A criterion of collective behavior of bacteria

Roman Czapla; Vladimir V. Mityushev; Roman Czapla; Vladimir V. Mityushev

doi:10.3934/mbe.2017018

Mathematical Biosciences and Engineering

2017, Volume 14, Issue 1: 277-287. doi: 10.3934/mbe.2017018

Previous Article Next Article

A criterion of collective behavior of bacteria

Roman Czapla ,
Vladimir V. Mityushev ^,

Institute of Computer Science, Pedagogical University, ul. Podchorazych 2, Krakow 30-084, Poland

Received: 01 October 2015 Accepted: 05 February 2016 Published: 01 January 2017
MSC : Primary: 92B15, 92B25; Secondary: 74Q15

It was established in the previous works that hydrodynamic interactions between the swimmers can lead to collective motion. Its implicit evidences were confirmed by reduction in the effective viscosity. We propose a new quantitative criterion to detect such a collective behavior. Our criterion is based on a new computationally effective RVE (representative volume element) theory based on the basic statistic moments ($e$-sums or generalized Eisenstein-Rayleigh sums). The criterion can be applied to various two-phase dispersed media (biological systems, composites etc). The locations of bacteria are modeled by short segments having a small width randomly embedded in medium without overlapping. We compute the $e$-sums of the simulated disordered sets and of the observed experimental locations of Bacillus subtilis. The obtained results show a difference between these two sets that demonstrates the collective motion of bacteria.
- Collective behavior of bacteria,
- disordered random sets,
- generalized Eisenstein-Rayleigh sums,
- RVE,
- non-overlapping segments on plane
Citation: Roman Czapla, Vladimir V. Mityushev. A criterion of collective behavior of bacteria[J]. Mathematical Biosciences and Engineering, 2017, 14(1): 277-287. doi: 10.3934/mbe.2017018

Related Papers:

Abstract

It was established in the previous works that hydrodynamic interactions between the swimmers can lead to collective motion. Its implicit evidences were confirmed by reduction in the effective viscosity. We propose a new quantitative criterion to detect such a collective behavior. Our criterion is based on a new computationally effective RVE (representative volume element) theory based on the basic statistic moments ($e$-sums or generalized Eisenstein-Rayleigh sums). The criterion can be applied to various two-phase dispersed media (biological systems, composites etc). The locations of bacteria are modeled by short segments having a small width randomly embedded in medium without overlapping. We compute the $e$-sums of the simulated disordered sets and of the observed experimental locations of Bacillus subtilis. The obtained results show a difference between these two sets that demonstrates the collective motion of bacteria.

References

[1]	[ N. I. Akhiezer, Elements of Theory of Elliptic Functions Nauka, 1970 (in Russian); Engl. transl. AMS, 1990.
[2]	[ R. Czapla,V. V. Mityushev,W. Nawalaniec, Effective conductivity of random two-dimensional composites with circular non-overlapping inclusions, Computational Materials Science, 63 (2012): 118-126.
[3]	[ R. Czapla,V. V. Mityushev,W. Nawalaniec, Simulation of representative volume elements for random 2D composites with circular non-overlapping inclusions, Theoretical and Applied Informatics, 24 (2012): 227-242.
[4]	[ R. Czapla,V. V. Mityushev,N. Rylko, Conformal mapping of circular multiply connected domains onto segment domains, Electron. Trans. Numer. Anal., 39 (2012): 286-297.
[5]	[ S. Gluzman,D. A. Karpeev,L. V. Berlyand, Effective viscosity of puller-like microswimmers: A renormalization approach, J. R. Soc. Interface, 10 (2013): 1-10.
[6]	[ V. V. Mityushev, Representative cell in mechanics of composites and generalized Eisenstein--Rayleigh sums, Complex Variables, 51 (2006): 1033-1045.
[7]	[ V. V. Mityushev,P. Adler, Longitudial permeability of a doubly periodic rectangular array of circular cylinders, I, ZAMM (Journal of Applied Mathematics and Mechanics), 82 (2002): 335-345.
[8]	[ V. V. Mityushev,W. Nawalaniec, Basic sums and their random dynamic changes in description of microstructure of 2D composites, Computational Materials Science, 97 (2015): 64-74.
[9]	[ V. V. Mityushev,N. Rylko, Optimal distribution of the non-overlapping conducting disks, Multiscale Model. Simul., 10 (2012): 180-190.
[10]	[ W. Nawalaniec, Algorithms for computing symbolic representations of basic e–sums and their application to composites Journal of Symbolic Computation 74 (2016), 328–345.
[11]	[ M. Potomkin, V. Gyrya, I. Aranson and L. Berlyand, Collision of microswimmers in viscous fluid Physical Review E 87 (2013), 053005.
[12]	[ S. D. Ryan,L. Berlyand,B. M. Haines,D. A. Karpeev, A kinetic model for semi-dilute bacterial suspensions, Multiscale Model. Simul., 11 (2013): 1176-1196.
[13]	[ S. D. Rayn, B. M. Haines, L. Berlyand, F. Ziebert and I. S. Aranson, Viscosity of bacterial suspensions: Hydrodynamic interactions and self-induced noise Rapid Communication to Phys. Rev. E 83 (2011), 050904(R).
[14]	[ S. D. Ryan, A. Sokolov, L. Berlyand and I. S. Aranson, Correlation properties of collective motion in bacterial suspensions New Journal of Physics 15 (2013), 105021, 18pp.
[15]	[ N. Rylko, Representative volume element in 2D for disks and in 3D for balls, J. Mechanics of Materials and Structures, 9 (2014): 427-439.
[16]	[ A. Sokolov and I. S. Aranson, Reduction of viscosity in suspension of swimming bacteria Phys. Rev. Lett. 103 (2009), 148101.
[17]	[ A. Sokolov and I. S. Aranson, Physical properties of collective motion in suspensions of bacteria Phys. Rev. Lett. 109 (2012), 248109.
[18]	[ A. Sokolov, I. S. Aranson, J. O. Kessler and R. E. Goldstein, Concentration dependence of the collective dynamics of swimming bacteria Physical Review Letters 98 (2007), 158102.
[19]	[ A. Sokolov, R. E. Goldstein, F. I. Feldstein and I. S. Aranson, Enhanced mixing and spatial instability in concentrated bacteria suspensions, Phys. Rev. E, 80 (2009), 031903.
[20]	[ M. Tournus,L. V. Berlyand,A. Kirshtein,I. Aranson, Flexibility of bacterial flagella in external shear results in complex swimming trajectories, Journal of the Royal Society Interface, 12 (2015): 1-11.
[21]	[ A. Weil, Elliptic Functions According to Eisenstein and Kronecker Springer-Verlag, 1976.
