Sliding-mode controller synthesis of robotic manipulator based on a new modified reaching law

Xinyu Shao ¹,
Zhen Liu ^{1,2
,
,},
Baoping Jiang ^{3
,
,}

1.
School of Automation, Qingdao University, Qingdao 266071, China
2.
Shandong Key Laboratory of Industrial Control Technology, Qingdao University, Qingdao 266071, China
3.
School of Electronic and Information Engineering, Suzhou University of Science and Technology, Suzhou 215000, China

Received: 29 January 2022 Revised: 13 March 2022 Accepted: 05 April 2022 Published: 22 April 2022

In this study, an adaptive modified reaching law-based switch controller design was developed for robotic manipulator systems using the disturbance observer (DO) approach. Firstly, a standard DO is employed to estimate the unknown disturbances of the plant, from which the control signal could be compensated. Then, an adaptive modified reaching law is established to dynamically adapt the switching gain of the sliding mode robust term and further guarantee the finite-time arrival of the established sliding surface. Additionally, the convergence of the error system is analyzed via the Lyapunov method. At last, the feasibility and effectiveness of the proposed control scheme are verified by using a two-joint robotic manipulator model. The simulation results show that the developed controller can achieve rapid tracking, reduce system chattering and improve the robustness of the plant. The main innovations of the work are as follows. 1) A new adaptive reaching law is proposed; it can reduce chattering effectively, and it has a fast convergence speed. 2) Regarding the nonlinear robotic manipulator model, a novel adaptive sliding-mode controller was synthesized based on the DO to estimate the unknown disturbance and ensure effective tracking of the desired trajectory.
- robotic manipulator,
- sliding-mode controller,
- modified reaching law,
- disturbance observer,
- Lyapunov method
Citation: Xinyu Shao, Zhen Liu, Baoping Jiang. Sliding-mode controller synthesis of robotic manipulator based on a new modified reaching law[J]. Mathematical Biosciences and Engineering, 2022, 19(6): 6362-6378. doi: 10.3934/mbe.2022298

Related Papers:

Abstract

In this study, an adaptive modified reaching law-based switch controller design was developed for robotic manipulator systems using the disturbance observer (DO) approach. Firstly, a standard DO is employed to estimate the unknown disturbances of the plant, from which the control signal could be compensated. Then, an adaptive modified reaching law is established to dynamically adapt the switching gain of the sliding mode robust term and further guarantee the finite-time arrival of the established sliding surface. Additionally, the convergence of the error system is analyzed via the Lyapunov method. At last, the feasibility and effectiveness of the proposed control scheme are verified by using a two-joint robotic manipulator model. The simulation results show that the developed controller can achieve rapid tracking, reduce system chattering and improve the robustness of the plant. The main innovations of the work are as follows. 1) A new adaptive reaching law is proposed; it can reduce chattering effectively, and it has a fast convergence speed. 2) Regarding the nonlinear robotic manipulator model, a novel adaptive sliding-mode controller was synthesized based on the DO to estimate the unknown disturbance and ensure effective tracking of the desired trajectory.
