Abstract

1. Introduction

Development an effective techniques for solving models involving fractional derivatives and temporal delays has recently attracted a lot of attention, which is encouraging. Flexible representation and the capability to accurately describe various phenomena are the main reasons why they are preferred over integer-order models. Fractional derivatives, unlike regular ones, are non-local in nature and could be used to describe memory effects, while time delays indicate the history of a previous state. It appears that the addition of the delay term in fractional differential equations is paving the way for new possibilities and opening new vistas in many scientific fields. This kind of fractional differential equation is effectively applied in many fields, including bioengineering, control theory, population dynamics, economics, electrochemistry, physics, and many more ^{[1,2,3,4,5,6,7]}. As the systems become increasingly sophisticated and linked, time delays are incorporated to account that changes in one variable may affect other variables with certain lags. For example, in biological models, delays explain incubation time or the time required for a plant to reach maturity. In control theory, time delays are considered in feedback control systems to account for delayed feedback. Economic models use delays to match transportation and information transfer more closely. The literature has paid considerable attention to fractional partial differential equations involving delays. Liu in ^[8] combined the Crank-Nicolson approach and the Legendre spectral technique to provide a fully discrete methodology for the nonlinear delayed diffusion-reaction equations. An effective approximation approach for nonlinear delayed fractional order diffusion equations was developed and evaluated by Pimenov and Hendy in ^[9]. In ^[10], a numerical approach was described for solving a certain form of a delayed fractional model with distributed order in time. The authors in that work used the Crank–Nicholson method to obtain the numerical solution. For solving the nonlinear form of fractional diffusion equations with temporal delay, Li et al. ^[11] suggested a linearized compact scheme. The spatial discretization in the mentioned work was accomplished with the help of the compact finite difference approach, while the temporal discretization was made by utilizing an $L1$ formula to the time fractional derivative and an extrapolation for the nonlinear component. For the solution of time-delayed nonlinear fractional diffusion equations, Mohebbi ^[12] developed a numerical method that is guaranteed to be stable under any conditions. The temporal direction was discretized using a finite difference method, while the spatial component via Chebyshev spectral collocation method. By developing a novel form of fractional Grönwall inequality in a discrete style, Hendy and Macías-Díaz ^[13] were capable of proving the stability and convergence of numerical solutions to the nonlinear time-fractional diffusion equations with multi-time delays.

On the other hand, substantial effort has been expended in the scientific literature to develop efficient formulas for approximating the time fractional derivatives in the Caputo sense. The $L1$ formula is considered one of the most extensive methods used for the solution of fractional differential equations that include Caputo derivatives ^{[14,15,16,17,18,19,20]}. In the case of a non-uniform mesh, the $L1$ approximation provides a decent approximation when the mesh is refined close to the point $t_{n+1}$ ^[21]. Even though the non-uniform mesh performs better than the uniform one, the second-order approximation will not be generated at all mesh nodes. In order to get a close approximation to the Caputo fractional derivative of order $\beta \ (0 < \beta < 1)$ , Gao et al.^[22] constructed a novel formulation called the $L1-2$ formula with $3-\beta$ convergence order in temporal direction at time $t_k (k\geq2)$ . This formula is produced by approximating the integrated function with three points using a piecewise quadratic interpolation approximation and it is properly defined as a modification of the $L1$ formula with some correction terms added. In ^[23,24], the Caputo time-fractional derivative is discretized by applying a numerical formula with $3-\beta$ order, known as, the $L2$ formula. This formula is generated with the use of piecewise quadratic interpolating polynomials. Through the development of a discrete energy analysis approach, a comprehensive theoretical examination of the stability and convergence of this method is performed for every $\beta \in (0, 1)$ . Alikhanov ^[25] devised a new difference scheme called the $L2-1_\sigma$ formula based on a high-order approximation for the Caputo fractional derivatives with $3-\beta$ convergence order in temporal direction at time $t = t_k+\sigma$ with $\sigma = 1-\frac{\beta}{2}$ . It was shown in ^[26,27,28] that the $L2-1_\sigma$ formula may be extended and used to solve the multi-term, distributed, variable-order time-fractional diffusion equations. On the basis of this formula, a number of recent studies have investigated and developed high-order techniques for time fractional models in the Caputo sense. An implicit technique for solving fractional diffusion equations with time delay is shown in ^[29], which combines the Alikhanov formula for time approximation with the central difference method for spatial discretization. A second-order numerical approach was suggested by Nandal and Pandey in ^[30] for solving a nonlinear fourth-order delayed distributed fractional subdiffusion problem. They estimated the time-fractional derivative with the Alikhanov formula as well as the spatial dimensions with the compact difference operator. For the fractional order nonlinear Ginzburg-Landau equation, Zaky et al. ^[31] numerically developed a useful technique by discretizing time direction using the Alikhanov formula and space direction with the methodology of spectral Legendre-Galerkin. Following up on the $L2-1_\sigma$ formula, a slew of new works have appeared (see, for example, ^{[32,33,34,35,36]}). Without loss of generality, in this work, we numerically propose a high-order algorithm for solving the following time-delayed nonlinear fractional order reaction-diffusion equations:

$\begin{equation} \frac {\partial ^\beta \Theta } {\partial t ^\beta} = \kappa\, \frac {\partial ^\alpha \Theta } {\partial |x|^\alpha} +F( \Theta (x , t), \Theta (x , t-s))+G(x, t), \quad x \in \Omega, \quad t \in I, \end{equation}$

(1.1)

initialized and constrained by the conditions

$\begin{equation} \left\{ \begin{array}{ll} \Theta (x , t) = \vartheta(x, t), & x \in \Omega, \quad t \in [-s, 0], \\ \Theta (a , t) = \Theta (b , t) = 0, & t \in I. \end{array} \right. \end{equation}$

(1.2)

In this case, time and space domains are represented by $I = [0, T] \subset \mathbb {R}$ and $\Omega = [a, b] \subset \mathbb {R}$ , respectively. Additionally, $\beta \in (0, 1)$ represents the temporal order of fractional time in which the time-fractional derivative is interpreted according to Caputo, whereas $\alpha \in (1, 2)$ represents the fractional order of space. The Riemann-Liouville fractional derivatives on its both sides for $n-1 < \alpha < n$ , are provided by ^[37]

$\begin{equation} {}_{-\infty} D_{x}^{\alpha} \Theta (x, t) = \frac{1}{\Gamma(n-\alpha)}\frac{\partial^{n}}{\partial x^{n}}\int_{-\infty}^{x}(x-\tau)^{n-1-\alpha} \Theta (\tau, t)d\tau, \end{equation}$

(1.3)

$\begin{equation} {}_x D_{\infty}^{\alpha} \Theta (x, t) = \frac{(-1)^{n}}{\Gamma(n-\alpha)}\frac{\partial^{n}}{\partial x^{n}}\int_{x}^{\infty}(\tau-x)^{n-1-\alpha} \Theta (\tau, t)d\tau, \end{equation}$

(1.4)

where $\Gamma(x)$ symbolizes the usual function of gamma. This allows us to give a definition for the Riesz space of fractional derivatives, which is ^[38]

$\begin{equation*} \frac {\partial ^\alpha \Theta } {\partial |x|^\alpha} = -c_{\alpha}\; \left({}_{a}D_{x}^{\alpha} \Theta (x, t)+{}_{x}D_{b}^{\alpha} \Theta (x, t)\right), \quad c_{\alpha} = \frac{1}{2\cos{\frac{\pi\alpha}{2}}}, \quad \alpha \in (1, 2). \end{equation*}$

The Caputo derivative $\frac {\partial ^\beta \Theta } {\partial t ^\beta}$ is defined as

$\begin{equation} \frac{{\partial ^\beta }\Theta(x, t)}{{\partial t^\beta }} = \frac{1}{{\Gamma (1 - \beta )}}\int_0^t {(t - r)^{ - \beta } \frac{\partial }{{\partial r}} \Theta (x, r)dr} , \quad \beta \in (0, 1). \end{equation}$

(1.5)

Our primary objectives of current work are to develop and investigate an effective numerical algorithm for a nonlinear time-delayed fractional order reaction-diffusion (1.1). A combination scheme is proposed that mixes the Alikhanov $L2-1_\sigma$ difference formula with Galerkin spectral Legendre scheme. More specifically, the spatial discretization is handled by utilizing Legendre–Galerkin spectral approach, whereas the fractional derivative in the temporal direction is discretized through the $L2-1_\sigma$ formula. Additionally, a suitable version of discrete fractional Grönwall inequalities is utilized in order to assert the unconditional stability and convergence of the proposed technique. The structure of this study is as follows. In the subsequent section, we shall describe and characterize the key features of fractional derivative spaces, Sobolev spaces, as well as Jacobi polynomials. On a uniform mesh, we detail in section 3 the way to construct the fully discrete $L2-1_\sigma$ Galerkin spectral scheme for the problems (1.1) and (1.2). Section 4 recalls several technical lemmas from the literature before proving that the suggested methodology is unconditionally stable and convergent. Finally, Section 5 includes a numerical test that validates the obtained scheme's convergence analysis.

2. Basic concepts

Here, we briefly review some fundamental concepts in fractional derivative spaces as well as the essential elements of their properties, see ^[39] for further details. Then, Jacobi polynomials' primary features are mentioned. Assume that $(\cdot, \cdot)_{0, \Omega}$ refer the standard inner product related to $L^{2}(\Omega)$ space with the usual $L^{2}$ norm and the maximum norm $\left\| \cdot \right\|_\infty$ . Define the space $C_0^{\infty}(\Omega)$ consists of all smooth functions that have compact support in $\Omega$ . Consider that $H^r(\Omega)$ and $H_0^r(\Omega)$ are the standard Sobolev spaces, and their associated norms and seminorms, respectively, are $\left\lVert{\cdot}\right\rVert_{r}$ and $\left|{\cdot}\right|_{r}$ . To further clarify, we characterize the approximation space $\mathcal {W}^0 _N$ as:

$\begin{equation*} \mathcal {W}^0 _N = \mathcal {P}_N (\Omega ) \cap H_0^1 (\Omega ), \end{equation*}$

where in $\mathcal {P} _N (\Omega)$ stands for the set of all polynomials defined on the domain $\Omega$ that have a degree no greater than $N$ . The interpolation operator of type Legendre-Gauss-Lobatto depicted by the symbol $I_N :C(\bar \Omega) \to \mathcal {W} _N$ , can be defined as follows

$\begin{equation*} \Theta (x_i) = I_N \ \Theta (x_i) \ \in \mathcal{P} _N, \quad i = 0, 1, \ldots, N. \end{equation*}$

Definition 1. The semi-norm and norm related to the space of left fractional derivatives are specified for a given $\varepsilon > 0$ , respectively, as follows:

$\begin{equation*} \mid \Theta \mid_{J_{L}^{\varepsilon}(\Omega)} = \left\lVert{_a D_{x}^{\varepsilon} \Theta }\right\rVert_{0, \Omega}, \quad \left\lVert{\Theta}\right\rVert_{J_{L}^{\varepsilon}(\Omega)} = \left(\mid \Theta \mid^{2}_{J_{L}^{\varepsilon}}(\Omega)+\left\lVert{ \Theta }\right\rVert^{2}_{0, \Omega}\right)^{1/2}, \end{equation*}$

also, $J_{L}^{\varepsilon}$ and $J_{L, 0}^{\varepsilon}$ are defined to be the closures of $C^{\infty}(\Omega)$ and $C_0^{\infty}(\Omega)$ , respectively, in relation to $\left\lVert{\cdot}\right\rVert_{J_{L}^{\varepsilon}(\Omega)}$ .

Definition 2. The semi-norm and norm related to the space of right fractional derivatives are specified for a given $\varepsilon > 0$ , respectively, as follows:

$\begin{equation*} \mid \Theta \mid_{J_{R}^{\varepsilon}(\Omega)} = \left\lVert{_x D_{b}^{\varepsilon} \Theta }\right\rVert_{0, \Omega}, \quad \left\lVert{\Theta}\right\rVert_{J_{R}^{\varepsilon}(\Omega)} = \left(\mid \Theta \mid^{2}_{J_{R}^{\varepsilon}(\Omega)}+\left\lVert{ \Theta }\right\rVert^{2}_{0, \Omega}\right)^{1/2}, \end{equation*}$

also, $J_{R}^{\varepsilon}$ and $J_{R, 0}^{\varepsilon}$ are defined to be the closures of $C^{\infty}(\Omega)$ and $C_0^{\infty}(\Omega)$ , respectively, in relation to $\left\lVert{\cdot}\right\rVert_{J_{R}^{\varepsilon}(\Omega)}$ .

Definition 3. The semi-norm and norm related to the space of symmetric fractional derivatives are specified for a given $\varepsilon > 0$ , respectively, as follows:

$\begin{equation*} \mid \Theta \mid_{J_{s}^{\varepsilon}(\Omega)} = \mid ({}_a D_{x}^{\varepsilon} \Theta , {}_x D_{b}^{\varepsilon} \Theta )_{0, \Omega} \mid^{1/2}, \quad \left\lVert{\Theta}\right\rVert_{J_{s}^{\varepsilon}(\Omega)} = \left(\mid \Theta \mid^{2}_{J_{s}^{\varepsilon}}(\Omega)+\left\lVert{ \Theta }\right\rVert^{2}_{0, \Omega}\right)^{1/2}, \end{equation*}$

also, $J_{s}^{\varepsilon}$ and $J_{s, 0}^{\varepsilon}$ are defined to be the closures of $C^{\infty}(\Omega)$ and $C_0^{\infty}(\Omega)$ , respectively, in relation to $\left\lVert{\cdot}\right\rVert_{J_{s}^{\varepsilon}(\Omega)}$ .

