), 2868–2884. https://doi.org/10.1016/j.cnsns.2013.01.022 doi: 10.1016/j.cnsns.2013.01.022
[7]	K. Hattaf, M. Rachik, S. Saadi, Y. Tabit, N. Yousfi, Optimal control of tuberculosis with exogenous reinfection, Applied Mathematical Sciences, 3 (2009), 231–240.
[8]	F. Gumaa, M. Abdoon, A. Qazza, R. Saadeh, M. Arishi, A. Degoot, Analyzing the impact of control strategies on VisceralLeishmaniasis: a mathematical modeling perspective, Eur. J. Pure Appl. Math., 17 (2024), 1213–1227. https://doi.org/10.29020/nybg.ejpam.v17i2.5121 doi: 10.29020/nybg.ejpam.v17i2.5121
[9]	J. Tchuenche, S. Khamis, F. Agusto, S. Mpeshe, Optimal control and sensitivity analysis of an influenza model with treatment and vaccination, Acta Biotheor., 59 (2011), 1–28. https://doi.org/10.1007/s10441-010-9095-8 doi: 10.1007/s10441-010-9095-8
[10]	K. Okosun, R. Ouifki, N. Marcus, Optimal control analysis of a malaria disease transmission model that includes treatment and vaccination with waning immunity, Biosystems, 106 (2011), 136–145. https://doi.org/10.1016/j.biosystems.2011.07.006 doi: 10.1016/j.biosystems.2011.07.006
[11]	H. Alsakaji, Y. El-Khatib, F. Rihan, A. Hashish, A stochastic epidemic model with time delays and unreported cases based on Markovian switching, Journal of Biosafety and Biosecurity, 6 (2024), 234–243. https://doi.org/10.1016/j.jobb.2024.08.002 doi: 10.1016/j.jobb.2024.08.002
[12]	X. Zhang, X. Liu, Backward bifurcation of an epidemic model with saturated treatment, J. Math. Anal. Appl., 348 (2008), 433–443. https://doi.org/10.1016/j.jmaa.2008.07.042 doi: 10.1016/j.jmaa.2008.07.042
[13]	S. Jana, S. Nandi, T. Kar, Complex dynamics of an SIR epidemic model with saturated incidence rate and treatment, Acta Biotheor., 64 (2016), 65–84. https://doi.org/10.1007/s10441-015-9273-9 doi: 10.1007/s10441-015-9273-9
[14]	M. Ali, F. Guma, A. Qazza, R. Saadeh, N. Alsubaie, M. Althubyani, et al., Stochastic modeling of influenza transmission: insights into disease dynamics and epidemic management, Partial Differential Equations in Applied Mathematics, 11 (2024), 100886. https://doi.org/10.1016/j.padiff.2024.100886 doi: 10.1016/j.padiff.2024.100886
[15]	R. Upadhyay, A. Pal, S. Kumari, P. Roy, Dynamics of an SEIR epidemic model with nonlinear incidence and treatment rates, Nonlinear Dyn., 96 (2019), 2351–2368. https://doi.org/10.1007/s11071-019-04926-6 doi: 10.1007/s11071-019-04926-6
[16]	M. Ali, S. Alzahrani, R. Saadeh, M. Abdoon, A. Qazza, N. Al-kuleab, et al., Modeling COVID-19 spread and non-pharmaceutical interventions in South Africa: a stochastic approach, Scientific African, 24 (2024), e02155. https://doi.org/10.1016/j.sciaf.2024.e02155 doi: 10.1016/j.sciaf.2024.e02155
[17]	F. Rihan, H. Alsakaji, C. Rajivganthi, Stochastic SIRC epidemic model with time-delay for COVID-19, Adv. Differ. Equ., 2020 (2020), 502. https://doi.org/10.1186/s13662-020-02964-8 doi: 10.1186/s13662-020-02964-8
[18]	Q. Yang, D. Jiang, N. Shi, C. Ji, The ergodicity and extinction of stochastically perturbed SIR and SEIR epidemic models with saturated incidence, J. Math. Anal. Appl., 388 (2012), 248–271. https://doi.org/10.1016/j.jmaa.2011.11.072 doi: 10.1016/j.jmaa.2011.11.072
[19]	S. Gani, S. Halawar, Optimal control analysis of deterministic and stochastic SIS epidemic model with vaccination, Int. J. Solids Struct., 12 (2017), 251–263.
[20]	X. Mao, G. Marion, E. Renshaw, Environmental Brownian noise suppresses explosions in population dynamics, Stoch. Proc. Appl., 97 (2002), 95–110. https://doi.org/10.1016/S0304-4149(01)00126-0 doi: 10.1016/S0304-4149(01)00126-0
[21]	X. Mao, Stochastic differential equations and applications, Chichester: Horwood Publishing, 2008.
[22]	L. Wang, D. Zhou, Z. Liu, D. Xu, X. Zhang, Media alert in an SIS epidemic model with logistic growth, J. Biol. Dynam., 11 (2017), 120–137. https://doi.org/10.1080/17513758.2016.1181212 doi: 10.1080/17513758.2016.1181212
[23]	R. Khasminskii, Stochastic stability of differential equations, 2 Eds., Heidelberg: Spinger-Verlag, 2011. https://doi.org/10.1007/978-3-642-23280-0
[24]	V. Rico-Ramirez, U. Diwekar, Stochastic maximum principle for optimal control under uncertainty, Comput. Chem. Eng., 28 (2004), 2845–2849. https://doi.org/10.1016/j.compchemeng.2004.08.001 doi: 10.1016/j.compchemeng.2004.08.001
[25]	S. Khare, K. Mathur, K. Das, Optimal control of deterministic and stochastic Eco-epidemic food adulteration model, Results in Control and Optimization, 14 (2024), 100336. https://doi.org/10.1016/j.rico.2023.100336 doi: 10.1016/j.rico.2023.100336
[26]	B $\emptyset$ ksendal, Stochastic differential equations: an introduction with applications, Berlin: Springer, 2003. https://doi.org/10.1007/978-3-642-14394-6
[27]	D. Higham, An algorithmic introduction to numerical simulation of stochastic differential equations, SIAM Rev., 43 (2001), 525–546. https://doi.org/10.1137/S0036144500378302 doi: 10.1137/S0036144500378302

