A study on the surface grinding process of the SUJ2 steel using CBN slotted grinding wheel

Nhu-Tung Nguyen; Do Duc Trung; Nhu-Tung Nguyen; Do Duc Trung

doi:10.3934/matersci.2020.6.871

AIMS Materials Science

2020, Volume 7, Issue 6: 871-886. doi: 10.3934/matersci.2020.6.871

Previous Article Next Article

Research article Topical Sections

A study on the surface grinding process of the SUJ2 steel using CBN slotted grinding wheel

Nhu-Tung Nguyen ,
Do Duc Trung ^,

Faculty of Mechanical Engineering, Hanoi University of Industry, Hanoi City, 100000, Vietnam

Received: 30 September 2020 Accepted: 07 December 2020 Published: 10 December 2020

Using slotted grinding wheel in machining is a new approach in grinding technology. The slotted grinding wheel is used to improve the introduction of cool lubricant into the cutting zone, improve chip release condition and heat release condition during machining, thereby facilitating to improve the efficiency of the grinding process. However, up to now, the studies that are performed using this type of grinding wheel is very limited. To contribute some results to this rather new research direction, in this article we present the grinding process of SUJ2 steel using CBN slotted grinding wheel. The orthogonal Taguchi matrix with nine experiments was used to design the experimental matrix with three input parameters including workpiece velocity, feed rate, and depth of cut. The output parameters that were used to evaluate the quality and effectiveness of the grinding process were surface roughness, system vibrations in X, Y, Z directions, and the material removal rate. In surface grinding process using CBN slotted grinding wheel, all three input parameters (workpiece velocity, feed rate, and depth of cut) have a significant influence on the surface roughness, vibration. In which, the feed rate has the most influence on the output parameters. The second factor that influenced on the output parameter was the depth of cut. The workpiece velocity has the smallest influence on the output parameters. Data Envelopment Analysis Based Ranking (DEAR) method was used to solve the multi-objective optimization problem in surface grinding process. By applying this method, the optimal value of input parameter that were determined to obtain the minimum values of surface roughness and system vibration components, and to obtain the maximum of material removal rate. The optimum values of input parameters were the workpiece velocity of 15 m/min, the feed rate of 4 mm/stroke, and cutting depth of 0.015 mm. DEAR method can be applied to improve the quality and the effectiveness of the grinding process by reducing the surface roughness and system vibration components and increasing the material removal rate.
- CBN slotted grinding wheel,
- SUJ2 steel,
- surface roughness,
- vibration,
- MRR,
- DEAR
Citation: Nhu-Tung Nguyen, Do Duc Trung. A study on the surface grinding process of the SUJ2 steel using CBN slotted grinding wheel[J]. AIMS Materials Science, 2020, 7(6): 871-886. doi: 10.3934/matersci.2020.6.871

Related Papers:

Abstract

Using slotted grinding wheel in machining is a new approach in grinding technology. The slotted grinding wheel is used to improve the introduction of cool lubricant into the cutting zone, improve chip release condition and heat release condition during machining, thereby facilitating to improve the efficiency of the grinding process. However, up to now, the studies that are performed using this type of grinding wheel is very limited. To contribute some results to this rather new research direction, in this article we present the grinding process of SUJ2 steel using CBN slotted grinding wheel. The orthogonal Taguchi matrix with nine experiments was used to design the experimental matrix with three input parameters including workpiece velocity, feed rate, and depth of cut. The output parameters that were used to evaluate the quality and effectiveness of the grinding process were surface roughness, system vibrations in X, Y, Z directions, and the material removal rate. In surface grinding process using CBN slotted grinding wheel, all three input parameters (workpiece velocity, feed rate, and depth of cut) have a significant influence on the surface roughness, vibration. In which, the feed rate has the most influence on the output parameters. The second factor that influenced on the output parameter was the depth of cut. The workpiece velocity has the smallest influence on the output parameters. Data Envelopment Analysis Based Ranking (DEAR) method was used to solve the multi-objective optimization problem in surface grinding process. By applying this method, the optimal value of input parameter that were determined to obtain the minimum values of surface roughness and system vibration components, and to obtain the maximum of material removal rate. The optimum values of input parameters were the workpiece velocity of 15 m/min, the feed rate of 4 mm/stroke, and cutting depth of 0.015 mm. DEAR method can be applied to improve the quality and the effectiveness of the grinding process by reducing the surface roughness and system vibration components and increasing the material removal rate.