Definition 4. Assuming that $\varepsilon > 0$ , then the fractional Sobolev space $H^{\varepsilon}(\Omega)$ is defined as follows:

$\begin{equation*} H^\varepsilon (\Omega ) = \left\{ { \Theta \in L^2 (\Omega )\left| {\left| \omega \right|^\varepsilon \mathcal{F}(\hat \Theta ) \in L^2 (\mathbb{R} )} \right.} \right\}, \end{equation*}$

with respect to following semi-norm and norm

$\begin{equation*} \mid \Theta \mid_{H^{\varepsilon}(\Omega)} = \left\lVert{\; \mid\omega \mid^{\varepsilon}\mathcal{F}(\hat \Theta )}\right\rVert_{0, \mathbb{R}}, \quad \left\lVert{\Theta}\right\rVert_{H^{\varepsilon}(\Omega)} = \left(\mid \Theta \mid^{2}_{H^{\varepsilon}(\Omega)}+\left\lVert{ \Theta }\right\rVert^{2}_{0, \Omega}\right)^{1/2}, \end{equation*}$

wherein $\mathcal{F}(\hat \Theta)$ stands for the Fourier transform of function $\hat \Theta$ , denoting the zero extension of function $\Theta$ beyond the spatial domain $\Omega$ . Also, we define $H ^\varepsilon (\Omega)$ and $H _0 ^\varepsilon (\Omega)$ as the closures of $C^{\infty}(\Omega)$ and $C_0^{\infty}(\Omega)$ , respectively, with consideration to $\left\lVert{\cdot}\right\rVert _{H ^\varepsilon (\Omega)}$ .

Remark 2.1. If $\varepsilon \neq n-\frac{1}{2}, \ n\in \mathbb{N}$ , then according to the above definitions, fractional derivative spaces $J_{L}^{\varepsilon}, \ J_{R}^{\varepsilon}, \ J_{s}^{\varepsilon}$ and $H^{\varepsilon}$ are identical, with equivalent semi-norms and norms.

The adjoint property, which we will revisit below, will play a crucial part in the study that follows.

Lemma 2.1. For a given $\varepsilon > 0$ , such that $1 < \varepsilon < 2$ , then for any two functions $\Theta \in H_{0}^{\varepsilon}(\Omega)$ and $\upsilon \in H_{0}^{\varepsilon/2}(\Omega)$ , the following relation is satisfied

$\begin{equation} \left({}_{a}D_{x}^{\varepsilon} \Theta , \upsilon\right)_{0, \Omega} = \left({}_{a} D_{x}^{\varepsilon/2} \Theta , {}_{x} D_{b}^{\varepsilon/2}\upsilon\right)_{0, \Omega}, \quad \left({}_{x}D_{b}^{\varepsilon} \Theta , \upsilon\right)_{0, \Omega} = \left({}_{x} D_{b}^{\varepsilon/2} \Theta , {}_{a} D_{x}^{\varepsilon/2}\upsilon\right)_{0, \Omega}. \end{equation}$

(2.6)

A brief overview of the basics of Jacobi polynomials follows. We recommend reading ^[40,41] for more information on orthogonal polynomials, and ^{[42,43,44,45,46,47,48,49]} for applications of spectral methods to these type of polynomials. For $p, q > -1$ and $x \in (-1, 1)$ , the hypergeometric functions make it possible to write the Jacobian polynomials as follows:

$\begin{equation} \gamma^{p , q} _0 (x) = \frac{(p+1)i}{i!} {_2 F_1} \left( -i, p+q+i+1;p+1;\frac{1-x}{2}\right), \quad i \in \mathbb{N}, \end{equation}$

(2.7)

where $(\cdot)_i$ signifies the symbol of Pochhammer. Assuming that $N$ is a positive integer, then the following three-term recurrence relations hold for $\{\gamma _i ^{p, q} (x) \} _{i = 0} ^N$ , as they hold for all classical orthogonal polynomials

$\begin{equation} \left\{\begin{array}{ll} \gamma ^{p, q} _0 (x) = 1, & \\ \gamma ^{p , q}_1 (x) = \frac {1} {2} (2 + p + q) x + \frac {1} {2} (p - q), & \\ \gamma ^{p , q} _{i + 1} (x) = \left( A ^{p , q} _i x - B ^{p , q} _i \right) \gamma ^{p , q} _i (x) - C ^{p , q} _i \gamma^{p , q} _{i - 1} (x), & 1 \leq i \leq N. \end{array}\right. \end{equation}$

(2.8)

Where the coefficients of recursion are provided by

$\begin{equation} \left\{ \begin{array}{l} A ^{p , q} _i = \frac {(2 i + p + q + 1) (2 i + p + q + 2)} {2 (i + 1) (i + p + q + 1)}, \\ B ^{p , q} _i = \frac {(2 i + p + q + 1) (p ^2 - q ^2)} {2 (i + 1) (i + p + q + 1) (2 i + p + q)}, \\ C ^{p , q} _i = \frac {(2 i + p + q + 2) (i + p) (i + q)} {(i + 1) (i + p + q + 1) (2 i + p + q)}. \end{array} \right. \end{equation}$

(2.9)

The existence of orthogonality in the set of Jacobi polynomials is due to a weight function, which is represented by $\omega^{p, q}(x) = (1-x)^p (1+x)^q$ , more precisely,

$\begin{equation} \int_{-1}^{1} \gamma_i ^{p , q} (x) \gamma_j ^{p , q} (x) \omega ^{p , q} (t) dx = \iota_i^{p, q } \delta_{i, j}, \end{equation}$

(2.10)

where $\delta_{i, j}$ represents the function of the Kronecker delta, and

$\begin{equation} \iota_i ^{p , q} = \frac {2 ^{(p + q + 1)} \Gamma (i + p + 1) \Gamma (i + q + 1)} {(2 i + p + q + 1) i! \Gamma (i + p + q + 1)}. \end{equation}$

(2.11)

In specifically, the Legendre polynomial is a subclass of the Jacobi polynomial, which it can be stated as:

$\begin{equation} L_i(x) = \gamma^{0, 0}_i(x) = {_2 F_1} \left( -i, i+1;1;\frac{1-x}{2}\right). \end{equation}$

(2.12)

3. The numerical scheme

Here, in this section, we will focus on developing a high-order numerical approximation for the problems (1.1) and (1.2) based on combining Alikhanov $L2-1_\sigma$ difference formula and the spectral method of Legendre-Galerkin in order to discretize the temporal and space–fractional derivatives, respectively. We begin with temporal discretization following that, we detail the suggested scheme's spatial discretization.

3.1. Temporal discretization

We choose a time step given by $\tau = \frac{s}{N_s}$ , where $N_s$ is a positive integer, in order to uniformly divide the temporal domain $I$ . This defines a class of uniform partitions denote by $t_k = k \tau$ , for each $-N_s \leq k \leq M,$ where $M = \left\lceil {\frac{T}{\tau }} \right\rceil$ . Denote $t_{k+\sigma} = (k+\sigma) \tau = \sigma t_{k+1}+(1-\sigma)t_{k}$ , for $k = 0, 1, \dots, M$ . Take $\Theta^{k+\sigma} = \Theta^{k+\sigma}(\cdot) = \Theta(\cdot, \ t_{k+\sigma})$ . For the Caputo derivative (1.5), we recall the Alikhanov $L2-1_\sigma$ difference formula ^[25].

Definition 5. The following coefficients are defined for any value of the parameter $\sigma = 1-\frac{\beta}{2}$ , $0 < \beta < 1$ ,

$\begin{equation} \mathcal{A}_{l}^{(\beta, \sigma)} = \left\{\begin{array}{ll} \sigma^{1-\beta}, & l = 0, \\ (l+\sigma)^{1-\beta}-(l-1+\sigma)^{1-\beta}, & l\geq 1, \end{array}\right. \end{equation}$

(3.13)

$\begin{equation} \mathcal{B}_{l}^{(\beta, \sigma)} = \frac{1}{2-\beta}\left[(l+\sigma)^{2-\beta}-(l-1+\sigma)^{2-\beta}\right]-\frac{1}{2}\left[(l+\sigma)^{1-\beta}+(l-1+\sigma)^{1-\beta}\right], \ l\geq 1, \end{equation}$

(3.14)

and

$\begin{equation} \mathcal{C}_{l}^{(k, \beta, \sigma)}{ = }\left\{\begin{array}{ll} \mathcal{A}_{0}^{(\beta, \sigma)}, & l = k = 0, \\ \mathcal{A}_{0}^{(\beta, \sigma)}+\mathcal{B}_{1}^{(\beta, \sigma)}, & l = 0, \ k\geq 1, \\ \mathcal{A}_{l}^{(\beta, \sigma)}+\mathcal{B}_{l+1}^{(\beta, \sigma)}-\mathcal{B}_{l}^{(\beta, \sigma)}, & 1\leq l\leq k-1, \\ \mathcal{A}_{k}^{(\beta, \sigma)}-\mathcal{B}_{k}^{(\beta, \sigma)}, & 1\leq l = k. \end{array}\right. \end{equation}$

(3.15)

Consequently, the $L2-1_\sigma$ difference formula which applied in this investigation can be formulated in light of the lemma below.

Lemma 3.1. Under the premise that $\Theta (t)\in C^{3}[0, t_{k+1}], \ 0\leq k\leq M-1$ , the high order $L2-1_{\sigma}$ difference formula reads as follows:

$\begin{equation} {}_{0} D_{t_{k+\sigma}}^{\beta}\Theta = \frac{\tau^{-\beta}}{\Gamma(2-\beta)}\sum\limits_{l = 0}^{k}\mathcal{C}_{k-l}^{(k, \beta, \sigma)}\delta_{t}\Theta^{l}+O(\tau^{3-\beta}), \ \ 0 < \beta < 1, \end{equation}$

(3.16)

where $\delta_{t} \Theta^{l} = \Theta^{l+1}-\Theta^{l}$ . For the sake of theoretical clarity, we rewrite (3.16) in an equivalent form as:

$\begin{equation} {}_{0} D_{t_{k+\sigma}}^{\beta} \Theta = \frac{\tau^{-\beta}}{\Gamma(2-\beta)}\sum\limits_{l = 0}^{k} \mathcal{D}_{l}^{(k, \beta, \sigma)}\Theta^{l}+O(\tau^{3-\beta}), \end{equation}$

(3.17)

where $\mathcal{D}_{1}^{(0, \beta, \sigma)} = -\mathcal{D}_{0}^{(0, \beta, \sigma)} = \sigma^{1-\beta},$ for $k = 0$ , and for $k \geq 1$ ,

$\begin{equation} \mathcal{D}_{l}^{(k, \beta, \sigma)} = \left\{\begin{array}{ll} -\mathcal{C}_{k}^{(k, \beta, \sigma)}, & l = 0, \\ \mathcal{C}_{k-l+1}^{(k, \beta, \sigma)}-C_{k-l}^{(k, \beta, \sigma)}, & 1\leq l\leq k, \\ \mathcal{C}_{0}^{(k, \beta, \sigma)}, & l = k+1. \end{array}\right. \end{equation}$

(3.18)

Definition 6. For the temporal Caputo fractional derivative, the $L2-1_\sigma$ approximation formula at node $t_{k+\sigma}, k\in \mathbb{Z}_{[0, M-1]}$ is defined as:

$\begin{equation} _{0} D_{\tau}^{\beta} \Theta^{k+\sigma} = \frac{\tau^{-\beta}}{\Gamma(2-\beta)}\sum\limits_{l = 0}^{k+1} \mathcal{D}_{l}^{(k, \beta, \sigma)} \Theta^l , \quad 0 < \beta < 1. \end{equation}$

(3.19)

By means of Taylor's theorem, it is observed that the following lemma is valid.

