Vibration suppression and Hopf bifurcation control in a nonlinear rotating pendulum using time-delayed acceleration feedback

Khalid Alluhydan ^{1
,
,},
M. N. Abd EL-Salam ²

1.
Department of Mechanical Engineering, College of Engineering, King Saud University, Riyadh 12372, Saudi Arabia
2.
Basic Sciences Department, Common First Year Deanship, King Saud University, Riyadh 12373, Saudi Arabia

Received: 29 May 2026 Revised: 26 June 2026 Accepted: 30 June 2026 Published: 21 July 2026
MSC : 34C15, 34C46, 34F15, 70H03, 74G10

The nonlinear vibration characteristics of a rotating pendulum subjected to harmonic excitation were examined in this work. To mitigate excessive oscillations and improve dynamic stability, a negative delayed acceleration feedback control scheme was implemented. Approximate analytical solutions were derived near the primary resonance using the method of multiple scales, resulting in nonlinear modulation equations that govern the amplitude and phase evolution. The steady-state response and its stability were analyzed through eigenvalue-based linearization techniques. Numerical simulations employing a fourth-order Runge–Kutta algorithm were performed to verify the analytical predictions and to explore the influence of key system parameters. The effects of detuning, excitation amplitude, nonlinear modulation strength, control gain, and time delay on the system response and stability were systematically investigated. The results demonstrate that time delay significantly alters stability boundaries through Hopf bifurcations, while appropriate tuning of the delayed feedback enhances vibration suppression. A good agreement between analytical and numerical results confirms the applicability of the perturbation approach and highlights the effectiveness of delayed acceleration control in suppressing nonlinear oscillations.
- rotating pendulum,
- time-delayed acceleration control,
- primary resonance,
- Hopf bifurcation
Citation: Khalid Alluhydan, M. N. Abd EL-Salam. Vibration suppression and Hopf bifurcation control in a nonlinear rotating pendulum using time-delayed acceleration feedback[J]. AIMS Mathematics, 2026, 11(7): 21654-21673. doi: 10.3934/math.2026876

Related Papers:

Abstract

The nonlinear vibration characteristics of a rotating pendulum subjected to harmonic excitation were examined in this work. To mitigate excessive oscillations and improve dynamic stability, a negative delayed acceleration feedback control scheme was implemented. Approximate analytical solutions were derived near the primary resonance using the method of multiple scales, resulting in nonlinear modulation equations that govern the amplitude and phase evolution. The steady-state response and its stability were analyzed through eigenvalue-based linearization techniques. Numerical simulations employing a fourth-order Runge–Kutta algorithm were performed to verify the analytical predictions and to explore the influence of key system parameters. The effects of detuning, excitation amplitude, nonlinear modulation strength, control gain, and time delay on the system response and stability were systematically investigated. The results demonstrate that time delay significantly alters stability boundaries through Hopf bifurcations, while appropriate tuning of the delayed feedback enhances vibration suppression. A good agreement between analytical and numerical results confirms the applicability of the perturbation approach and highlights the effectiveness of delayed acceleration control in suppressing nonlinear oscillations.