References

[1]	Farsky J, Baksa T, Zetek M (2020) Grinding of maraging steel 1.2709 with SiC grinding wheels and effect of grinding conditions on the surface roughness and wear of the wheels. Manuf Tech 20: 18–22.
[2]	Marinescu LD, Rowe WB, Dimitrov B, et al. (2004) Tribology of Abrasive Machining Processes, 1 Ed., Elsevier.
[3]	Malkin S (1998) Grinding Technology: Theory and Applications of Machining with Abrasives, New York: Industrial Press.
[4]	Tu HX, Hong TT, Nga NTT, et al. (2019) Influence of dressing parameters on surface roughness of workpiece for grinding hardened 9XC tool steel. IOP Conf Series: Materials Science and Engineering 542: 012008.
[5]	Son NH, Trung DD, Nguyen NT (2020) Surface Roughness Prediction in Grinding Process of the SKD11 Steel by using Response Surface Method. IOP Conf Series: Materials Science and Engineering 758: 012029.
[6]	Haddad M, Zitoune R, Eym F, et al. (2016) The effect of rectification of composite materials on the mechanical behavior of long fiber composite materials. AIMS Mater Sci 3: 645–657.
[7]	Ronoh KN, Mwema FM, Akinlabi SA, et al. (2019) Effects of cooling conditions and grinding depth on sustainable surface grinding of Ti–6Al–4V: Taguchi approach. AIMS Mater Sci 6: 697–712.
[8]	Lee KW, Wong PK, Zhang JH (2000) Study on the grinding of advanced ceramics with slotted diamond wheels. J Mater Process Technol 100: 230–235.
[9]	Marinescu ID, Hitchiner MP, Uhlmann E, et al. (2006) Handbook of Machining with Grinding Wheels, New York: CRC Press.
[10]	Malkin S, Guo C (2008) Theory and Applications of Machining with Abrasives, 2 Eds., New York: Industrial Press.
[11]	Cao Y, Guan J, Li B, et al. (2013), Modeling and simulation of grinding surface topography considering wheel vibration. Int J Adv Manuf Technol 66: 937–945.
[12]	Malkin S (1984) Grinding of metals: theory and applications. J Appl Metalwork 3: 95–109.
[13]	Aini R, Rahnejat H, Gohar R (1990) A five degrees of freedom analysis of vibrations in precision spindles. Int J Mach Tool Manu 30: 1–18.
[14]	Liu T, Deng Z, Lv L, et al. (2020). Experimental analysis of process parameter effects on vibrations in the high-speed grinding of a camshaft. Stroj Vestn-J Mech E 66: 175–183.
[15]	Nguyen NT, Dung HT, Trung DD (2020) Multi-objective optimization when surface grinding the 3X13 steel by combining the general reduced gradient algorithm and harmonic mean method. ASTESJ 5: 395–400.
[16]	Li C, Li X, Wu Y, et al. (2019) Deformation mechanism and force modelling of the grinding of YAG single crystals. Int J Mach Tools Manuf 143: 23–37.
[17]	Li C, Wu Y, Li X, et al. (2019) Deformation characteristics and surface generation modelling of crack-free grinding of GGG single crystals. J Mater Process Technol 279: 116577.
[18]	Lee KW, Wong PK, Zhang JH (2000) Study on the grinding of advanced ceramics with slotted diamond wheels. J Mater Process Technol 100: 230–235.
[19]	Jin DX, Meng Z (2003) Research for discontinuous grinding wheel with multi-porous grooves. Key Eng Mater 259: 117–121.
[20]	Fan X, Miller M (2004) Force analysis for segmental grinding. Proc of the ASPE Annual Meeting 84: 87.
[21]	Handigund PB, Miller MH (2001) Abrasive wear and forces in grinding of silicon carbide. Available from: https://pdfs.semanticscholar.org/9750/9eeb5d1820bfd6dd2dde60ff1b35d0198bc8.pdf.
[22]	Phuong NT, Giang NTP, Dong NT (2017) Research on the affect of technologycal parameters on cutting temperature when machining use segmented grinding wheel. IJECE 8: 208–212.
[23]	Phuong NT, Nguyen GPT, Nguyen DT (2017) A research on the effect of cutting parameters on cutting force in flat grinding using segmentd grinding wheel. Vietnam J Sci Technol 55: 793–802.
[24]	Sinha MK, Setti D, Ghosh S, et al. (2016). An investigation on surface burn during grinding of Inconel 718. J Manuf Process 21: 124–133.
[25]	Shi Z, Malkin S (2006) Wear of electroplated CBN grinding wheels. J Manuf Sci E-T Asme 128: 1–9.
[26]	Yu T (2016) Material removal modeling and life expectancy of electroplated CBN grinding wheel and paired polishing. [PhD's thesis]. Iowa State University, Iowa.
[27]	Heat treatment guide. Available from: https://steelnavigator.ovako.com/heat-treatment-guide/calculate/.
[28]	About: 100Cr6. Available from: https://steelnavigator.ovako.com/steel-grades/100cr6/.
[29]	Manoj M, Jinu GR, Muthuramalingam T (2018) Multi response optimization of AWJM process Parameterson machining TiB2 particles reinforced Al7075 composite using Taguchi-DEAR methodology. Silicon 10: 2287–2293.
[30]	Muthuramalingam T, Vasanth S, Vinothkumar P, et al. (2018) Multi criteria decision making of abrasive flow oriented process parameters in abrasive water jet machining using Taguchi-DEAR methodology. Silicon 10: 2015–2021.
[31]	Muthuramalingam T, Loganathan GB, Atif A, et al. (2019) Multi response optimization on machining titanium alloy using Taguchi-DEAR analysis in abrasive water jet cutting. SAE Tech Pap 28: 1–5.
[32]	Huu NH, Muthuramalingam T (2020) Multi criteria decision making of vibration assisted EDM process parameters on machining silicon steel using Taguchi-DEAR methodology. Silicon 32: 1–7.
[33]	Reddy V, Sridhar C (2016) Multi response optimization of EDM of AA6082 material using Taguchi-DEAR method. IJSTR 7: 215–219.
[34]	Muthuramalingam T, Vasanth S, Rabik M, et al. (2016) Multi response optimization of EDM process parameters using assignments of weight method. Int J Eng Res Technol 4: 1–3.
[35]	Sandeep MJ, Manjunath PGC, Chate GR, et al. (2019) Multi response optimization of green sand moulding parameters using Taguchi-DEAR method. Appl Mech Mater 895: 1–7.