Lemma 3.2. For a given function $\Theta(t)\in C^{2}[0, T]$ , the following identities hold

$\begin{equation*} \left. \begin{array}{ll} \Theta(\cdot, t_{k+\sigma}) = \sigma \ \Theta(\cdot, t_{k+1})+(1-\sigma) \ \Theta(\cdot, t_{k})+ O(\tau^{2}), \\ \Theta(\cdot, t_{k+\sigma}) = (\sigma+1) \ \Theta (\cdot, t_{k})-\sigma \ \Theta(\cdot, \ t_{k-1})+O(\tau^{2}), \\ \Theta(\cdot, t_{k+\sigma-N_s}) = \sigma \ \Theta(\cdot, t_{k+1-N_s})+(1-\sigma) \ \Theta(\cdot, t_{k-N_s})+O(\tau^{2}). \end{array} \right. \end{equation*}$

Following that, at each specified time $t_{k+\sigma}$ , we shall present a semi-discretized version of the system (1.1). To that end, the uniform $L2-1_{\sigma}$ formula (3.19) is used to estimate the time-fractional component, and Taylor's approximations are used to discretize the nonlinear source term. Thus, the resulting discrete-time system is as follows:

$\begin{equation} _{0} D_{\tau}^{\beta} \Theta^{k+\sigma} = \kappa \frac{\partial^{\alpha} \Theta^{k+\sigma}}{\partial |x|^\alpha}+F\left((\sigma+1) \Theta^{k} -\sigma \Theta^{k-1}, \sigma \Theta^{k+1-N_s}+(1-\sigma) \Theta^{k-N_s} \right)+G^{k+\sigma}(x), \quad x \in \Omega. \end{equation}$

(3.20)

We also take into account initial-boundary approximations as the following form

$\begin{equation} \left\{ \begin{array}{lll} \Theta_i^{k} = \vartheta(x_i, t_k), \quad -N_s \leq k\leq 0, \ x \in \Omega, \\ \Theta_0^{k} = \Theta_M^{k}(x) = 0, \quad -N_s \leq k\leq 0, \ x \in \Omega. \end{array} \right. \end{equation}$

(3.21)

According to Lemmas (3.1) and (3.2), this semi-scheme is technically accurate to the second order. Later in this context, a comprehensive study of the convergence rate for the full-discrete scheme will be provided. Next, we introduce the following two parameters:

$\begin{equation*} \lambda_k^{(\beta, \sigma)} : = \left(\frac{\mathcal{D}_{k+1}^{(k, \beta, \sigma)}}{\tau^\beta\Gamma(2-\beta)}\right)^{-1}, \qquad \tilde{\mathcal{D}}_{j}^{(k, \beta, \sigma)} : = \begin{cases} \frac{\zeta_k^{(\beta, \sigma)}\ \mathcal{D}_j^{(k, \beta, \sigma)}}{\tau^\beta\Gamma(2-\beta)}, & 0\leq j \leq k-1, \\ \frac{\zeta_k^{(\beta, \sigma)}\ \mathcal{D}_k^{(k, \beta, \sigma)}}{\tau^\beta\Gamma(2-\beta)}, & j = k. \end{cases} \end{equation*}$

Then, this permits the recasting of the semi-scheme (3.20) into the equivalent form given below

$\begin{align} \Theta^{k+1}- & \kappa \sigma \lambda_k^{(\beta, \sigma)} \frac{\partial^{\alpha} \Theta^{k+1}}{\partial |x|^\alpha} = \kappa(1-\sigma)\lambda_k^{(\beta, \sigma)} \frac{\partial^{\alpha} \Theta^{k}}{\partial |x|^\alpha}-\sum\limits_{j = 0}^{k} \tilde{\mathcal{D}}_{j, l}^{(k, \beta, \sigma)} \Theta^{j} \\ &+\lambda_k^{(\beta, \sigma)}F\left((\sigma+1) \Theta^{k} -\sigma \Theta^{k-1}, \sigma \Theta^{k+1-N_s}+(1-\sigma) \Theta^{k-N_s} \right) +G^{k+1}. \end{align}$

(3.22)

3.2. Spatial discretization

We first present the space function below to give suitable base functions that precisely meet the boundary requirements specified in spectral techniques for space fractional order equations in order to linearize the space-fractional components ^[50,51]:

$\begin{equation} \mathcal {W}^0 _N = \mathcal {P} _N (\Omega ) \cap H_0^1 (\Omega ) = \text {span} \left\{ \psi _n (x) : n = 0 , 1 , \ldots , N - 2 \right\}, \end{equation}$

(3.23)

where $\psi _n$ symbolizes the base functions, which are represented by the Legendre polynomial as:

$\begin{equation} \psi _n (x) = L _n (\hat x) - L _{n + 2} (\hat x) = \frac {2 n + 3} {2 (n + 1)} (1 - \hat x ^2) \ \gamma_n ^{1 , 1} (\hat x), \quad \forall \ \hat {x} \in [- 1 , 1], \end{equation}$

(3.24)

where $x = \frac {1} {2} ((b - a) \hat x + a + b) \in [a, b]$ . Therefore, the fully discrete $L2-1_{\sigma}$ Galerkin spectral scheme for (3.22) can be expressed as follows: find $\Theta^{k+1} \in \mathcal {W}^0 _N$ , $k\geq0$ such that satisfying the following system:

$\begin{equation} \left\{ \begin{array}{lll} \left(\Theta^{k+1}, \upsilon \right)- \kappa \sigma \lambda_k^{(\beta, \sigma)}\left(\frac{\partial^{\alpha} \Theta^{k+1}}{\partial |x|^\alpha}, \upsilon \right) = \kappa(1-\sigma)\lambda_k^{(\beta, \sigma)}\left(\frac{\partial^{\alpha} \Theta^{k}}{\partial |x|^\alpha}, \upsilon \right)-\sum\limits_{j = 0}^{k} \tilde{\mathcal{D}}_{j, l}^{(k, \beta, \sigma)} \left(\Theta^{j}, \upsilon \right)\\ \quad+\lambda_k^{(\beta, \sigma)} \left(I_N F\left((\sigma+1) \ \Theta^{k} -\sigma \ \Theta^{k-1}, \sigma \ \Theta^{k+1-N_s}+(1-\sigma) \ \Theta^{k-N_s} \right), \upsilon \right)+\left(I_N G^{k+1}(x), \upsilon \right), \\\quad k\geq0, \ \forall\ \upsilon \in {W}^0 _N, \\ \Theta_N^{0} = \pi^{1, 0}_N \ \vartheta, \end{array} \right. \end{equation}$

(3.25)

where $\pi_{N}^{1, 0}$ is a suitable projection operator in this case. Following this, we could further generalize the approximation as:

$\begin{equation} \Theta_N^{k+1} = \sum\limits_{i = 0}^{N-2} \hat \Theta_i^{k+1} \psi_i (x), \end{equation}$

(3.26)

where $\hat \Theta_i^{k+1}$ are an undetermined expansion coefficients. The uniform full discrete scheme for the problems (1.1) and (1.2) can be expressed as a linear system in a matrix form using (3.26), lemma 2.1 and allowing $\upsilon = \psi _k$ , for each $0 \leq k \leq N - 2$ as follows:

$\begin{equation} \left(\bar{M} - \kappa \sigma \lambda_k^{(\beta, \sigma)}(S + S^T) \right) U^{k+1} = R^k + \lambda_k^{(\beta, \sigma)} H^{k}+ G^{k+1}, \end{equation}$

(3.27)

where

$\begin{align} & s_{ij} = \int _\Omega {}_a D _x ^{\frac {\alpha} {2}} \psi_i(x) {} _x D _b ^{\frac {\alpha} {2}} \psi _j (x) dx , \quad S = \left( {s _{ij} } \right) _{i , j = 0} ^{N - 2}, \\ & m_{ij} = \int _\Omega \psi _i (x) \psi _j (x) dx, \quad \bar{M} = \left( m _{ij} \right) _{i , j = 0} ^{N - 2}, \\ & h_i^k = \int _\Omega \psi_i (x) I_N F\left((\sigma+1) \ \Theta^{k} -\sigma \ \Theta^{k-1}, \sigma \ \Theta^{k+1-N_s}+(1-\sigma) \ \Theta^{k-N_s}\right) dx, \\ & g_i^{k+1} = \int _\Omega \psi _i (x) I _N g^{k+1} dx , \quad G ^{k+1} = (g_0^{k+1}, g_1^{k+1}, \ldots, g_{N - 2}^{k+1}) ^\top, \quad H ^{k} = (h_0^{k}, h_1^{k}, \ldots , h_{N-2}^{k})^\top , \\ & U^{k+1} = \left(\hat \Theta_0^{k+1}, \hat \Theta_1^{k+1}, \ldots , \hat \Theta_{N - 2}^{k+1}\right)^\top, \quad R^k = \kappa(1-\sigma) \lambda_k^{(\beta, \sigma)}(S + S^T)\Theta^{k}-\tilde{\mathcal{D}}_{l}^{(k, \beta, \sigma)}\tilde{M} \Theta^k. \\ \end{align}$

(3.28)

The elements of the stiffness matrix $S$ and the mass matrix $\tilde{M}$ can be easily handled using the next two lemmas.

Lemma 3.3. ^[50,51] The following relation can be used to manipulate the components that make up the stiffness matrix $S$ , namely,

$\begin{equation*} s_{ij} = a_i^{j} - a _i ^{j + 2} - a _{i + 2} ^j + a _{i + 2} ^{j + 2}, \quad i, j = 0 , 1 , \ldots , N - 2, \end{equation*}$

the formula where the coefficients $a _i^j$ may be determined reads

$\begin{equation} \begin{split} a _i^j & = \int_\Omega {} _a D _x ^{\frac {\alpha} {2}} L _i (\hat x) {} _x D _b ^{\frac {\alpha} {2}} L _j (\hat x) dx \\ & = \left( \frac {b - a} {2} \right) ^{1 - \alpha} \frac {\Gamma (i + 1) \Gamma (j + 1)} {\Gamma (i - \frac {\alpha} {2} + 1) \Gamma (j - \frac {\alpha} {2} + 1)} \cdot \\ & \qquad \cdot \sum _{r = 0} ^N \varpi _r ^{- \frac {\alpha} {2} , - \frac {\alpha} {2}} J _i ^{\frac {\alpha} {2} , - \frac {\alpha} {2}} \left( x _r ^{- \frac {\alpha} {2} , - \frac {\alpha} {2}} \right) J _j ^{- \frac {\alpha} {2} , \frac {\alpha} {2}} \left( x _r ^{- \frac {\alpha} {2} , - \frac {\alpha}{2}} \right), \end{split} \end{equation}$

(3.29)

and $\left\{ \varpi _r ^{ - \frac {\alpha} {2}, - \frac {\alpha} {2}}, x _r ^{ - \frac {\alpha} {2}, - \frac {\alpha} {2}} \right\} _{i = 0}^N$ are Jacobi-Gauss collection points and their corresponding weights related to the weight function $\omega ^{- \frac {\alpha} {2}, - \frac {\alpha} {2}}$ .

Lemma 3.4. ^[50,51] The nonzero components of the symmetric mass matrix $\bar{M}$ are given by

$\begin{equation} m _{ij} = m _{ji} = \left\{ \begin{array}{ll} \frac {b - a} {2 j + 1} + \frac {b - a} {2j + 5}, & \forall i = j, \\ - \frac {b - a} {2 j + 5}, & \forall i = j + 2. \end{array} \right. \end{equation}$

(3.30)

4. Theoretical analysis

This section aims to verify how effectively the numerical solution of the suggested approach for the problems (1.1) and (1.2). We start in the first part with a review of certain technical lemmas that will be important later on. In the second subsection, we conduct stability and convergence studies of the suggested method. We assume that the Lipschitz condition below holds for the function $F$ , which is necessary for the theoretical analysis, i.e,

$\begin{equation} \left| {F( \Theta _1 , v_1 ) - F( \Theta _2 , v_2 )} \right| \le L\left( {\left| { \Theta _1 - \Theta _2 } \right| + \left| {v_1 - v_2 } \right|} \right), \end{equation}$

(4.31)

where $L$ is a positive constant.

4.1. Technical Lemmas

Here, we recall some lemmas that will be used in our investigation. To avoid tying these definitions to specific values for $N$ , $n$ , and $\tau$ , we will refer to $C$ and $C_{ \Theta }$ in the following as arbitrary positive constants that can shift depending on the circumstances. Additionally, we accept on the convention $\mathbb{Z}_{[a, b]} = \mathbb{Z} \cap [a, b]$ , where $\mathbb{Z}$ is the set of all positive integers. For the rest of this discussion, we'll be using the following notation

$\begin{equation} A ( \Theta, w) = \kappa c _\alpha \left[ \left( {} _a D _x ^{\alpha / 2} \Theta , {} _x D _b ^{\alpha / 2} w \right) + \left( {} _x D _b ^{\alpha / 2} \Theta , {} _a D _x ^{\alpha / 2} w \right) \right], \quad w \in \mathcal {W}^0 _N. \end{equation}$

(4.32)

The orthogonal projection operator, denoted by $\pi^{\frac {\alpha} {2}, 0}_N : H _0 ^{\frac {\alpha} {2}} (\Omega) \rightarrow \mathcal {W}^0 _N$ , will have the following property:

$\begin{equation} A ( \Theta - \pi^{\frac {\alpha} {2}, 0}_N \Theta , w) = 0, \quad \forall \, \Theta \in H _0 ^{\frac {\alpha} {2}} (\Omega), \quad w \in \mathcal {W}^0 _N. \end{equation}$

(4.33)

We provide the following semi-norm and norm to facilitate theoretical analysis.

$\begin{equation} | \Theta |_{\alpha/2}: = A( \Theta, \Theta )^{1/2}, \end{equation}$

(4.34)

$\begin{equation} \left\lVert{ \Theta }\right\rVert_{\alpha/2}: = (\left\lVert{ \Theta }\right\rVert^2+| \Theta |_{\alpha/2}^2)^{1/2}. \end{equation}$

(4.35)

The three lemmas below are all mentioned in ^[50].

Lemma 4.1. Suppose that $\alpha$ and $s$ are two real integers such that $\alpha \ne 1/2, \ \ 0 < \alpha < 1, \ \ \alpha < s$ . Then, for every function $\Theta \in H _0 ^{\frac {\alpha} {2}} (\Omega) \cap H ^s (\Omega)$ , the approximation that follows valid

$\begin{align} | \Theta -\pi_{N}^{\frac{\alpha}{2}, 0} \Theta |_{\frac{\alpha}{2}}\leq C N^{\frac{\alpha}{2}-s}\left\lVert{\Theta}\right\rVert_s, \end{align}$

(4.36)

where $C$ is a positive constant C independent of $N$ .

Lemma 4.2. We assume that $\Theta \in H _0 ^{\frac {\alpha} {2}} (\Omega)$ and that $\Omega = (a, b)$ . Then, there are two positive, independent constants $C_1 < 1$ and $C_2$ with respect to $\Theta$ , such that the following remains true

$\begin{equation*} C_1 \left\lVert{\Theta}\right\rVert_{\frac{\alpha}{2}} \leq | \Theta |_{\frac{\alpha}{2}} \leq \left\lVert{\Theta}\right\rVert_{\frac{\alpha}{2}} \leq C_2 | \Theta |_{H^{\frac {\alpha} {2}} (\Omega)}. \end{equation*}$

Lemma 4.3. The inverse inequality that follows holds true for every given set of values for $\Theta \in \mathcal {P} _N (\Omega)$

$\begin{equation*} \left\lVert{\Theta}\right\rVert_{\infty} \leq C N \left\lVert{\Theta}\right\rVert, \end{equation*}$

where $C$ is a constant that is positive and independent of $\Theta$ and $N$ .