References

[1]	X. Xu, M. Wiercigroch, M. Cartmell, Rotating orbits of a parametrically-excited pendulum, Chaos, Soliton Fract., 23 (2005), 1537–1548. https://doi.org/10.1016/j.chaos.2004.06.053 doi: 10.1016/j.chaos.2004.06.053
[2]	M. Lakshmanan, S. Rajasekar, Nonlinear dynamics: Integrability, chaos and patterns, Berlin, Heidelberg: Springer, 2003. https://doi.org/10.1007/978-3-642-55688-3
[3]	A. O. Belyakov, A. P. Seyranian, A. Luongo, Dynamics of the pendulum with periodically varying length, Physica D, 238 (2009), 1589–1597. https://doi.org/10.1016/j.physd.2009.04.015 doi: 10.1016/j.physd.2009.04.015
[4]	M. Farkas, Periodic motions, New York: Springer, 1994. https://doi.org/10.1007/978-1-4757-4211-4
[5]	M. Colera, M. Pérez-Saborid, Numerical investigation of the effects of compressibility on the flutter of a cantilevered plate in an inviscid, subsonic, open flow, J. Sound Vib., 423 (2018), 442–458. https://doi.org/10.1016/j.jsv.2018.01.041 doi: 10.1016/j.jsv.2018.01.041
[6]	A. H. Nayfeh, D. T. Mook, Nonlinear oscillations, Wiley, 1995. https://doi.org/10.1002/9783527617586
[7]	A. H. Nayfeh, Perturbation methods, Wiley, 2000. https://doi.org/10.1002/9783527617609
[8]	A. H. Nayfeh, B. Balachandran, Applied nonlinear dynamics: Analytical, computational, and experimental methods, New York: Wiley, 1995. https://doi.org/10.1002/9783527617548
[9]	R. H. Rand, Lecture notes on nonlinear vibrations, 2012.
[10]	P. Wahi, A. Chatterjee, Averaging oscillations with small fractional damping and delayed terms, Nonlinear Dyn., 38 (2004), 3–22. https://doi.org/10.1007/s11071-004-3744-x doi: 10.1007/s11071-004-3744-x
[11]	K. Wu, C. Ren, Y. Chen, Time-delay vibration reduction control of 3-DOF vehicle model with vehicle seat, Appl. Sci., 11 (2021), 9426. https://doi.org/10.3390/app11209426 doi: 10.3390/app11209426
[12]	X. Sun, Y. Qu, F. Wang, J. Xu, Effects of time-delayed vibration absorber on bandwidth of beam for low broadband vibration suppression, Appl. Math. Mech., 44 (2023), 1629–1650. https://doi.org/10.1007/s10483-023-3038-6 doi: 10.1007/s10483-023-3038-6
[13]	Y. Guo, G. F. Xu, C. Y. Duan, Research on time-delayed vibration reduction control of 1/4 vehicle semi-active suspension system with three degrees of freedom, Adv. Mech. Eng., 16 (2024), 1–11. https://doi.org/10.1177/16878132241273541 doi: 10.1177/16878132241273541
[14]	W. Chu, C. Li, Z. Lyu, Vibration mitigation of flexible beams through boundary motion with enhanced time-delayed control, Thin-Walled Struct., 210 (2025), 113056. https://doi.org/10.1016/j.tws.2025.113056 doi: 10.1016/j.tws.2025.113056
[15]	Y. A. Amer, A. T. El-Sayed, M. N. Abd EL-Salam, Position and velocity time delay for suppression vibrations of a hybrid rayleigh-van der pol-duffing oscillator, Sound Vib., 54 (2020), 149–161. https://doi.org/10.32604/sv.2020.08469 doi: 10.32604/sv.2020.08469
[16]	N. A. Saeed, J. Awrejcewicz, M. A. Alkashif, M. S. Mohamed, 2D and 3D visualization for the static bifurcations and nonlinear oscillations of a self-excited system with time-delayed controller, Symmetry, 14 (2022), 621. https://doi.org/10.3390/sym14030621 doi: 10.3390/sym14030621
[17]	H. S. Bauomy, A. T. El-Sayed, A time-delayed proportional-derivative controller for a dielectric elastomer circular membrane, Chin. J. Phys., 84 (2023), 216–231. https://doi.org/10.1016/j.cjph.2022.11.004 doi: 10.1016/j.cjph.2022.11.004
[18]	W. Li, L. Zhang, J. Cao, A note on Turing–Hopf bifurcation in a diffusive Leslie–Gower model with weak Allee effect on prey and fear effect on predator, Appl. Math. Lett., 172 (2026), 109741. https://doi.org/10.1016/j.aml.2025.109741 doi: 10.1016/j.aml.2025.109741
[19]	R. E. Abdullah, R. K. Hussein, Y. A. Amer, O. M. Khaled, M. I. Attia, A. M. Abd-Elal, et al., Nonlinear vibration reduction in vertical conveyor systems using a nonlinear integral negative derivative feedback controller, AIMS Math., 10 (2025), 28129–28150. https://doi.org/10.3934/math.20251237 doi: 10.3934/math.20251237
[20]	H. S. Bauomy, A. T. El-Sayed, Active control of a rectangular thin plate via negative acceleration feedback, J. Comput. Nonlinear Dyn., 11 (2016), 041025. https://doi.org/10.1115/1.4033307 doi: 10.1115/1.4033307
[21]	D. H. Yang, J. H. Shin, H. Lee, S. K. Kim, M. K. Kwak, Active vibration control of structure by active mass damper and multi-modal negative acceleration feedback control algorithm, J. Sound Vib., 392 (2017), 18–30. https://doi.org/10.1016/j.jsv.2016.12.036 doi: 10.1016/j.jsv.2016.12.036
[22]	Z. Cui, X. Zhang, T. Lu, Resonance analysis and time-delay feedback controllability for a fractional horizontal nonlinear roller system, AIMS Math., 9 (2024), 24832–24853. https://doi.org/10.3934/math.20241209 doi: 10.3934/math.20241209
[23]	E. Kaslik, E. A. Kokovics, A. Rădulescu, Stability and bifurcations in Wilson-Cowan systems with distributed delays, and an application to basal ganglia interactions, Commun. Nonlinear Sci. Numer. Simul., 104 (2022), 105984. https://doi.org/10.1016/j.cnsns.2021.105984 doi: 10.1016/j.cnsns.2021.105984
[24]	K. Mokni, H. Ali, B. Ghosh, M. Chaoui, Nonlinear dynamics of a Darwinian Ricker system with strong Allee effect and immigration, Math. Comput. Simul., 229 (2025), 789–813, https://doi.org/10.1016/j.matcom.2024.10.017 doi: 10.1016/j.matcom.2024.10.017
[25]	S. Chatterjee, Vibration control by recursive time-delayed acceleration feedback, J. Sound Vib., 317 (2008), 67–90. https://doi.org/10.1016/j.jsv.2008.03.020 doi: 10.1016/j.jsv.2008.03.020
[26]	Z. Wang, H. Hu, Q. Xu, G. Stepan, Effect of delay combinations on stability and Hopf bifurcation of an oscillator with acceleration-derivative feedback, Int. J. Non-Linear Mech., 94 (2017), 392–399. DOI:10.1016/j.ijnonlinmec.2016.10.008 doi: 10.1016/j.ijnonlinmec.2016.10.008