Reader Comments

Your name:*

Email:*
© 2024 the Author(s), licensee AIMS Press. This is an open access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0)

通讯作者: 陈斌, bchen63@163.com

1.
沈阳化工大学材料科学与工程学院沈阳 110142

AIMS Mathematics

1.8 3.4

Metrics

Article views(663) PDF downloads(102) Cited by(0)

Preview PDF

Download XML

Export Citation

Article outline

Show full outline

Figures and Tables

Figures(3) / Tables(1)

AIMS Mathematics

Optimal control and analysis of a stochastic SEIR epidemic model with nonlinear incidence and treatment

Related Papers:

Abstract

1. Introduction

2. Preliminaries

2.1. $\mathbb{Z}_+$ -rings and $\mathbb{Z}_+$ -modules

2.2. Based rings and based modules

3. Irreducible based modules over $r(S_4)$

3.1. Irreducible based modules of rank $\le 3$ over $r(S_4)$

3.2. Irreducible based modules of rank $4, \, 5$ over $r(S_4)$

4. Categorified based modules by module categories over ${ Rep}(S_4)$

4.1. The module categories over ${ Rep}(S_4)$ with trivial twists

4.2. The module categories over ${ Rep}(S_4)$ with nontrivial twists

5. Conclusions

Author contributions

Use of AI tools declaration

Acknowledgments

Conflict of interest

References

Reader Comments

通讯作者: 陈斌, bchen63@163.com

Metrics

Figures and Tables

Other Articles By Authors

Catalog

AIMS Mathematics

Optimal control and analysis of a stochastic SEIR epidemic model with nonlinear incidence and treatment

Related Papers:

Abstract

1. Introduction

2. Preliminaries

2.1. Z+ \mathbb{Z}_+ -rings and Z+ \mathbb{Z}_+ -modules

2.2. Based rings and based modules

3. Irreducible based modules over r(S4) r(S_4)

3.1. Irreducible based modules of rank ≤3 \le 3 over r(S4) r(S_4)

3.2. Irreducible based modules of rank 4,5 4, \, 5 over r(S4) r(S_4)

4. Categorified based modules by module categories over Rep(S4) { Rep}(S_4)

4.1. The module categories over Rep(S4) { Rep}(S_4) with trivial twists

4.2. The module categories over Rep(S4) { Rep}(S_4) with nontrivial twists

5. Conclusions

Author contributions

Use of AI tools declaration

Acknowledgments

Conflict of interest

References

Reader Comments

通讯作者: 陈斌, bchen63@163.com

Metrics

Figures and Tables

Other Articles By Authors

Related pages

Tools

Export File

Citation

Format

Content

Catalog

2.1. $\mathbb{Z}_+$ -rings and $\mathbb{Z}_+$ -modules

3. Irreducible based modules over $r(S_4)$

3.1. Irreducible based modules of rank $\le 3$ over $r(S_4)$

3.2. Irreducible based modules of rank $4, \, 5$ over $r(S_4)$

4. Categorified based modules by module categories over ${ Rep}(S_4)$

4.1. The module categories over ${ Rep}(S_4)$ with trivial twists

4.2. The module categories over ${ Rep}(S_4)$ with nontrivial twists