The properties of the interpolation operator $I _N$ are summarized in the following lemma and remark.

Lemma 4.4. ^[41] Assume that $\Theta \in H ^s (\Omega)$ , then for $s \geq 1$ and $0 \leq l \leq 1$ , the following relation is valid

$\begin{equation*} \left\lVert{ \Theta - I _N \Theta }\right\rVert _l \leq C N ^{l - s} \left\lVert{ \Theta }\right\rVert _s, \end{equation*}$

where $C > 0$ is a constant independent of $N$ .

Remark 4.1. The smoothness of the solution to a fractional differential equation does not imply the smoothness of the source term. Consequently, the solution $\Theta$ has a different regularity order $s$ than the regularity order $r$ for the source term $G$ , which means that

$\begin{equation*} \left\lVert{I _N G - G}\right\rVert \leq C N^{-r}\left\lVert{ \Theta }\right\rVert_{r}, \forall G \in H ^r (\Omega), \end{equation*}$

where $C > 0$ is a constant independent of $N$ , $\Theta$ and $g$ .

Lemma 4.5. ^[52] All absolutely continuous functions $\Theta (t)$ on $[0, T]$ satisfy the following inequality

$\begin{equation} \left(\frac {\partial ^\beta} {\partial t ^\beta} \Theta (t), \Theta (t)\right) \geq \frac {1} {2} \frac {\partial ^\beta} {\partial t ^\beta} \left\lVert{ \Theta (t)}\right\rVert^{2}. \end{equation}$

(4.37)

Lemma 4.6. ^[25] The following inequality holds for any $\Theta(t)$ identified on the interval $\Omega$ and $\beta \in (0, 1)$ . If $\Theta^{k+\sigma} = \sigma \Theta^{k+1}+(1-\sigma) \Theta^k,$ then

$\begin{equation*} \left(D_{\tau}^\beta, \Theta^{k+\sigma}\right)\geq \frac {1} {2} \ D_{\tau}^{\beta} \left\lVert{\Theta^{k+\sigma}}\right\rVert^2. \end{equation*}$

It's worth noting that a significant amount of consideration has been paid to developing fractional Grönwall inequalities in their continuous form in recent years. However, their discrete form has received less attention, and a few recent studies ^{[11,53,54,55]} have attempted to close the gap. In what follows, we present a developed discrete version of Grönwall inequality that agrees with the $L2-1_\sigma$ difference schemes and plays an important part in demonstrating the stability and convergence of our suggested approach.

Lemma 4.7. ^[13,28] Assume that $\{ Q ^i \} _{i = -N_{s}} ^\infty$ and $\{ \zeta ^n \} _{n = 0} ^\infty$ are both non-negative sequences. Suppose that $\mu_i, \, i \in \mathbb {Z} _{[1,6]}$ are independent positive constants with respect to $\tau$ , such that the sequences satisfying

$\begin{align*} &Q^i \geq 0 \; \; \forall\; i \geq 0, \quad Q^0 \; \; {{is \; recognized}} \; \; {{and}}\; \; Q ^i = 0 \; \; \forall\; i < 0, \\ &_{0}D_{t_{k+\sigma}}^{\beta} Q^{k} \leq \mu_{1} Q^{k}+\zeta^{k}, \quad \forall k\leq N_s, \\ &_{0}D_{t_{k+\sigma}}^{\beta} Q^{k} \leq \mu_{1} Q^{k}+\mu_{2} Q^{k-1}+\mu_{3} Q^{k-2} +\mu_{4}Q^{k-3}+\mu_{5} Q^{k+1-N_s}+\mu_{6} Q^{k-N_s}+\zeta^{k}, \quad \forall k\leq N_s. \end{align*}$

In that case, there is a positive constant $\tau\leq \tau^{*} = \sqrt[\beta]{{1}/(2\Gamma(2-\beta)\mu_{1})}$ , which causes

$\begin{equation*} Q^{k+1}\leq 2 E_{\beta}(2\mu t_{k}^{\beta}) \left(Q^{0}+\frac{t_{k}^{\beta}}{\Gamma(1+\beta)}\max\limits_{0\leq k_{0}\leq k}\zeta^{k_{0}} \right), \end{equation*}$

where $E_{\beta}(z)$ represent the Mittag-Leffler function and

$\begin{equation*} \mu = \mu_{1}+\frac{\mu_{2}}{b_0^{(\beta, \sigma)}-b_1^{(\beta, \sigma)}}+\frac{\mu_{3}}{b_{1}^{(\beta, \sigma)}-b_2^{(\beta, \sigma)}} +\frac{\mu_{4}}{b_2^{(\beta, \sigma)}-b_3^{(\beta, \sigma)}}+\frac{\mu_{5}}{b_{N_s-2}^{(\beta, \sigma)}-b_{N_s-1}^{(\beta, \sigma)}}+\frac{\mu_{6}}{b_{N_s-1}^{(\beta, \sigma)}-b_{N_s}^{(\beta, \sigma)}}. \end{equation*}$

4.2. Stability analysis

The variational formulation of the proposed scheme can be obtained by means of (3.17), (3.20) side by side to Lemma 3.2. More specifically, we need to find $\{ \Theta_{N}^{k}\}_{k = 1}^{M}\in \mathcal {P} _N$ , such that satisfying the following:

$\begin{align} \left(D_{\tau}^{\beta} \Theta_{N}^{k+\sigma}, \upsilon_N \right) + A\left(\Theta_N^{k+\sigma}, \upsilon_N \right) & = \left(I_N F\left((\sigma+1) \Theta_N^{k} -\sigma \ \Theta_N^{k-1}, \sigma \ \Theta_N^{k+1-N_s}+(1-\sigma) \Theta_N^{k-N_s} \right), \upsilon \right)\\ &+\left(I_N G^{k+\sigma}, \upsilon \right), \ \forall \upsilon_{N}\in \mathcal {P} _N, \end{align}$

(4.38)

with initial conditions

$\begin{equation*} \Theta _{N}^{k} = \pi_{N}^{1, 0} \psi^{k}, \ -N_s\leq k\leq 0. \end{equation*}$

Due to the linear iterative nature of the method, a solution to an algebraic equation system is all that is required at each iteration. The suggested scheme's well-posedness, meaning it is uniquely solvable and continues to rely on its initial boundary conditions which is sufficient to hold the Lax-Milgram lemma's assumptions ^[56]. In particular, it can be seen from Eq (4.38) that the bilinear shape $A(\cdot, \cdot)$ is continuous as well as coercive related to $H_0^{\alpha/2} \times H_0^{\alpha/2}$ . We further presume that $\{\tilde{ \Theta }_{N}^{k}\}_{k = 1}^{M}$ is the solution of the following variational form

$\begin{align} \left(D_{\tau}^{\beta}\tilde{\Theta}_N^{k+\sigma}, \upsilon_{N}\right)+A\left(\tilde{\Theta}_N^{k+\sigma}, \upsilon_{N}\right)& = \left(I_N F\left((\sigma+1) \tilde{\Theta}_N^{k} -\sigma \tilde{\Theta}_N^{k-1}, \sigma \tilde{\Theta}_N^{k+1-N_s}+(1-\sigma) \tilde{\Theta}_N^{k-N_s} \right), \upsilon \right)\\ &+\left(I_N\, \tilde{G}^{k+\sigma}, \upsilon_{N}\right), \ \forall \upsilon_{N}\in \mathcal {P} _N, \end{align}$

(4.39)

with initial conditions

$\begin{equation*} \tilde{ \Theta }_{N}^{k} = \pi_{N}^{1, 0} \psi^{k}, \ \ -N_{\bf s}\leq k\leq 0. \end{equation*}$

Now, we are ready to offer the stability theorem in the context of the subsequent discussion.

Theorem 4.1. The suggested method (4.38) in this sense, is said to be unconditionally stable, which means it holds the following for $\tau > 0$ ,

$\begin{equation*} \left\lVert{\Theta _{N}^{k+\sigma}-\tilde{\Theta }_{N}^{k+\sigma}}\right\rVert^{2}\leq C \max\limits_{1\leq k\leq M} \left\lVert{G^{k+\sigma}-\tilde{G}^{k+\sigma}}\right\rVert^{2}. \end{equation*}$

where $C$ is a generic positive constant independent of $N$ and $\tau$ .

Proof. Subtracting (4.39) from (4.38) and by taking $\Theta _{N}^{k}-\tilde{ \Theta }_{N}^{k}: = \eta_{N}^{k}$ , then the error equation holds

$\begin{align} \left(D_{\tau}^{\beta}\eta_{N}^{k+\sigma}, \ \upsilon_{N}\right)+A\left(\eta_{N}^{k+\sigma}, \ \upsilon_{N}\right) & = \left(I_N\, F\left((\sigma+1) \Theta _N^{k} -\sigma \Theta _N^{k-1}, \sigma \Theta _N^{k+1-N_s}+(1-\sigma) \Theta ^{k-N_s} \right) \right. \\ &\left. \quad - I_N\, F\left((\sigma+1) \tilde{\Theta}_N^{k} -\sigma \tilde{\Theta}_N^{k-1}, \sigma \tilde{\Theta}_N^{k+1-N_s}+(1-\sigma) \tilde{\Theta}_N^{k-N_s} \right), \ \upsilon_{N}\right) \\ &+ \left( I_N\, G^{k+\sigma}- I_N\, \tilde{G}^{k+\sigma}, \ \upsilon_{N} \right). \end{align}$

(4.40)

Applying the Lipschitz condition (4.31) and using Hölder inequality side by side to Young inequality, we derive the following for the first term of the right-hand side

$\begin{align*} & \left(I_N\, F\left((\sigma+1) \Theta _N^{k} -\sigma \Theta _N^{k-1}, \sigma \Theta _N^{k+1-N_s}+(1-\sigma) \Theta _N^{k-N_s} \right) \right. \\ & \quad \left.-I_N\, F \left((\sigma+1) \tilde{\Theta}_N^{k} -\sigma \tilde{\Theta}_N^{k-1}, \sigma \tilde{\Theta}_N^{k+1-N_s}+(1-\sigma) \tilde{\Theta}_N^{k-N_s} \right), \ \upsilon_{N}\right) \\ &\leq C L \left( \left\lVert{(\sigma+1) \eta_{N}^k -\sigma \eta_{N}^{k-1}}\right\rVert + \left\lVert{\sigma \eta_{N}^{k+1-N_s} -(1-\sigma) \eta_{N} ^{k-N_s} }\right\rVert \right) \left\lVert{\upsilon_{N}}\right\rVert \\ &\leq \epsilon C L^{2} \left\lVert{(\sigma+1) \eta_{N}^k -\sigma \eta_{N}^{k-1}}\right\rVert^2 + \epsilon C L^{2} \left\lVert{\sigma \eta_{N}^{k+1-N_s} -(1-\sigma) \eta_{N} ^{k-N_s} }\right\rVert^2 +\frac{1}{2 \epsilon} \left\lVert{\upsilon_{N}}\right\rVert^2 \\ &{ \leq 2 \epsilon C L^2 (\sigma+1)^2 \left\lVert{\eta_{N}^k }\right\rVert^2 + 2 \epsilon C L^2 \sigma^2 \left\lVert{\eta_{N}^{k-1}}\right\rVert^2 + 2 \epsilon C L^2 \sigma^2 \left\lVert{\eta_{N}^{k+1-N_s}}\right\rVert^2 +2 \epsilon C L^2 (1-\sigma)^2 \left\lVert{\eta_{N}^{k-N_s}}\right\rVert^2 + \frac{1}{2 \epsilon} \left\lVert{\upsilon_{N}}\right\rVert^2.} \end{align*}$

Using the Hölder inequality, the Young inequality, as well as the interpolation operator property, we obtain the second term as

$\begin{equation*} \left( I_N\, G^{k+\sigma}- I_N\, \tilde{G}^{k+\sigma}, \ \upsilon_{N} \right) \leq \frac{\epsilon}{2} C \left\lVert{G^{k+\sigma}- \tilde{G}^{k+\sigma}}\right\rVert^2 +\frac{1}{2 \epsilon} \left\lVert{\upsilon_{N}}\right\rVert^2. \end{equation*}$

Hence, (4.40) becomes

$\begin{align*} \left (D_{\tau}^{\beta}\eta_{N}^{k+\sigma}, \ \upsilon_{N})+A(\eta_{N}^{k+\sigma}, \ \upsilon_{N}\right) &\leq \frac{1}{\epsilon}\left\lVert{\upsilon_{N}}\right\rVert^{2}+ 2 \epsilon C L^2 (\sigma+1)^2 \left\lVert{\eta_{N}^k }\right\rVert^2 + 2 \epsilon C L^2 \sigma^2 \left\lVert{\eta_{N}^{k-1}}\right\rVert^2 + 2 \epsilon C L^2 \sigma^2 \left\lVert{\eta_{N}^{k+1-N_s}}\right\rVert^2 \\ &+2 \epsilon C L^2 (1-\sigma)^2 \left\lVert{\eta_{N}^{k-N_s}}\right\rVert^2 \quad + \frac{\epsilon}{2} C \left\lVert{G^{k+\sigma}- \tilde{G}^{k+\sigma}}\right\rVert^2. \end{align*}$

Taking $\upsilon_{N} = \eta_{N}^{k+\sigma}$ and using lemma 4.6 and (4.34), we deduce that

$\begin{align*} \frac{1}{2}D_{\tau}^{\beta} \left\lVert{\eta_{N}^{k+\sigma}}\right\rVert^{2}+|\eta_{N}^{k+\sigma}|_{\alpha/2}^{2} &\leq \frac{1}{\epsilon}\left\lVert{\eta_{N}^{k+\sigma}}\right\rVert^{2}+2 \epsilon C L^{2} (\sigma+1)^2 \left\lVert{\eta_{N}^{k}}\right\rVert^2 +2 \epsilon C L^{2}\sigma^2 \left\lVert{\eta_{N}^{k-1}}\right\rVert^2 +2 \epsilon C L^{2} \sigma^2 \left\lVert{\eta_{N}^{k+1-N_s}}\right\rVert^2 \\ & \quad +2 \epsilon C L^{2} (1-\sigma)^2 \left\lVert{\eta_{N}^{k-N_s}}\right\rVert^2 + \frac{\epsilon}{2} C \left\lVert{G^{k+\sigma}- \tilde{G}^{k+\sigma}}\right\rVert^2, \end{align*}$

following the omission of the second term in the left hand side, we have

$\begin{align*} D_{\tau}^{\beta} \left\lVert{\eta_{N}^{k+\sigma}}\right\rVert^{2} &\leq \frac{2}{\epsilon}\left\lVert{\eta_{N}^{k+\sigma}}\right\rVert^{2}+ 4 \epsilon C L^{2} (\sigma+1)^2 \left\lVert{\eta_{N}^{k}}\right\rVert^2 +4 \epsilon C L^{2}\sigma^2 \left\lVert{\eta_{N}^{k-1}}\right\rVert^2 + 4 \epsilon C L^{2} \sigma^2 \left\lVert{\eta_{N}^{k+1-N_s}}\right\rVert^2 \\ & \quad + 4 \epsilon C L^{2} (1-\sigma) \left\lVert{\eta_{N}^{k-N_s}}\right\rVert^2 + \epsilon C \left\lVert{G^{k+\sigma}- \tilde{G}^{k+\sigma}}\right\rVert^2 \\ & { \leq \frac{4}{\epsilon}(\sigma+1)^2 (1+C \epsilon^2 L^2) \left\lVert{\eta_{N}^{k}}\right\rVert^2 + \frac{4}{\epsilon} \sigma^2 (1+C \epsilon^2 L^2) \left\lVert{\eta_{N}^{k-1}}\right\rVert^2 + 4 \epsilon C L^{2} \sigma^2 \left\lVert{\eta_{N}^{k+1-N_s}}\right\rVert^2 }\\ & { \quad + 4 \epsilon C L^{2} (1-\sigma)^2 \left\lVert{\eta_{N}^{k-N_s}}\right\rVert^2 + \epsilon C \left\lVert{G^{k+\sigma}- \tilde{G}^{k+\sigma}}\right\rVert^2.} \end{align*}$

A direct application of the Grönwall inequality (see Lemma 4.7), we find that for $\epsilon > 0$ , there exists a positive independent constant $\tau^{*} = \sqrt[\beta]{{1}/\left(2\Gamma \left(2-\beta \right) \ \frac{4}{\epsilon}\left(\sigma+1 \right)^2 \left(1+C \epsilon^2 L^2 \right) \right)}$ , such that when $\tau < \tau^{*}$ , the following is hold

$\begin{equation*} \left\lVert{\eta_{N}^{k+\sigma}}\right\rVert^{2} \leq\frac{2 \epsilon C t_{k}^{\beta}}{\Gamma(1+\beta)}E_{\beta}(2\mu t_{k}^{\beta}) \max\limits_{1\leq k\leq M}\left\lVert{G^{k}-\tilde{G}^{k}}\right\rVert^{2}, \end{equation*}$

with

$\begin{equation*} { \mu = \frac{4}{\epsilon}(\sigma+1)^2 (1+C \epsilon^2 L^2)+\frac{4}{\epsilon}\frac{\sigma^2 (1+C \epsilon^2 L^2)}{b_0^{(\beta, \sigma)}-b_1^{(\beta, \sigma)}}+\frac{4 \epsilon C L^{2} \sigma^2 }{b_{N_s-2}^{(\beta, \sigma)}-b_{N_s-1}^{(\beta, \sigma)}} +\frac{4 \epsilon C L^{2} (1-\sigma)^2}{b_{N_s-1}^{(\beta, \sigma)}-b_{N_s}^{(\beta, \sigma)}}.} \end{equation*}$

Therefore, the proposed method is guaranteed to be unconditionally stable.

4.3. Convergence

Here, we present the proof of the convergence theorem for the suggested scheme (4.38) using discrete error estimates.

Theorem 4.2. Let $\{ \Theta^{k}\}_{k = -N_s}^{M}$ and $\{ \Theta _{N}^{k}\}_{k = -N_s}^{M}$ , be the exact and the approximate solutions of problem (1.1) and the proposed method (4.38), respectively. Assume that $\Theta \in C^2\left([0, T]; L^2(\Omega)\right)\cap C^1\left([0, T]; H^{{s}}(\Omega)\right)$ . Then for an arbitrary constant $C$ independent of $N$ and $\tau$ , the following statement is valid

$\begin{equation} { \left|\Theta ^{k+\sigma}- \Theta _N^{k+\sigma}\right|_{\alpha/2}\leq C \left( \tau^{2}+ N^{-r} \right), \quad 1\leq k\leq M, } \end{equation}$

(4.41)

where $r$ is the source term's regularity order.

Proof. Take $\Theta^{k}- \Theta _N^{k} = \xi_N ^k = (\Theta ^{k}-\pi_{N}^{\frac{\alpha}{2}, 0} \Theta ^{k})+(\pi_{N}^{\frac{\alpha}{2}, 0} \Theta^{k}- \Theta _N^{k}) \overset{\Delta}{ = }\tilde{\xi}_{N}^{k}+\hat{\xi}_{N}^{k}$ . In addition, (1.1) has the following weak formulation:

$\begin{equation} \left(_{0}^{C}D_{t}^{\beta} \Theta^{k+\sigma}, \ \upsilon_{N} \right)+ A\left( \Theta ^{k+\sigma}, \ \upsilon_{N}\right) = \left(F \left( \Theta ^{k+\sigma}, \Theta ^{k+\sigma-N_s}\right), \ \upsilon_{N} \right) +\left( G^{k+\sigma}, \ \upsilon_{N} \right). \end{equation}$

(4.42)

By subtracting (4.38) from (4.42), and using the notion of orthogonal projection, then the error equation satisfies

$\begin{equation} (D_{\tau}^{\beta} \ \hat{\xi}_{N}^{k+\sigma}, \ \upsilon_{N})+A (\hat{\xi}_{N}^{k+\sigma}, \upsilon_{N})\overset{\Delta}{ = } \rho_{1}^{(k, \sigma)}+\rho_{2}^{(k, \sigma)}+\rho_{3}^{(k, \sigma)}+\rho_{4}^{(k, \sigma)}, \end{equation}$

(4.43)

where

$\begin{align*} \rho_{1}^{(k, \sigma)}& = \left(I_N F\left( \Theta^{k+\sigma}, \ \Theta^{k+\sigma-N_s}\right)-I_N F \left((\sigma+1) \Theta _{N}^{k}- \sigma \Theta _{N}^{k-1}, \ \sigma \Theta _{N}^{k+1-N_s}+(1-\sigma ) \Theta _{N}^{k-N_s} \right), \ \upsilon_{N}\right), \\ \rho_{2}^{(k, \sigma)}& = \left(F \left( \Theta ^{k+\sigma}, \ \Theta^{k+\sigma-N_s} \right) -I_N F \left( \Theta^{k+\sigma}, \ \Theta^{k+\sigma-N_s} \right), \ \upsilon_{N}\right), \\ \rho_{3}^{(k, \sigma)}& = \left(D_{\tau}^{\beta}\ \pi_{N}^{\frac{\alpha}{2}, 0} \Theta ^{k+\sigma}-_{0}^{C}D_{t}^{\beta} \Theta ^{k+\sigma}, \ \upsilon_{N}\right), \\ \rho_{4}^{(k, \sigma)}& = \left(G ^{k+\sigma} - I_N G^{k+\sigma}, \ \upsilon_{N} \right). \end{align*}$

To proceed, we make an estimate of the terms $\rho_{1}^{(k, \sigma)}$ , $\rho_{2}^{(k, \sigma)}$ , $\rho_{3}^{(k, \sigma)}$ and $\rho_{4}^{(k, \sigma)}$ on the right-hand side. Regarding the first term $\rho_{1}^{(k, \sigma)}$ , we have

$\begin{align} \rho_{1}^{(k, \sigma)} = & \left(I_N F \left( \Theta^{k+\sigma}, \ \Theta^{k+\sigma-N_s}\right)-I_N F \left((\sigma+1) \Theta^{k}- \sigma \Theta^{k-1}, \ \sigma \Theta^{k+1-N_s}+(1-\sigma) \Theta^{k-N_s} \right), \ \upsilon_{N} \right) \\ &+\left(I_N F \left((\sigma+1) \Theta ^{k}- \sigma \Theta^{k-1}, \sigma \Theta^{k+1-N_s}+(1-\sigma) \Theta^{k-N_s} \right) \right. \\ &\quad \left.-I_N F \left((\sigma+1) \Theta _{N}^{k}- \sigma \Theta _{N}^{k-1}, \ \sigma \Theta _{N}^{k+1-N_s}+(1-\sigma ) \Theta _{N}^{k-N_s} \right), \ \upsilon_{N} \right) \\ \overset{\Delta}{ = }&\rho_{11}^{(k, \sigma)}+\rho_{12}^{(k, \sigma)}. \end{align}$

(4.44)

Invoking Taylor expansion holds

$\begin{align*} F \left( \Theta^{k+\sigma}, \ \Theta^{k+\sigma-N_s} \right) & = f \left((\sigma+1) \Theta^{k}- \sigma \Theta^{k-1}, \sigma \Theta^{k+1-N_s}+(1+\sigma) \Theta^{k-N_s}\right)+\tilde{c}_{ \Theta}\tau^{2}. \end{align*}$

In addition, we use Hölder's and Young's inequalities to

$\begin{align} \rho_{11}^{(k, \sigma)}&\leq \left\lVert{I_N F\left( \Theta^{k+\sigma}, \ \Theta^{k+\sigma-N_s} \right)-I_N F \left((\sigma+1) \Theta^{k}- \sigma \Theta^{k-1}, \sigma \Theta ^{k+1-N_s}+(1-\sigma) \Theta^{k-N_s} \right)}\right\rVert \ \left\lVert{\upsilon_{N}}\right\rVert \\ &\leq C \left\lVert{ F\left( \Theta^{k+\sigma}, \ \Theta^{k+\sigma-N_s} \right)- F \left((\sigma+1) \Theta^{k}- \sigma \Theta^{k-1}, \sigma \Theta^{k+1-N_s}+(1-\sigma) \Theta^{k-N_s} \right)}\right\rVert \ \left\lVert{\upsilon_{N}}\right\rVert \\ &\leq \frac{\epsilon}{2} C \tilde{c}_{ \Theta }\tau^{4}+\frac{1}{2\epsilon}\left\lVert{\upsilon_{N}}\right\rVert^{2}. \end{align}$

(4.45)

By plugging into the Lipschitz condition (4.31) and using Hölder inequality side by side to Young inequality, we deduce that

$\begin{align} \rho_{12}^{(k, \sigma)}& \leq L C \left(\left\lVert{(\sigma+1) \xi_{N}^{k}- \sigma \xi_{N}^{k-1} }\right\rVert+\left\lVert{ \sigma \xi_{N}^{k+1-N_s} +(1-\sigma) \xi_{N}^{k-N_s}}\right\rVert \right) \left\lVert{\upsilon_{N}}\right\rVert \\ &\leq \frac{\epsilon}{2} C L^2 \left( \left\lVert{(\sigma+1) \hat{\xi}_{N}^{k}- \sigma \hat{\xi}_{N}^{k-1}}\right\rVert+\left\lVert{\sigma \hat{\xi}_{N}^{k+1-N_s}+(1-\sigma) \hat{\xi}_N^{k-N_s}}\right\rVert+\left\lVert{(\sigma+1)\tilde{\xi}_{N}^{k}- \sigma \tilde{\xi}_{N}^{k-1}}\right\rVert\right. \\ &\left. \quad +\left\lVert{\sigma \tilde{\xi}_{N}^{k+1-N_s}-(1-\sigma)\tilde{\xi}_N^{k-N_s}}\right\rVert \right)^2 +\frac{1}{2 \epsilon} \left\lVert{\upsilon_{N}}\right\rVert^2 \\ &{ \leq 2 \epsilon C L^2 (\sigma+1)^2 \left\lVert{\hat{\xi}_{N}^{k}}\right\rVert^2 +2 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k-1}}\right\rVert^2+2 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k+1-N_s}}\right\rVert^2 +2 \epsilon C L^2 (1-\sigma)^2 \left\lVert{\hat{\xi}_{N}^{k-N_s}}\right\rVert^2} \\ &\quad{+ 2 \epsilon C L^2 (\sigma+1)^2 \left\lVert{\tilde{\xi}_{N}^{k}}\right\rVert^2 +2 \epsilon C L^2 \sigma^2 \left\lVert{\tilde{\xi}_{N}^{k-1}}\right\rVert^2+2 \epsilon C L^2 \sigma^2 \left\lVert{\tilde{\xi}_{N}^{k+1-N_s}}\right\rVert^2} \\ &\quad+2 \epsilon C L^2 (1-\sigma)^2 \left\lVert{\tilde{\xi}_{N}^{k-N_s}}\right\rVert^2 + \frac{1}{2 \epsilon} \left\lVert{\upsilon_{N}}\right\rVert^2. \end{align}$

(4.46)

In addition, considering the Lemmas 4.1 and 4.2, it can be shown that

$\begin{align*} &\left\lVert{\tilde{\xi}_{N}^{k}}\right\rVert^2\leq \frac{C}{C_1} N^{\alpha-2s} \left\lVert{\Theta ^{k}}\right\rVert_{s}^{2}, \qquad \left\lVert{\tilde{\xi}_{N}^{k-1}}\right\rVert^2\leq \frac{C}{C_1} N^{\alpha-2s} \left\lVert{\Theta^{k-1}}\right\rVert_{s}^{2}, \\ &\left\lVert{\tilde{\xi}_{N}^{k+1-N_s}}\right\rVert^{2} \leq \frac{C}{C_1} N^{\alpha-2s} \left\lVert{\Theta ^{k+1-N_s}}\right\rVert_{s}^{2}, \qquad \left\lVert{\tilde{\xi}_{N}^{k-N_s}}\right\rVert^{2}\leq \frac{C}{C_1} N^{\alpha-2s}\left\lVert{\Theta ^{k-N_s}}\right\rVert^{2}, \end{align*}$

then (4.46) becomes

$\begin{align} \rho_{12}^{(k, \sigma)}\leq & 2 \epsilon C L^2 (\sigma+1)^2 \left\lVert{\hat{\xi}_{N}^{k}}\right\rVert^2 +2 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k-1}}\right\rVert^2+2 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k+1-N_s}}\right\rVert^2 \\ &+2 \epsilon C L^2 (1-\sigma)^2 \left\lVert{\hat{\xi}_{N}^{k-N_s}}\right\rVert^2+\tilde{C} N^{\alpha-2s} \left\lVert{\Theta}\right\rVert_{s}^{2}+\frac{1}{2\epsilon} \left\lVert{\upsilon_{N}}\right\rVert^{2}. \end{align}$

(4.47)

Substituting (4.45) and (4.47) into (4.44), we obtain that

$\begin{align} \rho_{1}^{(k, \sigma)} \leq &\frac{1}{\epsilon}\left\lVert{\upsilon_{N}}\right\rVert^{2}+2 \epsilon C L^2 (\sigma+1)^2 \left\lVert{\hat{\xi}_{N}^{k}}\right\rVert^2 +2 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k-1}}\right\rVert^2+2 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k+1-N_s}}\right\rVert^2 \\ &+2 \epsilon C L^2 (1-\sigma)^2 \left\lVert{\hat{\xi}_{N}^{k-N_s}}\right\rVert^2 +\tilde{C} N^{\alpha-2s} \left\lVert{\Theta}\right\rVert_{s}^{2}+\frac{\epsilon}{2}\tilde{c}_{\Theta}\tau^{4}. \end{align}$

(4.48)

Hölder's inequality, Young's inequality, and Lemma 4.4 allow us to deduce the following for the second term $\rho_{2}^{(k, \sigma)}$ as follows:

$\begin{align} \rho_{2}^{(k, \sigma)} &\leq \left\lVert{ F \left( \Theta^{k+\sigma}, \ \Theta^{k+\sigma-N_s}\right)- I_N F \left( \Theta ^{k+\sigma}, \ \Theta ^{k+\sigma-N_s}\right)}\right\rVert \ \left\lVert{\upsilon_{N}}\right\rVert \\ & \leq \frac{\epsilon}{2} \left\lVert{ F \left( \Theta ^{k+\sigma}, \ \Theta ^{k+\sigma-N_s} \right)- I_N F \left( \Theta^{k+\sigma}, \ \Theta^{k+\sigma-N_s} \right)}\right\rVert^2 + \frac{1}{2 \epsilon} \left\lVert{\upsilon_{N}}\right\rVert^2 \\ & \leq \frac{1}{2\epsilon} \left\lVert{\upsilon_{N}}\right\rVert^2+\frac{\epsilon}{2} C N^{-2r}\left\lVert{ \Theta}\right\rVert_{s}^2. \end{align}$

(4.49)

For the third term $\rho_{3}^{(k, \sigma)}$ , it holds

$\begin{align} \rho_{3}^{(k, \sigma)}& = \left(D_{\tau}^{\beta}\pi_{N}^{\frac{\alpha}{2}, 0} \Theta^{k+\sigma}-_{0}^{C}D_{t}^{\beta}\pi_{N}^{\frac{\alpha}{2}, 0} \Theta ^{k+\sigma}, \upsilon_{N} \right)+\left(_{0}^{C}D_{t}^{\beta}\pi_{N}^{\frac{\beta}{2}, 0} \Theta^{k+\sigma}-_{0}^{C}D_{t}^{\beta} \Theta^{k+\sigma}, \upsilon_{N}\right) \\ & = \left(\pi_{N}^{\frac{\alpha}{2}, 0} \left(D_{\tau}^{\beta} \Theta ^{k+\sigma}-_{0}^{C}D_{t}^{\alpha} \Theta^{k+\sigma} \right), \upsilon_{N} \right)-\left(_{0}^{C}D_{t}^{\beta}\tilde{\xi}_{N}^{k+\sigma}, \ \upsilon_{N} \right) \\ &\overset{\Delta}{ = }\rho_{31}^{(k, \sigma)}+\rho_{32}^{(k, \sigma)}, \end{align}$

(4.50)

combining 3.1 with Hölder inequality and Young inequality yields

$\begin{align*} \rho_{31}^{(k, \sigma)} & \leq \frac{\epsilon}{2} \left\lVert{\pi_{N}^{\frac{\alpha}{2}, 0}\left(D_{\tau}^{\beta} \Theta ^{k+\sigma}-_{0}^{C}D_{t}^{\beta} \Theta^{k+\sigma} \right)}\right\rVert^{2}+\frac{1}{2\epsilon} \left\lVert{\upsilon_{N}}\right\rVert^{2} \\ &\leq\frac{\epsilon}{2} C \left\lVert{ D_{\tau}^{\beta} \Theta ^{k+\sigma}-_{0}^{C}D_{t}^{\beta} \Theta^{k+\sigma }}\right\rVert^{2}+\frac{1}{2\epsilon} \left\lVert{\upsilon_{N}}\right\rVert^{2} \\ &\leq \frac{\epsilon}{2}C{\Theta }\tau^{9-2\beta}+\frac{1}{2\epsilon} \left\lVert{\upsilon_{N}}\right\rVert^{2}, \end{align*}$

furthermore, by means of Lemma 4.1, we have

$\begin{align*} \rho_{32}^{(k, \sigma)}& \leq \frac{\epsilon}{2} C N^{\alpha-2s} \left\lVert{_{0}^{C}D_{t}^{\beta} \Theta ^{k+\sigma}}\right\rVert_{s}^{2}+\frac{1}{2} \left\lVert{\upsilon_{N}}\right\rVert^{2} \\ &\leq \frac{\epsilon}{2} C N^{\alpha-2s} \left\lVert{_{0}^{C}D_{t}^{\beta} \Theta}\right\rVert_{s}^{2}+\frac{1}{2\epsilon} \left\lVert{\upsilon_{N}}\right\rVert^{2}. \end{align*}$

Thus (4.50) becomes

$\begin{equation} \rho_{3}^{(k, \sigma)}\leq \frac{1}{\epsilon} \left\lVert{\upsilon_{N}}\right\rVert^{2}+\frac{\epsilon}{2} C N^{\alpha-2s} \left\lVert{_{0}^{C}D_{t}^{\beta} \Theta}\right\rVert_{s}^{2}+\frac{\epsilon}{2} C_{\Theta}\tau^{9-2\beta}. \end{equation}$

(4.51)

By the aid of Remark 4.1, we obtain the following for the fourth term $\rho_{4}^{(k, \sigma)}$

$\begin{align} \rho_{4}^{(k, \sigma)}&\leq \frac{\epsilon}{2} C N^{\alpha-2r}\left\lVert{ \Theta }\right\rVert_{r}^2 +\frac{1}{2\epsilon} \left\lVert{\upsilon_{N}}\right\rVert^2. \end{align}$

(4.52)

Substituting (4.48), (4.49), (4.51) and (4.52) into (4.43), we can infer that

$\begin{align} (D_{\tau}^{\beta}\hat{\xi}_{N}^{k+\sigma}, \ \upsilon_{N})+A (\hat{\xi}_{N}^{k+\sigma}, \upsilon_{N}) &\leq\frac{3}{\epsilon} \left\lVert{\upsilon_{N}}\right\rVert^{2}+2 \epsilon C L^2 (\sigma+1)^2 \left\lVert{\hat{\xi}_{N}^{k}}\right\rVert^2 +2 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k-1}}\right\rVert^2+2 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k+1-N_s}}\right\rVert^2 \\ &\quad+2 \epsilon C L^2 (1-\sigma)^2 \left\lVert{\hat{\xi}_{N}^{k-N_s}}\right\rVert+\tilde{R}, \end{align}$

(4.53)

where

$\begin{equation*} \tilde{R} = \epsilon \tilde{C} N^{\alpha-2s}\left( \left\lVert{\Theta}\right\rVert_{s}^{2} +\left\lVert{_{0}^{C}D_{t}^{\beta} \Theta}\right\rVert_{s}^{2}\right)+\epsilon \tilde {C} N^{-2r} \left\lVert{\Theta}\right\rVert_{r}^{2}+\epsilon \tilde {C}_{\Theta} \left(\tau^{4}+\tau^{9-2\beta} \right). \end{equation*}$

Taking $\upsilon_{N} = \hat{\xi}_{N}^{k+\sigma}$ in (4.53) and applying Lemma 4.6, we can conclude that

$\begin{align*} \frac{1}{2} D_{\tau}^{\beta} \left\lVert{\hat{\xi}_{N}^{k+\sigma}}\right\rVert^{2}+|\hat{\xi}_{N}^{k+\sigma}|_{\alpha/2}^{2} &\leq \frac{3}{\epsilon} \left\lVert{\hat{\xi}_{ N}^{k+\sigma}}\right\rVert^{2}+2 \epsilon C L^2 (\sigma+1)^2 \left\lVert{\hat{\xi}_{N}^{k}}\right\rVert^2 +2 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k-1}}\right\rVert^2+2 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k+1-N_s}}\right\rVert^2 \\ &\quad+2 \epsilon C L^2 (1-\sigma)^2 \left\lVert{\hat{\xi}_{N}^{k-N_s}}\right\rVert+\tilde{R}, \end{align*}$

hence, after omitting the second term on the left side of the above equation, we get

$\begin{align} D_{\tau}^{\beta} \left\lVert{\hat{\xi}_{N}^{k+\sigma}}\right\rVert^{2} &\leq \frac{6}{\epsilon} \left\lVert{\hat{\xi}_{ N}^{k+\sigma}}\right\rVert^{2}+ 4 \epsilon C L^2 (\sigma+1)^2 \left\lVert{\hat{\xi}_{N}^{k}}\right\rVert^2 +4 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k-1}}\right\rVert^2+ 4 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k+1-N_s}}\right\rVert^2 \\ &\quad +4 \epsilon C L^2 (1-\sigma)^2 \left\lVert{\hat{\xi}_{N}^{k-N_s}}\right\rVert+R \\ & { \leq \frac{4}{\epsilon}(\sigma+1)^2 (3+C \epsilon^2 L^2) \left\lVert{\hat{\xi}^{k}}\right\rVert^2 + \frac{4}{\epsilon} \sigma^2 (3+C \epsilon^2 L^2) \left\lVert{\hat{\xi}^{k-1}}\right\rVert^2 + 4 \epsilon C L^2 \sigma^2 \left\lVert{\hat{\xi}_{N}^{k+1-N_s}}\right\rVert^2 } \\ &\quad { +4 \epsilon C L^2 (1-\sigma)^2 \left\lVert{\hat{\xi}_{N}^{k-N_s}}\right\rVert+R, } \end{align}$

(4.54)

with $R = 2\tilde{R}$ . By means of Lemma 4.7 we find that for $\epsilon > 0$ , there is some positive independent constant $\tau^{*} = \sqrt[\beta]{{1}/\left(2\Gamma(2-\beta) \ \frac{4}{\epsilon}(\sigma+1)^2 (3+C \epsilon^2 L^2) \right)}$ , when $\tau < \tau^{*}$ , we have

$\begin{equation*} \left\lVert{\hat{\xi}_{N}^{k+\sigma}}\right\rVert^{2} \leq\frac{2 R C t_{k}^{\beta}}{\Gamma(1+\beta)}E_{\beta}(2\mu t_{k}^{\beta}), \end{equation*}$

with

$\begin{equation*} { \mu = \frac{4}{\epsilon}(\sigma+1)^2 (3+C \epsilon^2 L^2)+\frac{4}{\epsilon}\frac{\sigma^2 (3+C \epsilon^2 L^2)}{b_0^{(\beta, \sigma)}-b_1^{(\beta, \sigma)}}+\frac{4 \epsilon C L^{2} \sigma^2 }{b_{N_s-2}^{(\beta, \sigma)}-b_{N_s-1}^{(\beta, \sigma)}} +\frac{4 \epsilon C L^{2} (1-\sigma)^2}{b_{N_s-1}^{(\beta, \sigma)}-b_{N_s}^{(\beta, \sigma)}}. } \end{equation*}$

Consequently, the scheme converges regardless of circumstances. The triangle inequality and (4.36) were then combined to complete the (4.41) proof.

5. Numerical experiments

As such, we perform a test example to further characterize the suggested system's temporal and spatial convergence orders. We also show how the dynamics of the solution to systems of fractional diffusion equations with delay are affected by fractional orders in the temporal and spatial directions. In order to investigate both temporal and spatial convergence orders independently, we will determine the orders of convergence in both using the $L2-$ Error norms, which are described as follows:

$\begin{equation*} \text{ Order} = \frac{{\ln \left( {\left\| {Error \left( {N, M_1 } \right)} \right\|/\left\| {Error \left( {N , M_2 } \right)} \right\|} \right)}}{{\ln \left( {M_1 /M_2 } \right)}}, \end{equation*}$

where $M_1 \neq M_2$ .

Example 1. Consider the following nonlinear delayed diffusion problem

$\begin{equation} \frac {\partial ^\beta \Theta } {\partial t ^\beta} (x, t) = \frac {\partial ^\alpha \Theta } {\partial |x|^\alpha} (x, t) - 2 \Theta (x, t) + \frac{{ \Theta (x, t - 0.1)}}{{1 + \Theta ^2 (x, t - 0.1)}}+G(x, t), \quad x \in (0, 1), \quad t \in (0, 1], \end{equation}$

(5.55)

such that problem (5.55) admits an exact solution $\frac{t^2}{\Gamma(3)}x^2(1-x)^2$ with respect to a given function $G(x, t)$ .

As shown in , a comparison between the L2-errors and their accompanying convergence orders for different values of $\alpha$ and $\beta$ with $N = 100$ for both $L1$ and $L2-1_\sigma$ schemes are listed. It is shown that $2-\beta$ temporal accuracy has been reached for the $L^2$ -errors in the case of $L1$ scheme, (see our previous work ^[48]), while a high order of second temporal accuracy has been reached for the $L^2$ -errors in case $L2-1_\sigma$ scheme which accords with the temporal order of convergence provided by Theorem 4.2. Orders of spatial convergence are shown for various values of $\alpha$ values at $\tau = 1/500$ in . In addition, when the $L^2$ errors diminish exponentially, spatial-spectral accuracy increases for a smooth solution. The convergence findings coincide completely with the theoretical ones. At each level of convergence, we see full concordance between theoretical and experimental results.

Table 1. The rate of convergence and the associate errors for

$\Theta$ versus

$N$ and

$\tau$ with

$N = 100$ for example 1.

	$\tau$	$\alpha-1=\beta=0.1$		$\alpha-1=\beta=0.5$		$\alpha-1=\beta=0.9$
	$\tau$	Error	Order	Error	Order	Error	Order
	0.1/5	$2.612 \times 10^{-7}$	--	$4.076\times10^{-6}$	--	$2.449\times10^{-5}$	--
	0.1/10	$7.466\times 10^{-8}$	$1.807$	$1.454\times 10^{-6}$	$1.487$	$1.143\times 10^{-5}$	$1.099$
L1-scheme	0.1/15	$3.588\times 10^{-8}$	$1.807$	$7.943\times 10^{-7}$	$1.491$	$7.319\times 10^{-6}$	$1.100$
	0.1/20	$2.156 \times 10^{-8}$	$1.771$	$5.168 \times10^{-7}$	$1.494$	$5.334 \times10^{-6}$	$1.100$
	0.1/25	$1.481\times 10^{-8}$	$1.682$	$3.702\times 10^{-7}$	$1.495$	$4.173\times 10^{-6}$	$1.100$
	0.1/5	$2.341 \times 10^{-7}$	--	$1.030\times10^{-6}$	--	$1.909\times10^{-6}$	--
	0.1/10	$5.893\times 10^{-8}$	$1.990$	$2.572\times 10^{-7}$	$2.001$	$4.773\times 10^{-7}$	$1.999$
$L2-1_\sigma$ scheme	0.1/15	$2.622\times 10^{-8}$	$1.997$	$1.143\times 10^{-7}$	$2.000$	$2.122\times 10^{-7}$	$1.999$
	0.1/20	$1.473 \times 10^{-8}$	$2.004$	$6.435\times10^{-8}$	$1.997$	$1.194 \times10^{-7}$	$1.997$
	0.1/25	$9.405\times 10^{-9}$	$2.010$	$4.123\times 10^{-8}$	$1.995$	$7.652\times 10^{-8}$	$1.995$

| Show Table

DownLoad: CSV

Figure 1. Rate of convergence in space direction for different values of

$\alpha$ and

$\beta$ at

$\tau = 1/500$ .

DownLoad: Full-Size Img PowerPoint

6. Conclusions and remarks

In this study, we introduced an effective spectral Galerkin approach to handle the nonlinear fractional order reaction-diffusion equations with a fixed delay. This approach is accomplished by constructing a numerical algorithm that integrates the efficacy of $L2-1_\sigma$ type approximation side by side to the effectiveness of the Galerkin spectral Legendre technique. In other words, on a uniform mesh, we used the $L2-1_\sigma$ difference formula and the Legendre-Galerkin spectral technique for time and space discretizations, respectively. According to the literature overview, the majority of earlier research provided error estimates only in a limited (local) time period or when the numerical solution declines in time. However, we presented a theoretical analysis to obtain the optimal error estimates for the suggested scheme with no constraints compared to earlier studies, using the developed $L2-1_\sigma$ fractional Grönwall type inequality in a discrete version. In the case of smooth solutions, the suggested scheme's convergence analysis was established, and it was demonstrated that the scheme under consideration is effective with second-order precision in time and spectral accuracy in space. In the situation of a non-smooth solution in time, a high-order graded $L2-1_\sigma$ scheme can be dealt with using a non-uniform Alikhanov scheme ^[55,57] to preserve the second order. Additionally, a more generic investigation for problem (1.1) is possible by replacing the fixed delay with a distributed one. These preparations are meant to serve as a road map for future study. Finally, a numerical test is offered to demonstrate the effectiveness of the proposed scheme and show that is consistent with theoretical results.

Acknowledgment

The authors are grateful to the handling editor and the anonymous referees for their constructive feedback and helpful suggestions, which highly improved the paper. V.G. Pimenov wishes to acknowledge the support of the RSF grant, project 22-21-00075.

Conflict of interest

The authors declare no conflict of interest.

References

[1]	V. S. Chandel, Gl. Wang, M. Talha, Advances in modelling and analysis of nano structures: A review, Nanotechn. Rev., 9 (2020), 230-258. https://doi.org/10.1515/ntrev-2020-0020 doi: 10.1515/ntrev-2020-0020
[2]	R. H. J. Peerlings, N. A. Fleck, Computational evaluation of strain gradient elasticity constants, Int. J. Multiscale Comput. Eng., 2 (2004), 599-619. https://doi.org/10.1615/IntJMultCompEng.v2.i4.60 doi: 10.1615/IntJMultCompEng.v2.i4.60
[3]	B. I. Yakobson, C. Brabec, J. Bernholc, Nanomechanics of carbon tubes: Instabilities beyond linear response, Phys. Rev. Lett., 76 (1996), 2511. https://doi.org/10.1103/PhysRevLett.76.2511 doi: 10.1103/PhysRevLett.76.2511
[4]	L. Behera, S. Chakraverty, Recent researches on nonlocal elasticity theory in the vibration of carbon nanotubes using beam models, Arch. Comput. Meth. Eng., 24 (2017), 481-494. https://doi.org/10.1007/s11831-016-9179-y doi: 10.1007/s11831-016-9179-y
[5]	B. Arash, Q. Wang, A review on the application of nonlocal elastic models in modeling of carbon nanotubes and graphenes, Comput. Mater. Sci., 51 (2012), 303-313. https://doi.org/10.1016/j.commatsci.2011.07.040 doi: 10.1016/j.commatsci.2011.07.040
[6]	Y. Liu, J. Reddy, A nonlocal curved beam model based on a modified couple stress theory, Int. J. Struc. Stab. Dynam., 11 (2011), 495-512. https://doi.org/10.1142/s0219455411004233 doi: 10.1142/s0219455411004233
[7]	S. Park, X. Gao, Bernoulli-Euler beam model based on a modified couple stress theory, J. Microm. Microeng., 16 (2006), 2355. https://doi.org/10.1061/40830(188)166 doi: 10.1061/40830(188)166
[8]	A. C. Eringen, On differential equations of nonlocal elasticity and solutions of screw dislocation and surface waves, J. Appl. Phys., 54 (1983). 4703-4710. http://dx.doi.org/10.1063/1.332803 doi: 10.1063/1.332803
[9]	A. C. Eringen, Nonlocal continuum field theories. Springer Science & Business Media, Springer-Verlag: New York, 2002.
[10]	A. C. Eringen, D. Edelen, On nonlocal elasticity, Int. J. Eng Sci., 10 (1972), 233-248. https://doi.org/10.1016/0020-7225(72)90039-0 doi: 10.1016/0020-7225(72)90039-0
[11]	A. C. Eringen, Nonlocal polar field theory. In: A.C. Eringen (ed.), Continuum Physics. 4. Academic Press: New York, 1976.
[12]	A. Farajpour, M. H. Ghayesh, H. Farokhi, A review on the mechanics of nanostructures, Int. J. Eng. Sci., 133 (2018), 231-263. https://doi.org/10.1016/j.ijengsci.2018.09.006 doi: 10.1016/j.ijengsci.2018.09.006
[13]	C. Lim, G. Zhang, J. Reddy, A higher-order nonlocal elasticity and strain gradient theory and its applications in wave propagation, J. Mech. Phys. Solids, 78 (2015), 298-313. https://doi.org/10.1016/j.jmps.2015.02.001 doi: 10.1016/j.jmps.2015.02.001
[14]	E. C. Aifantis, On the role of gradients in the localization of deformation and fracture, Int. J. Eng. Sci., 30 (1992), 1279-1299. https://doi.org/10.1016/0020-7225(92)90141-3 doi: 10.1016/0020-7225(92)90141-3
[15]	L. Li, Y. Hu, L. Ling, Wave propagation in viscoelastic single-walled carbon nanotubes with surface effect under magnetic field based on nonlocal strain gradient theory, Physica E: Low-dimensional Sys. Nanostruc., 75 (2016), 118-124. https://doi.org/10.1016/j.physe.2015.09.028 doi: 10.1016/j.physe.2015.09.028
[16]	J. L. Liu, Y. Mei, R. Xia, W. L. Zhu, Large displacement of a static bending nanowire with surface effects, Physica E: Low-Dimensional Sys. Nanostruc., 44 (2012), 2050-2055. https://doi.org/10.1016/j.physe.2012.06.009 doi: 10.1016/j.physe.2012.06.009
[17]	F. Yang, A. C. M. Chong, D. C. C. Lam, P. Tong, Couple stress based strain gradient theory for elasticity, Int. J. Solids Struct., 39 (2002), 2731-2743. https://doi.org/10.1016/S0020-7683(02)00152-X doi: 10.1016/S0020-7683(02)00152-X
[18]	R. D. Mindlin, Second gradient of strain and surface-tension in linear elasticity, Int. J. Solids Struct., 1 (1965), 417-438. https://doi.org/10.1016/0020-7683(65)90006-5 doi: 10.1016/0020-7683(65)90006-5
[19]	B. Akgöz, Ö. Civalek, A size-dependent shear deformation beam model based on the strain gradient elasticity theory, Int. J. Eng. Sci., 70 (2013), 1-14. https://doi.org/10.1016/j.ijengsci.2013.04.004 doi: 10.1016/j.ijengsci.2013.04.004
[20]	R. Barretta, F. M. de Sciarra, Variational nonlocal gradient elasticity for nano-beams, Int. J. Eng. Sci., 143 (2019), 73-91. https://doi.org/10.1016/j.ijengsci.2019.06.016 doi: 10.1016/j.ijengsci.2019.06.016
[21]	C. Li, H. Qing, C. F. Gao, Theoretical analysis for static bending of Euler-Bernoulli using different nonlocal gradient models, Mech. Adv. Mater. Struct., 28 (2020), 1965-1977. https://doi.org/10.1080/15376494.2020.1716121 doi: 10.1080/15376494.2020.1716121
[22]	S. K. Jena, S. Chakraverty, M. Malikan, H. Mohammad-Sedighi, Hygro-magnetic vibration of the single-walled carbon nanotube with nonlinear temperature distribution based on a modified beam theory and nonlocal strain gradient model, Int. J. Appl. Mech., 12 (2020), 2050054. https://doi.org/10.1142/S1758825120500544 doi: 10.1142/S1758825120500544
[23]	S. Zeng, K. Wang, B. Wang, J. Wu, Vibration analysis of piezoelectric sandwich nanobeam with flexoelectricity based on nonlocal strain gradient theory, Appl. Math. Mech., 41 (2020), 859-880. https://doi.org/10.1007/s10483-020-2620-8 doi: 10.1007/s10483-020-2620-8
[24]	P. Bian, H. Qing, On bending consistency of Timoshenko beam using differential and integral nonlocal strain gradient models, ZAMM J. Appl. Math. Mech., 101 (2021), e202000132. https://doi.org/10.1002/zamm.202000132 doi: 10.1002/zamm.202000132
[25]	P. Jiang, H. Qing, C. Gao, Theoretical analysis on elastic buckling of nanobeams based on stress-driven nonlocal integral model, Appl. Math. Mech., 41 (2019), 207-232. https://doi.org/10.1007/s10483-020-2569-6 doi: 10.1007/s10483-020-2569-6
[26]	P. Zhang, H. Qing, The consistency of the nonlocal strain gradient integral model in size-dependent bending analysis of beam structures, Int. J. Mech. Sci., 189 (2021), 105991. https://doi.org/10.1016/j.ijmecsci.2020.105991 doi: 10.1016/j.ijmecsci.2020.105991
[27]	S. Narendar, S. Gopalakrishnan, Nonlocal wave propagation in rotating nanotube, Results Phys., 1 (2011), 17-25. https://doi.org/10.1016/j.rinp.2011.06.002 doi: 10.1016/j.rinp.2011.06.002
[28]	F. Ebrahimi, M. R. Barati, P. Haghi, Wave propagation analysis of size-dependent rotating inhomogeneous nanobeams based on nonlocal elasticity theory, J. Vibr. Control, 24 (2018), 3809-3818. https://doi.org/10.1177/1077546317711537 doi: 10.1177/1077546317711537
[29]	M. Malik, D. Das, Free vibration analysis of rotating nano-beams for flap-wise, chord-wise and axial modes based on Eringen's nonlocal theory, Int. J. Mech. Sci., 179 (2020), 105655. https://doi.org/10.1016/j.ijmecsci.2020.105655 doi: 10.1016/j.ijmecsci.2020.105655
[30]	L. Hao-nan, L. Cheng, S. Ji-ping, Y. Lin-quan, Vibration analysis of rotating functionally graded piezoelectric nanobeams based on the nonlocal elasticity theory, J. Vibr. Eng. Techn., (2021), https://doi.org/10.1007/s42417-021-00288-9. doi: 10.1007/s42417-021-00288-9
[31]	M. Mohammadi, M. Safarabadi, A. Rastgoo, A. Farajpour, Hygro-mechanical vibration analysis of a rotating viscoelastic nanobeam embedded in a visco-Pasternak elastic medium and in a nonlinear thermal environment, Acta Mechanica, 227 (2016), 2207-2232. https://doi.org/10.1007/s00707-016-1623-4 doi: 10.1007/s00707-016-1623-4
[32]	S. Faroughi, A. Rahmani, M. I. Friswell, On wave propagation in two-dimensional functionally graded porous rotating nano-beams using a general nonlocal higher-order beam model, Appl. Math. Model., 80 (2020), 169-190. https://doi.org/10.1016/j.apm.2019.11.040 doi: 10.1016/j.apm.2019.11.040
[33]	F. Ebrahimi, A. Dabbagh, Wave dispersion characteristics of rotating heterogeneous magneto-electro-elastic nanobeams based on nonlocal strain gradient elasticity theory, J. Electro. Waves Applic., 32 (2018), 138-169. https://doi.org/10.1080/09205071.2017.1369903 doi: 10.1080/09205071.2017.1369903
[34]	A. Rahmani, B. Safaei, Z. Qin, On wave propagation of rotating viscoelastic nanobeams with temperature effects by using modified couple stress-based nonlocal Eringen's theory, Eng. Comput., (2021). https://doi.org/10.1007/s00366-021-01429-0. doi: 10.1007/s00366-021-01429-0
[35]	S. M. Ragab, A. E. Abouelregal, H. F. AlShaibi, R. A. Mansouri, Heat transfer in biological spherical tissues during hyperthermia of magnetoma, Biology, 10 (2021), 1259. https://doi.org/10.3390/biology10121259 doi: 10.3390/biology10121259
[36]	A. Babaei, M. Arabghahestani, Free vibration analysis of rotating beams based on the modified couple stress theory and coupled displacement field, Appl. Mech., 2 (2021), 226-238. https://doi.org/10.3390/applmech2020014 doi: 10.3390/applmech2020014
[37]	A. E. Abouelregal, H. Ahmad, Thermodynamic modeling of viscoelastic thin rotating microbeam based on non-Fourier heat conduction, Appl. Math. Modell., 91 (2021), 973-988. https://doi.org/10.1016/j.apm.2020.10.006 doi: 10.1016/j.apm.2020.10.006
[38]	A. E. Abouelregal, H. Ahmad, K. A. Gepreeld, P. Thounthong, Modelling of vibrations of rotating nanoscale beams surrounded by a magnetic field and subjected to a harmonic thermal field using a state-space approach, Europ. Phys. J. Plus, 136 (2021), 268. https://doi.org/10.1140/epjp/s13360-021-01257-7 doi: 10.1140/epjp/s13360-021-01257-7
[39]	A. E. Abouelregal, H. Ahmad, T. A. Nofal, H. Abu-Zinadah, Thermo-viscoelastic fractional model of rotating nanobeams with variable thermal conductivity due to mechanical and thermal loads, Mod. Phys. Lett. B, 35 (2021), 2150297. https://doi.org/10.1142/S0217984921502973 doi: 10.1142/S0217984921502973
[40]	A. E. Abouelregal, H. M. Sedighi, S. A. Faghidian, A. H. Shirazi, Temperature-dependent physical characteristics of the rotating nonlocal nanobeams subject to a varying heat source and a dynamic load, Facta Univer. Series: Mech. Eng., 19 (2021), 633-656. https://doi.org/10.22190/FUME201222024A doi: 10.22190/FUME201222024A
[41]	A. E. Abouelregal, H. M. Sedighi, The effect of variable properties and rotation in a visco-thermoelastic orthotropic annular cylinder under the Moore-Gibson-Thompson heat conduction model, Proc. Institut. Mech. Eng., Part L: J. Mat.: Design Appl., 235 (2021), 1004-1020. https://doi.org/10.1177/1464420720985899 doi: 10.1177/1464420720985899
[42]	H.W. Lord, Y. H. Shulman, A generalized dynamical theory of thermoelasticity, J. Mech. Phys. Solids, 15 (1967), 299-309. https://doi.org/10.1016/0022-5096(67)90024-5 doi: 10.1016/0022-5096(67)90024-5
[43]	D. Y. Tzou, Thermal shock phenomena under high rate response in solids, Annual Rev. Heat Trans., 4 (1992), 111-185. https://doi.org/10.1615/AnnualRevHeatTransfer.v4.50 doi: 10.1615/AnnualRevHeatTransfer.v4.50
[44]	D. Y. Tzou, A unified field approach for heat conduction from macro-to micro-scales, J. Heat Trans., 117 (1995), 8-16. https://doi.org/10.1115/1.2822329 doi: 10.1115/1.2822329
[45]	D. Y. Tzou, The generalized lagging response in small-scale and high-rate heating, Int. J. Heat Mass Trans., 38 (1995), 3231-3240. https://doi.org/10.1016/0017-9310(95)00052-B doi: 10.1016/0017-9310(95)00052-B
[46]	A. E. Abouelregal, Two-temperature thermoelastic model without energy dissipation including higher order time-derivatives and two phase-lags, Mater. Res. Express, 6 (2019), 116535. http://dx.doi.org/10.1088/2053-1591/ab447f doi: 10.1088/2053-1591/ab447f
[47]	A. E. Abouelregal, On Green and Naghdi thermoelasticity model without energy dissipation with higher order time differential and phase-lags, J. Appl. Comp. Mech., 6 (2020), 445-456. http://doi.org/10.22055/JACM.2019.29960.1649 doi: 10.22055/JACM.2019.29960.1649
[48]	A. E. Abouelregal, A novel generalized thermoelasticity with higher-order time-derivatives and three-phase lags, Multidiscip. Model. Ma. Structures, 16 (2020), 689-711. https://doi.org/10.1108/MMMS-07-2019-0138 doi: 10.1108/MMMS-07-2019-0138
[49]	A. E. Abouelregal, Three-phase-lag thermoelastic heat conduction model with higher-order time-fractional derivatives, Indian J. Phys., 94 (2020), 1949-1963. https://doi.org/10.1007/s12648-019-01635-z doi: 10.1007/s12648-019-01635-z
[50]	D. Singh, G. Kaur, S. K. Tomar, Waves in nonlocal elastic solid with voids, J. Elast., 128 (2017), 85-114. https://doi.org/10.1016/j.euromechsol.2018.03.015 doi: 10.1016/j.euromechsol.2018.03.015
[51]	R. D. Mindlin, Micro-structure in linear elasticity, Arch. Rat. Mech. Analy., 16 (1964), 51-78. https://doi.org/10.1007/BF00248490 doi: 10.1007/BF00248490
[52]	M. Jirasek, Nonlocal theories in continuum mechanics, Acta Polytech., 44 (2004), 16-34. https://doi.org/10.14311/610 doi: 10.14311/610
[53]	J. Reddy, Nonlocal theories for bending, buckling and vibration of beams, Int. J. Eng. Sci., 45 (2007), 288-307. https://doi.org/10.1016/j.ijengsci.2007.04.004 doi: 10.1016/j.ijengsci.2007.04.004
[54]	D. C. C. Lam, F. Yang, A. C. M. Chong, J. Wang, P. Tong, Experiments and theory in strain gradient elasticity, J. Mech. Phys. Solids, 51 (2003), 1477-1508. https://doi.org/10.1016/S0022-5096(03)00053-X doi: 10.1016/S0022-5096(03)00053-X
[55]	L. Li, H. Tang, Y. Hu, The effect of thickness on the mechanics of nanobeams, Int. J. Eng. Sci., 123 (2018), 81-91. https://doi.org/10.1016/j.ijengsci.2017.11.021 doi: 10.1016/j.ijengsci.2017.11.021
[56]	G. Honig, U. Hirdes, A method for the numerical inversion of Laplace transform, J. Comput. Appl. Math., 10 (1984), 113-132. https://doi.org/10.1016/0377-0427(84)90075-X doi: 10.1016/0377-0427(84)90075-X
[57]	A. Cheng, P. Sidauruk, Approximate inversion of the Laplace transform, Math. J., 4 (1994), 76-82. Corpus ID: 53626109
[58]	H. Hassanzadeh, M. Poolad-Darvish, Comparison of different numerical Laplace inversion methods for engineering application, Appl. Math. Comput., 189 (2007), 1966-1981. https://doi.org/10.1016/j.amc.2006.12.072 doi: 10.1016/j.amc.2006.12.072
[59]	B. Gu, T. He, Y. Ma, Thermoelastic damping analysis in micro-beam resonators considering nonlocal strain gradient based on dual-phase-lag model, Int. J. Heat Mass Trans., 180 (2021), 121771. https://doi.org/10.1016/j.ijheatmasstransfer.2021.121771 doi: 10.1016/j.ijheatmasstransfer.2021.121771
[60]	X. Li, L. Li, Y. Hu, Z. Ding, W. Deng, Bending, buckling and vibration of axially functionally graded beams based on nonlocal strain gradient theory, Comp. Struc., 165 (2017), 250-265. https://doi.org/10.1016/j.compstruct.2017.01.032 doi: 10.1016/j.compstruct.2017.01.032
[61]	L. Lu, X. Guo, J. Zhao, A unified nonlocal strain gradient model for nanobeams and the importance of higher order terms, Int. J. Eng. Sci., 119 (2017), 265-277. https://doi.org/10.1016/j.ijengsci.2017.06.024 doi: 10.1016/j.ijengsci.2017.06.024
[62]	L. Lu, X. Guo, J. Zhao, Size-dependent vibration analysis of nanobeams based on the nonlocal strain gradient theory, Int. J. Eng. Sci., 116 (2017), 12-24. https://doi.org/10.1016/j.ijengsci.2017.03.006 doi: 10.1016/j.ijengsci.2017.03.006
[63]	X. Zhu, L. Li, Closed form solution for a nonlocal strain gradient rod in tension, Int. J. Eng. Sci., 119 (2017), 16-28. https://doi.org/10.1016/j.ijengsci.2017.06.019 doi: 10.1016/j.ijengsci.2017.06.019
[64]	S. Singh, D. Kumar, K. N. Rai, Convective-radiative fin with temperature dependent thermal conductivity, heat transfer coefficient and wavelength dependent surface emissivity, Propuls. Power Res., 3 (2014), 207-221. https://doi.org/10.1016/j.jppr.2014.11.003 doi: 10.1016/j.jppr.2014.11.003
[65]	C. B. Xiong, L. N. Yu, Y. B. Niu, Effect of variable thermal conductivity on the generalized thermoelasticity problems in a fiber-reinforced anisotropic half-space, Advan. Mater. Sci. Eng., 2019 (2019), Article ID 8625371. https://doi.org/10.1155/2019/8625371 doi: 10.1155/2019/8625371
[66]	C. Xiong, Y. Guo, Effect of variable properties and moving heat source on magnetothermoelastic problem under fractional order thermoelasticity, Advan. Mater. Sci. Eng., 2016 (2016), Article ID 5341569. https://doi.org/10.1155/2016/5341569 doi: 10.1155/2016/5341569
[67]	A. S. V. Kanth, N. U. Kumar, A haar wavelet study on convective-radiative fin under continuous motion with temperature-dependent thermal conductivity, Walailak J. Sci. Techn., 11 (2014), 211-224. https://doi.org/10.14456/WJST.2014.40 doi: 10.14456/WJST.2014.40
[68]	Y. Wang, D. Liu, Q. Wang, J. Zhou, Asymptotic solutions for generalized thermoelasticity with variable thermal material properties, Arch. Mech., 68 (2016), 181-202. https://doi.org/10.1142/S1758825113500233 doi: 10.1142/S1758825113500233
[69]	F. Ebrahimi, P. Haghi, Elastic wave dispersion modelling within rotating functionally graded nanobeams in thermal environment, Adv. Nano Res., 6 (2018), 201-217. https://doi.org/10.12989/anr.2018.6.3.201 doi: 10.12989/anr.2018.6.3.201

Reader Comments

Your name:*

Email:*
© 2022 the Author(s), licensee AIMS Press. This is an open access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0)
